Front Fork replacement parts for 2016 Yamaha XV250

OEM Parts Yamaha 2016 Yamaha XV250 Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (L.H) Part #: 2UJ-23102-30-00 Required per assembly: 1 $716.99 $653.92 - + Add to cart
2	TUBE, OUTER, (LEFT) Part #: 2UJ-23126-30-00 Required per assembly: 1 $244.99 $228.77 - + Add to cart
3	METAL, SLIDE, 1 Part #: 51Y-23125-00-00 Required per assembly: 1 $32.99 $23.72 - + Add to cart
4	SEAL, DUST Part #: 2UJ-23144-00-00 Required per assembly: 1 $32.99 $24.68 - + Add to cart
5	OIL SEAL Part #: 2UJ-23145-00-00 Required per assembly: 1 $24.98 $17.78 - + Add to cart
6	RING, SNAP Part #: 22W-23153-L0-00 Required per assembly: 1 $9.49 $7.98 - + Add to cart
7	INNER TUBE COMP 1 Part #: 2UJ-23110-00-00 Required per assembly: 1 $171.99 $153.82 - + Add to cart
8	CYLINDER, COMP, FRONT, FORK Part #: 2UJ-23170-00-00 Required per assembly: 1 $76.98 $69.05 - + Add to cart
9	SPRING, REBOUND Part #: 509-23151-L0-00 Required per assembly: 1 Not Available
10	SPINDLE, TAPER Part #: 39K-23173-00-00 Required per assembly: 1 Not Available
11	SPRING, FRONT, FORK Part #: 2UJ-23141-00-00 Required per assembly: 1 $32.99 $28.77 - + Add to cart
12	GASKET Part #: 509-23158-L0-00 Required per assembly: 1 $17.98 $14.09 - + Add to cart
13	O-RING Part #: 3J2-23114-00-00 Required per assembly: 1 $9.49 $8.06 - + Add to cart
14	BOLT, CAP Part #: 2JN-23111-00-00 Required per assembly: 1 $44.99 $39.39 - + Add to cart
15	BOLT, HEXAGON, SOCKET, HEAD Part #: 3D8-23181-00-00 Required per assembly: 1 $9.49 $7.50 - + Add to cart
16	WASHER, SPRING, UPPER Part #: 3DM-23149-10-00 Required per assembly: 1 $6.49 $5.03 - + Add to cart
17	SPACER Part #: 58T-23118-L0-00 Required per assembly: 1 Not Available
18	FRONT FORK ASSEMBLY (R.H) Part #: 2UJ-23103-30-00 Required per assembly: 1 $421.99 $419.24 - + Add to cart
19	TUBE, OUTER, (RIGHT) Part #: 2UJ-23136-30-00 Required per assembly: 1 $190.99 $178.84 - + Add to cart
20	METAL, SLIDE, 1 Part #: 51Y-23125-00-00 Required per assembly: 1 $32.99 $23.72 - + Add to cart
21	SEAL, DUST Part #: 2UJ-23144-00-00 Required per assembly: 1 $32.99 $24.68 - + Add to cart
22	OIL SEAL Part #: 2UJ-23145-00-00 Required per assembly: 1 $24.98 $17.78 - + Add to cart
23	RING, SNAP Part #: 22W-23153-L0-00 Required per assembly: 1 $9.49 $7.98 - + Add to cart
24	INNER TUBE COMP 1 Part #: 2UJ-23110-00-00 Required per assembly: 1 $171.99 $153.82 - + Add to cart
25	CYLINDER, COMP, FRONT, FORK Part #: 2UJ-23170-00-00 Required per assembly: 1 $76.98 $69.05 - + Add to cart
26	SPRING, REBOUND Part #: 509-23151-L0-00 Required per assembly: 1 Not Available
27	SPINDLE, TAPER Part #: 39K-23173-00-00 Required per assembly: 1 Not Available
28	SPRING, FRONT, FORK Part #: 2UJ-23141-00-00 Required per assembly: 1 $32.99 $28.77 - + Add to cart
29	GASKET Part #: 509-23158-L0-00 Required per assembly: 1 $17.98 $14.09 - + Add to cart
30	O-RING Part #: 3J2-23114-00-00 Required per assembly: 1 $9.49 $8.06 - + Add to cart
31	BOLT, CAP Part #: 2JN-23111-00-00 Required per assembly: 1 $44.99 $39.39 - + Add to cart
32	BOLT, HEXAGON, SOCKET, HEAD Part #: 3D8-23181-00-00 Required per assembly: 1 $9.49 $7.50 - + Add to cart
33	WASHER, SPRING, UPPER Part #: 3DM-23149-10-00 Required per assembly: 1 $6.49 $5.03 - + Add to cart
34	SPACER Part #: 58T-23118-L0-00 Required per assembly: 1 Not Available
35	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08035-00 Required per assembly: 1 $2.70 $2.51 - + Add to cart
36	UNDER BRACKET COMP. Part #: 2UJ-23340-40-00 Required per assembly: 1 $216.99 $214.64 - + Add to cart
37	SEAL, DUST Part #: 5VC-23462-00-00 Required per assembly: 1 $8.99 $7.38 - + Add to cart
38	BOLT 1 Part #: 2UJ-23346-10-00 Required per assembly: 2 $4.50 $3.73 - + Add to cart
39	HOLDER, BRAKE, HOSE Part #: 3DM-25886-10-00 Required per assembly: 1 $17.48 $14.21 - + Add to cart
40	STOPPER, 1 Part #: 2UJ-26114-00-00 Required per assembly: 1 Not Available
41	BOLT, FLANGE Part #: 95817-06010-00 Required per assembly: 1 $5.49 $3.84 - + Add to cart
