Front Suspension Wheel replacement parts for 2016 Yamaha YXZ1000 EPS Special

OEM Parts Yamaha 2016 Yamaha YXZ1000 EPS Special Front Suspension Wheel

FRONT SUSPENSION WHEEL Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT UPPER ARM SU Part #: 2HC-F3505-10-00 Required per assembly: 1 ~~$186.99~~ $171.12 - + Add to cart
2	BALL JOINT 2 Part #: 2HC-23579-00-00 Required per assembly: 1 ~~$104.98~~ $90.87 - + Add to cart
3	CIRCLIP Part #: 93410-42096-00 Required per assembly: 1 ~~$2.75~~ $2.30 - + Add to cart
4	FRONT UPPER ARM SU Part #: 2HC-F3506-10-00 Required per assembly: 1 ~~$214.99~~ $194.15 - + Add to cart
5	BALL JOINT 2 Part #: 2HC-23579-00-00 Required per assembly: 1 ~~$104.98~~ $90.87 - + Add to cart
6	CIRCLIP Part #: 93410-42096-00 Required per assembly: 1 ~~$2.75~~ $2.30 - + Add to cart
7	FRONT LOWER ARM SU Part #: 2HC-F3507-10-00 Required per assembly: 1 ~~$118.98~~ $104.17 - + Add to cart
8	FRONT LOWER ARM SU Part #: 2HC-F3508-10-00 Required per assembly: 1 ~~$118.98~~ $103.16 - + Add to cart
9	BUSH, SOLID Part #: 90381-18003-00 Required per assembly: 16 ~~$7.99~~ $5.88 - + Add to cart
10	COLLAR Part #: 90387-12063-00 Required per assembly: 8 ~~$15.49~~ $12.08 - + Add to cart
11	COVER, THRUST, 1 Part #: 1XD-23517-00-00 Required per assembly: 16 ~~$11.49~~ $9.18 - + Add to cart
12	BOLT Part #: 90101-12050-00 Required per assembly: 8 ~~$12.49~~ $9.77 - + Add to cart
13	WASHER, PLATE Part #: 90201-12045-00 Required per assembly: 16 ~~$6.49~~ $5.50 - + Add to cart
14	NUT, SELF-LOCKING Part #: 90185-12007-00 Required per assembly: 8 ~~$11.49~~ $8.77 - + Add to cart
15	NIPPLE, GREASE(6A1) Part #: 93700-06M03-00 Required per assembly: 4 ~~$8.49~~ $8.30 - + Add to cart
16	NIPPLE, GREASE Part #: 93700-06009-00 Required per assembly: 4 ~~$12.49~~ $9.75 - + Add to cart
17	NUT, CASTLE Part #: 90171-14005-00 Required per assembly: 2 ~~$13.49~~ $10.57 - + Add to cart
18	PIN, COTTER Part #: 91490-30030-00 Required per assembly: 2 Note: Sold in multiples of 5 only ~~$8.49~~ $7.24 - + Add to cart
19	NUT, CASTLE Part #: 90171-14005-00 Required per assembly: 2 ~~$13.49~~ $10.57 - + Add to cart
20	PIN, COTTER Part #: 91490-30030-00 Required per assembly: 2 Note: Sold in multiples of 5 only ~~$8.49~~ $7.24 - + Add to cart
21	SHOCK ABSORBER ASSEMBLY Part #: 2HC-F3390-00-00 Required per assembly: 2 ~~$890.89~~ $830.90 - + Add to cart
22	LABEL, WARNING Part #: 1HP-F2259-01-00 Required per assembly: 1 ~~$23.98~~ $15.86 - + Add to cart
23	NUT, SELF-LOCKING Part #: 90185-10012-00 Required per assembly: 4 ~~$3.60~~ $2.93 - + Add to cart
24	BOLT, FLANGE Part #: 90105-10283-00 Required per assembly: 4 ~~$6.49~~ $4.75 - + Add to cart
25	COVER, UNDER, 1 Part #: 2HC-F3123-01-00 Required per assembly: 1 ~~$10.49~~ $7.68 - + Add to cart
26	COVER, UNDER, 2 Part #: 2HC-F3133-01-00 Required per assembly: 1 ~~$10.49~~ $7.68 - + Add to cart
27	BOLT, WITH, WASHER Part #: 90119-06212-00 Required per assembly: 4 ~~$9.49~~ $6.11 - + Add to cart
28	COVER 1 Part #: 2HC-F198F-00-00 Required per assembly: 2 ~~$4.45~~ $3.84 - + Add to cart
29	BAR, STABILIZER, FRONT Part #: 8GN-2386E-00-00 Required per assembly: 1 Note: AP (14MM) ~~$299.99~~ $268.95 - + Add to cart
30	JOINT, STABILIZER, 1 Part #: 16B-2385L-10-00 Required per assembly: 1 ~~$78.98~~ $62.64 - + Add to cart
31	JOINT, STABILIZER, 2 Part #: 16B-2385M-10-00 Required per assembly: 1 ~~$78.98~~ $63.59 - + Add to cart
32	WASHER, PLATE Part #: 90201-10035-00 Required per assembly: 4 ~~$4.50~~ $3.76 - + Add to cart
33	NUT, SELF-LOCKING Part #: 90185-10012-00 Required per assembly: 4 ~~$3.60~~ $2.93 - + Add to cart
34	BUSH Part #: 2HC-F3583-00-00 Required per assembly: 2 ~~$4.54~~ $3.73 - + Add to cart
35	BRKT., STABILIZER, FR. Part #: 2HC-F386B-00-00 Required per assembly: 2 ~~$4.00~~ $3.43 - + Add to cart
36	BOLT, FLANGE Part #: 95817-08014-00 Required per assembly: 4 ~~$2.50~~ $1.91 - + Add to cart
