Frame replacement parts for 2016 Yamaha Stryker Bullet Cowl

OEM Parts Yamaha 2016 Yamaha Stryker Bullet Cowl Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRAME COMP. Part #: 27D-21110-00-00 Required per assembly: 1 $2,684.61 - + Add to cart
2	BRACKET, 10 Part #: 27D-2119M-00-00 Required per assembly: 1 ~~$28.98~~ $25.22 - + Add to cart
3	BOLT, BUTTON, HEAD Part #: 92017-06014-00 Required per assembly: 2 ~~$4.59~~ $3.92 - + Add to cart
4	STAY, ENGINE, 7 Part #: 27D-21387-00-00 Required per assembly: 1 ~~$34.99~~ $29.94 - + Add to cart
5	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-10047-00 Required per assembly: 2 $5.35 - + Add to cart
6	STAY, ENGINE, 3 Part #: 27D-21317-00-00 Required per assembly: 1 ~~$120.98~~ $109.68 - + Add to cart
7	BOLT, FLANGE Part #: 90105-12083-00 Required per assembly: 1 $11.60 - + Add to cart
8	NUT, CROWN Part #: 90176-12003-00 Required per assembly: 1 $11.76 - + Add to cart
9	BOLT, HEX., SOCKET, BUTTON Part #: 90111-10052-00 Required per assembly: 2 $6.71 - + Add to cart
10	NUT, SELF-LOCKING Part #: 90185-10011-00 Required per assembly: 2 $5.77 - + Add to cart
11	CAP Part #: 5YU-2143A-00-00 Required per assembly: 1 Not Available
12	BRACKET 11 Part #: 27D-2114V-00-00 Required per assembly: 1 ~~$22.98~~ $21.48 - + Add to cart
13	BRKT. Part #: 27D-2116B-00-00 Required per assembly: 1 $17.79 - + Add to cart
14	STAY, ENGINE, 5 Part #: 27D-21318-00-00 Required per assembly: 1 ~~$31.98~~ $27.91 - + Add to cart
15	STAY, ENGINE, 5 Part #: 27D-21314-00-00 Required per assembly: 1 $16.59 - + Add to cart
16	BOLT, FLANGE Part #: 90105-10391-00 Required per assembly: 2 $12.82 - + Add to cart
17	NUT, SELF-LOCKING Part #: 95602-10200-00 Required per assembly: 2 $3.25 - + Add to cart
18	BOLT, FLANGE Part #: 90105-12080-00 Required per assembly: 1 $12.68 - + Add to cart
19	NUT, SELF-LOCKING Part #: 90185-12002-00 Required per assembly: 1 ~~$13.49~~ $12.89 - + Add to cart
20	STAY, ENGINE, 3 Part #: 3D8-21316-00-00 Required per assembly: 1 ~~$21.98~~ $20.61 - + Add to cart
21	BOLT, FLANGE Part #: 95817-10020-00 Required per assembly: 2 ~~$8.49~~ $5.15 - + Add to cart
22	BOLT, FLANGE Part #: 90105-12044-00 Required per assembly: 1 ~~$23.98~~ $21.56 - + Add to cart
23	NUT, SELF-LOCKING Part #: 90185-12002-00 Required per assembly: 1 ~~$13.49~~ $12.89 - + Add to cart
24	BOLT, FLANGE Part #: 90105-12045-00 Required per assembly: 1 ~~$22.98~~ $20.83 - + Add to cart
25	NUT, SELF-LOCKING Part #: 90185-12002-00 Required per assembly: 1 ~~$13.49~~ $12.89 - + Add to cart
26	BRACKET, COIL Part #: 27D-21359-00-00 Required per assembly: 1 ~~$18.48~~ $18.45 - + Add to cart
27	BOLT, FLANGE Part #: 95022-06012-00 Required per assembly: 1 $4.21 - + Add to cart
28	BRACKET, FRONT, UPPER, 1 Part #: 27D-21415-00-00 Required per assembly: 1 ~~$35.99~~ $31.04 - + Add to cart
29	BOLT, FLANGE Part #: 95022-06012-00 Required per assembly: 2 $4.21 - + Add to cart
30	CLAMP Part #: 90464-11007-00 Required per assembly: 1 $4.92 - + Add to cart
31	COVER, SIDE, 5 Part #: 27D-2171E-00-00 Required per assembly: 1 $17.57 - + Add to cart
32	COVER, SIDE, 6 Part #: 27D-2171X-00-00 Required per assembly: 1 $30.57 - + Add to cart
33	BOLT, FLANGE(4MY) Part #: 95027-06012-00 Required per assembly: 1 $4.57 - + Add to cart
34	STAY, SIDE, COVER, 2 Part #: 27D-21322-00-00 Required per assembly: 1 $15.02 - + Add to cart
35	GROMMET Part #: 90480-01022-00 Required per assembly: 2 $3.98 - + Add to cart
36	SPACER Part #: 90560-06244-00 Required per assembly: 2 ~~$9.49~~ $8.93 - + Add to cart
37	RIVET Part #: 90269-07007-00 Required per assembly: 1 $4.69 - + Add to cart
38	SCREW, SPEC'L, SHAPE Part #: 90149-06298-00 Required per assembly: 2 ~~$6.49~~ $5.89 - + Add to cart
39	RIVET Part #: 90269-05079-00 Required per assembly: 4 $2.54 - + Add to cart
40	PROTECTOR Part #: 3D8-2117G-00-00 Required per assembly: 1 Not Available
41	DAMPER Part #: 5H0-8235Y-M0-00 Required per assembly: 1 Note: Sold in multiples of 5 only $8.69 - + Add to cart
42	PROTECTOR Part #: 3MA-27491-00-00 Required per assembly: 2 $10.56 - + Add to cart
43	PLUG Part #: 90338-27007-00 Required per assembly: 2 ~~$6.49~~ $6.17 - + Add to cart
