Front Fork replacement parts for 2016 Yamaha Bolt C Spec

OEM Parts Yamaha 2016 Yamaha Bolt C Spec Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (L Part #: B33-23102-00-00 Required per assembly: 1 $542.29 $501.99 - + Add to cart
2	TUBE, OUTER, (L.H) Part #: B33-23126-00-00 Required per assembly: 1 $314.99 $307.31 - + Add to cart
3	INNER TUBE COMP.1 Part #: B33-23110-00-00 Required per assembly: 1 $294.99 $289.49 - + Add to cart
4	METAL, SLIDE Part #: 4FM-23171-40-00 Required per assembly: 1 $25.98 $20.02 - + Add to cart
5	CYLINDER, COMP., FR Part #: B33-23170-00-00 Required per assembly: 1 $59.99 $51.92 - + Add to cart
6	METAL, SLIDE, 1 Part #: 4FM-23125-40-00 Required per assembly: 1 $36.99 $28.76 - + Add to cart
7	WASHER, OIL, SEAL Part #: 36Y-23146-10-00 Required per assembly: 1 $30.98 $21.68 - + Add to cart
8	OIL SEAL Part #: 4EB-23145-01-00 Required per assembly: 1 $31.98 $23.83 - + Add to cart
9	RING, SNAP Part #: 26H-23156-00-00 Required per assembly: 1 $8.49 $6.49 - + Add to cart
10	SEAL, DUST Part #: 4EB-23144-00-00 Required per assembly: 1 $24.98 $19.14 - + Add to cart
11	SPINDLE, TAPER Part #: 4YR-23173-00-00 Required per assembly: 1 $43.99 $32.42 - + Add to cart
12	GASKET Part #: 509-23158-L0-00 Required per assembly: 1 $17.98 $14.09 - + Add to cart
13	BOLT, HEXAGON, SOCKET, HEAD Part #: 3D8-23181-00-00 Required per assembly: 1 $9.49 $7.50 - + Add to cart
14	SPRING, FRONT, FORK Part #: B33-23141-00-00 Required per assembly: 1 $36.99 $32.18 - + Add to cart
15	WASHER, SPRING, UPPER Part #: 4DW-23149-40-00 Required per assembly: 1 $7.49 $6.31 - + Add to cart
16	SPACER Part #: 22B-23118-20-00 Required per assembly: 1 $18.48 $15.06 - + Add to cart
17	BOLT, CAP Part #: 1D0-23111-00-00 Required per assembly: 1 $51.99 $44.27 - + Add to cart
18	O-RING Part #: 1TP-23188-01-00 Required per assembly: 1 $5.99 $4.69 - + Add to cart
19	BOOT Part #: B33-23191-00-00 Required per assembly: 1 $62.99 $51.18 - + Add to cart
20	BAND Part #: 43M-23192-L0-00 Required per assembly: 1 $22.98 $18.30 - + Add to cart
21	SCREW, PAN, HEAD Part #: 98517-04016-00 Required per assembly: 1 $9.49 $6.06 - + Add to cart
22	FRONT FORK ASSEMBLY (R Part #: B33-23103-00-00 Required per assembly: 1 $542.29 $501.99 - + Add to cart
23	TUBE, OUTER Part #: B33-23136-00-00 Required per assembly: 1 $312.99 $307.56 - + Add to cart
24	INNER TUBE COMP.1 Part #: B33-23110-00-00 Required per assembly: 1 $294.99 $289.49 - + Add to cart
25	METAL, SLIDE Part #: 4FM-23171-40-00 Required per assembly: 1 $25.98 $20.02 - + Add to cart
26	CYLINDER, COMP., FR Part #: B33-23170-00-00 Required per assembly: 1 $59.99 $51.92 - + Add to cart
27	METAL, SLIDE, 1 Part #: 4FM-23125-40-00 Required per assembly: 1 $36.99 $28.76 - + Add to cart
28	WASHER, OIL, SEAL Part #: 36Y-23146-10-00 Required per assembly: 1 $30.98 $21.68 - + Add to cart
29	OIL SEAL Part #: 4EB-23145-01-00 Required per assembly: 1 $31.98 $23.83 - + Add to cart
30	RING, SNAP Part #: 26H-23156-00-00 Required per assembly: 1 $8.49 $6.49 - + Add to cart
31	SEAL, DUST Part #: 4EB-23144-00-00 Required per assembly: 1 $24.98 $19.14 - + Add to cart
32	SPINDLE, TAPER Part #: 4YR-23173-00-00 Required per assembly: 1 $43.99 $32.42 - + Add to cart
33	GASKET Part #: 509-23158-L0-00 Required per assembly: 1 $17.98 $14.09 - + Add to cart
34	BOLT, HEXAGON, SOCKET, HEAD Part #: 3D8-23181-00-00 Required per assembly: 1 $9.49 $7.50 - + Add to cart
35	SPRING, FRONT, FORK Part #: B33-23141-00-00 Required per assembly: 1 $36.99 $32.18 - + Add to cart
36	WASHER, SPRING, UPPER Part #: 4DW-23149-40-00 Required per assembly: 1 $7.49 $6.31 - + Add to cart
37	SPACER Part #: 22B-23118-20-00 Required per assembly: 1 $18.48 $15.06 - + Add to cart
38	BOLT, CAP Part #: 1D0-23111-00-00 Required per assembly: 1 $51.99 $44.27 - + Add to cart
39	O-RING Part #: 1TP-23188-01-00 Required per assembly: 1 $5.99 $4.69 - + Add to cart
40	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08035-00 Required per assembly: 2 $2.70 $2.51 - + Add to cart
41	BOOT Part #: B33-23191-00-00 Required per assembly: 1 $62.99 $51.18 - + Add to cart
42	BAND Part #: 43M-23192-L0-00 Required per assembly: 1 $22.98 $18.30 - + Add to cart
43	SCREW, PAN, HEAD Part #: 98517-04016-00 Required per assembly: 1 $9.49 $6.06 - + Add to cart
44	UNDER BRACKET COMP. Part #: 1TP-23340-01-00 Required per assembly: 1 $431.99 $431.51 - + Add to cart
45	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-10020-00 Required per assembly: 4 $9.49 $6.55 - + Add to cart
46	SEAL, STEERING Part #: 3FV-23462-00-00 Required per assembly: 1 $26.98 $21.26 - + Add to cart
47	BEARING, SPECIAL Part #: 93399-99932-00 Required per assembly: 1 $69.98 $55.57 - + Add to cart
48	FORK SEALS KIT Part #: 4EB-W003B-00-00 Required per assembly: 1 $41.99 $37.74 - + Add to cart
