Fender replacement parts for 2016 Yamaha YZFR6

OEM Parts Yamaha 2016 Yamaha YZFR6 Fender

FENDER Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FENDER, FRONT Part #: 2C0-21511-01-P0 Required per assembly: 1 $145.99 $139.40 - + Add to cart
2	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-06043-00 Required per assembly: 2 $5.49 $3.27 - + Add to cart
3	GROMMET Part #: 90480-14003-00 Required per assembly: 4 $9.49 $6.12 - + Add to cart
4	COLLAR Part #: 90387-06057-00 Required per assembly: 4 $9.49 $6.05 - + Add to cart
5	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-06030-00 Required per assembly: 2 $4.75 $3.18 - + Add to cart
6	NUT, FLANGE, (7NB) Part #: 95780-06500-00 Required per assembly: 2 $2.95 $1.87 - + Add to cart
7	EMBLEM, YAMAHA, (BLACK, METALLIC, X) Part #: 99244-00080-00 Required per assembly: 1 Note: PWS1(PURPLISH WHITE SOLID 1) $17.48 $13.43 - + Add to cart
8	BOX, BATTERY, 1 Part #: 13S-8212B-00-00 Required per assembly: 1 Not Available
9	DAMPER 2 Part #: 51Y-21639-00-00 Required per assembly: 1 $6.99 $5.32 - + Add to cart
10	DAMPER Part #: 13S-21649-00-00 Required per assembly: 8 $7.49 $6.27 - + Add to cart
11	BAND, BATTERY Part #: 133-82131-00-00 Required per assembly: 1 $30.98 $21.41 - + Add to cart
12	NUT, SPRING Part #: 90183-04039-00 Required per assembly: 2 $8.49 $5.79 - + Add to cart
13	PLUG, SPEC'L, SHAPE Part #: 90338-07180-00 Required per assembly: 3 $8.49 $5.58 - + Add to cart
14	CLAMP Part #: 90464-13185-00 Required per assembly: 2 $6.49 $3.64 - + Add to cart
15	BOLT Part #: 90109-06171-00 Required per assembly: 2 $9.49 $6.15 - + Add to cart
16	RIVET Part #: 90269-07010-00 Required per assembly: 3 $4.70 $3.67 - + Add to cart
17	PROTECTOR Part #: 13S-21652-00-00 Required per assembly: 1 $44.99 $39.39 - + Add to cart
18	DAMPER PLATE ASSEMBLY Part #: 13S-24140-00-00 Required per assembly: 1 $24.98 $20.70 - + Add to cart
19	BAND, TOOL Part #: 13S-21376-00-00 Required per assembly: 1 $8.49 $6.82 - + Add to cart
20	FENDER, REAR Part #: 13S-21611-00-P0 Required per assembly: 1 Note: FOR DPBMC(DEEP PURPLISH BLUE METALLIC C) $174.99 $163.20 - + Add to cart
21	SEAT Part #: 13S-2172P-00-00 Required per assembly: 1 $15.49 $10.93 - + Add to cart
22	SEAT Part #: 13S-2173P-00-00 Required per assembly: 1 $15.49 $10.96 - + Add to cart
23	SEAL 2 Part #: 13S-21735-00-00 Required per assembly: 2 $8.49 $7.18 - + Add to cart
24	DAMPER, PLATE Part #: 90520-02014-00 Required per assembly: 2 $1.60 $0.98 - + Add to cart
25	SEAL Part #: 13S-21669-00-00 Required per assembly: 1 $9.49 $7.91 - + Add to cart
26	SEAL, 2 Part #: 13S-216A2-00-00 Required per assembly: 1 $9.49 $7.88 - + Add to cart
27	SEAL, 3 Part #: 13S-216A3-00-00 Required per assembly: 1 $11.99 $8.00 - + Add to cart
28	SEAL, 4 Part #: 13S-216A4-00-00 Required per assembly: 1 $11.99 $8.07 - + Add to cart
29	FENDER 2 Part #: 13S-2162R-00-P2 Required per assembly: 1 Note: FOR DPBMC(DEEP PURPLISH BLUE METALLIC C) $184.99 $179.03 - + Add to cart
30	RIVET Part #: 90269-06001-00 Required per assembly: 2 $6.49 $5.32 - + Add to cart
31	PLUG, SPEC'L, SHAPE Part #: 90338-07180-00 Required per assembly: 2 $8.49 $5.58 - + Add to cart
32	PLATE 1 Part #: 5GM-27445-00-00 Required per assembly: 1 $7.49 $6.35 - + Add to cart
33	GROMMET Part #: 90480-08005-00 Required per assembly: 4 $9.49 $6.17 - + Add to cart
34	SEAL 1 Part #: 13S-21732-00-00 Required per assembly: 2 $18.98 $15.47 - + Add to cart
35	SEAL 1 Part #: 13S-21575-00-00 Required per assembly: 2 $8.49 $6.67 - + Add to cart
36	SEAL 4 Part #: 13S-2173N-00-00 Required per assembly: 2 $10.99 $8.23 - + Add to cart
37	RIVET Part #: 90269-07010-00 Required per assembly: 2 $4.70 $3.67 - + Add to cart
38	CLAMP (4FM) Part #: 90464-15195-00 Required per assembly: 1 $4.41 $2.72 - + Add to cart
39	SCREW, TRUSS, HEAD, TAPPING Part #: 97707-50014-00 Required per assembly: 4 $9.49 $6.06 - + Add to cart
40	BRACKET Part #: 13S-21131-00-00 Required per assembly: 1 $93.98 $79.86 - + Add to cart
41	NUT Part #: 90179-06010-00 Required per assembly: 2 $6.49 $4.19 - + Add to cart
42	PLUG Part #: 90338-07018-00 Required per assembly: 2 $8.49 $5.70 - + Add to cart
43	DAMPER Part #: 5YT-24665-00-00 Required per assembly: 1 $8.49 $6.27 - + Add to cart
44	BOLT, BUTTON, HEAD Part #: 92012-06016-00 Required per assembly: 4 $9.49 $6.11 - + Add to cart
45	WASHER, SPECIAL, 1 Part #: 13S-21615-00-00 Required per assembly: 4 $17.98 $12.82 - + Add to cart
46	BOLT, HEXAGON Part #: 97017-06025-00 Required per assembly: 4 $4.54 $2.93 - + Add to cart
47	TOOL KIT Part #: 2C0-28100-00-00 Required per assembly: 1 $59.99 $52.32 - + Add to cart
48	HELMET HANGER ASSEMBLY Part #: 2C0-21370-00-00 Required per assembly: 1 $34.99 $30.18 - + Add to cart
49	TOOL, KIT, 2 Part #: 2C0-28110-00-00 Required per assembly: 1 $67.98 $56.10 - + Add to cart
50	BOX, SPARK, PLUG Part #: 4XV-2814F-00-00 Required per assembly: 1 $41.99 $32.69 - + Add to cart
51	SPANNER, SPECIAL Part #: 4FM-28135-00-00 Required per assembly: 1 $17.48 $14.44 - + Add to cart
52	CLAMP Part #: 90465-13M11-00 Required per assembly: 1 $8.49 $5.62 - + Add to cart
53	GUARD, MUD Part #: 2C0-21629-11-00 Required per assembly: 1 $37.99 $30.18 - + Add to cart
54	REAR REFLECTOR ASSEMBLY Part #: 3Y6-85130-02-00 Required per assembly: 1 $30.98 $22.33 - + Add to cart
55	NUT, S/L, FLANGE Part #: 95607-05200-00 Required per assembly: 1 $10.49 $6.73 - + Add to cart
56	REAR STAY COMP. Part #: 13S-21640-00-00 Required per assembly: 1 $176.99 $157.34 - + Add to cart
57	COVER, REAR, FENDER, 1 Part #: 2C0-2163A-00-00 Required per assembly: 1 $12.49 $10.19 - + Add to cart
58	COVER, REAR, FENDER, 2 Part #: 2C0-2163E-00-00 Required per assembly: 1 $12.49 $10.19 - + Add to cart
59	CLAMP Part #: 90464-14228-00 Required per assembly: 1 $5.49 $4.22 - + Add to cart
60	BOLT Part #: 90109-06182-00 Required per assembly: 4 $13.49 $10.95 - + Add to cart
61	REAR REFLECTOR ASSEMBLY Part #: 3Y6-85130-02-00 Required per assembly: 2 $30.98 $22.33 - + Add to cart
62	NUT, WITH, WASHER Part #: 95702-05500-00 Required per assembly: 2 $0.28 $0.25 - + Add to cart
63	BRACKET, REAR, STAY Part #: 2C0-21688-00-00 Required per assembly: 1 $14.49 $10.25 - + Add to cart
64	BRACKET, REAR, STAY, 2 Part #: 2C0-21689-00-00 Required per assembly: 1 $11.99 $10.01 - + Add to cart
65	SCREW, WITH, WASHER Part #: 90159-06011-00 Required per assembly: 2 $9.49 $6.09 - + Add to cart
66	NUT, SELF-LOCKING Part #: 95617-06100-00 Required per assembly: 2 $2.89 $2.28 - + Add to cart
67	BRACKET, LICENSE Part #: 5MT-84751-00-00 Required per assembly: 1 $32.99 $23.39 - + Add to cart
68	WASHER, PLATE, 8221447500 Part #: 90201-06057-00 Required per assembly: 2 $6.49 $3.70 - + Add to cart
69	NUT, SELF-LOCKING Part #: 95617-06100-00 Required per assembly: 2 $2.89 $2.28 - + Add to cart
70	LABEL, CAUTION Part #: 3JJ-28446-A1-00 Required per assembly: 1 $8.49 $6.79 - + Add to cart
71	LABEL, CAUTION Part #: 3TB-24877-A0-00 Required per assembly: 1 $5.49 $4.51 - + Add to cart
	EMBLEM, YAMAHA Part #: 99241-00080-00 Required per assembly: 1 $15.49 $11.69 - + Add to cart
	FENDER, REAR, UR, FOR, MNM3 Part #: 13S-21611-00-P9 Required per assembly: 1 $206.99 $198.30 - + Add to cart
	FENDER 2 UR FOR MNM3 Part #: 13S-2162R-00-P7 Required per assembly: 1 $193.99 $173.71 - + Add to cart
	FENDER, FRONT Part #: 2C0-21511-01-PB Required per assembly: 1 $129.99 $128.23 - + Add to cart
