Steering replacement parts for 2016 Yamaha XT250

OEM Parts Yamaha 2016 Yamaha XT250 Steering

STEERING Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BEARING TAPRD Part #: 93332-00079-00 Required per assembly: 1 $75.98 $62.48 - + Add to cart
2	HOLDER, BRAKE, HOSE, 1 Part #: 3C5-25875-00-00 Required per assembly: 1 $10.49 $8.89 - + Add to cart
3	HOLDER, BRAKE, HOSE, 2 Part #: 3C5-25876-00-00 Required per assembly: 1 $4.79 $3.99 - + Add to cart
4	BOLT, FLANGE Part #: 95027-06010-00 Required per assembly: 1 $3.54 $2.43 - + Add to cart
5	BOLT, FLANGE Part #: 95817-06012-00 Required per assembly: 1 $1.95 $1.47 - + Add to cart
6	BEARING TAPRD Part #: 93332-00079-00 Required per assembly: 1 $75.98 $62.48 - + Add to cart
7	COVER, BALL, RACE, 1 Part #: 1J7-23415-00-00 Required per assembly: 1 $7.49 $6.31 - + Add to cart
8	WASHER, PLATE, (0.5T) Part #: 90201-256K5-00 Required per assembly: 1 Note: U.R. $16.48 $10.21 - + Add to cart
9	NUT, SPEC'L, SHAPE Part #: 90179-25615-00 Required per assembly: 1 $29.98 $20.91 - + Add to cart
10	NUT Part #: 90179-25003-00 Required per assembly: 1 $20.98 $16.50 - + Add to cart
11	WASHER, PLATE Part #: 90202-26142-00 Required per assembly: 1 $10.49 $7.92 - + Add to cart
12	WASHER, SPECIAL Part #: 3YF-23418-00-00 Required per assembly: 1 $19.98 $16.33 - + Add to cart
13	DAMPER Part #: 3C5-23426-00-00 Required per assembly: 2 $2.25 $1.87 - + Add to cart
14	CROWN, HANDLE Part #: 3C5-23435-00-00 Required per assembly: 1 $236.99 $203.56 - + Add to cart
15	NUT Part #: 90179-22007-00 Required per assembly: 1 $11.49 $9.19 - + Add to cart
16	CAP Part #: 5HP-2319U-00-00 Required per assembly: 1 $16.48 $11.63 - + Add to cart
17	BOLT, FLANGE, (4KG) Part #: 95024-08040-00 Required per assembly: 4 $9.49 $6.05 - + Add to cart
18	HOLDER, HANDLE, UPPER, S8, FOR, PWS1 Part #: 1E6-23441-10-P2 Required per assembly: 2 $31.98 $22.45 - + Add to cart
19	BOLT, FLANGE Part #: 95817-08035-00 Required per assembly: 4 $10.49 $6.55 - + Add to cart
20	STAY 1 Part #: 3C5-2317E-01-00 Required per assembly: 1 $20.98 $16.95 - + Add to cart
21	HOLDER STOPPER 1 Part #: 3C5-23348-10-00 Required per assembly: 1 $106.98 $96.54 - + Add to cart
22	COLLAR Part #: 90387-06161-00 Required per assembly: 2 $9.49 $6.12 - + Add to cart
23	GROMMET Part #: 90480-14011-00 Required per assembly: 2 $6.49 $5.13 - + Add to cart
24	BOLT, FLANGE Part #: 95022-06040-00 Required per assembly: 2 $3.70 $3.08 - + Add to cart
