2016 Yamaha YDREX6PTV4 - Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

FRAME COMP.

Part #: JD4-F2501-21-00 Required per assembly: 1
Not Available
2

FOOTREST 1

Part #: JW9-F7411-01-00 Required per assembly: 1
$810.24
-
+
Add to cart
3

FOOTREST 1

Part #: JD4-F7411-50-00 Required per assembly: 1
Not Available
4

BOLT

Part #: JD1-K7481-00-00 Required per assembly: 10
$1.80
$1.29
-
+
Add to cart
5

NUT

Part #: JD1-K7528-00-00 Required per assembly: 10
$1.05
$0.60
-
+
Add to cart
6

WASHER 1

Part #: JD1-K7525-00-00 Required per assembly: 20
$0.30
$0.23
-
+
Add to cart
7

BRACKET, FOOTREST, 1

Part #: JD3-F7452-00-00 Required per assembly: 1
Not Available
8

BRACKET, FOOTREST, 2

Part #: JD3-F7462-00-00 Required per assembly: 1
$18.48
$14.35
-
+
Add to cart
9

BOLT

Part #: JW1-F1738-00-00 Required per assembly: 12
$2.14
$1.66
-
+
Add to cart
10

BOLT

Part #: JW1-F1738-00-00 Required per assembly: 4
$2.14
$1.66
-
+
Add to cart
11

BRACKET, 3

Part #: JC1-F252M-00-00 Required per assembly: 1
$45.99
$37.77
-
+
Add to cart
12

MEMBER, CROSS

Part #: JW9-F2198-10-00 Required per assembly: 2
$51.28
-
+
Add to cart
13

BOLT

Part #: JW1-F1738-00-00 Required per assembly: 4
$2.14
$1.66
-
+
Add to cart
14

BRACKET, DASH, UPPER

Part #: JW1-F258G-02-00 Required per assembly: 1
$110.46
-
+
Add to cart
15

BOLT, FLANGE

Part #: 90105-06831-00 Required per assembly: 6
$2.29
$1.72
-
+
Add to cart
16

STAY, BATTERY, 1

Part #: JW9-F2535-00-00 Required per assembly: 2
$23.98
$23.37
-
+
Add to cart
17

BOLT

Part #: JW1-F1738-00-00 Required per assembly: 4
$2.14
$1.66
-
+
Add to cart
18

PLUG

Part #: JW9-F2417-00-00 Required per assembly: 2
$2.99
$2.12
-
+
Add to cart
