2017 Honda CMX500A Rebel 500 ABS - Speedometer

SPEEDOMETER Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
F 02
001

RUB, L., SIDE, COVER

Part #: 11356-KWN-700 Required per assembly: 2
$3.04
$2.83
-
+
Add to cart
002

METER ASSY. COMB

Part #: 37100-MKG-L54 Required per assembly: 1
$228.75
$182.42
-
+
Add to cart
003

METER, LCD, (MPH/KPH)

Part #: 37130-MKG-L51 Required per assembly: 1
$216.97
$173.03
-
+
Add to cart
004

STAY, METER

Part #: 37210-K87-A00 Required per assembly: 1
$21.90
$20.62
-
+
Add to cart
005

COLLAR, METER, STAY

Part #: 37211-K87-A00 Required per assembly: 2
$2.84
$2.64
-
+
Add to cart
006

CASE ASSEMBLY (UPPER)

Part #: 37610-MKG-L52 Required per assembly: 1
$62.75
$50.04
-
+
Add to cart
007

CASE LOWER ASSEMBLY

Part #: 37620-MKG-A02 Required per assembly: 1
$24.33
$19.40
-
+
Add to cart
008

SCREW, PAN, (6X25)

Part #: 90135-K87-A00 Required per assembly: 2
$1.79
$1.65
-
+
Add to cart
009

HOLDER (26MM)

Part #: 90617-RGH-003 Required per assembly: 1
$8.91
$7.71
-
+
Add to cart
010

SCREW, TAP, (3X16)

Part #: 93903-224J0 Required per assembly: 4
$1.42
$1.30
-
+
Add to cart
011

SCREW, TAP, (5X16)

Part #: 93903-25380 Required per assembly: 3
$1.95
$1.80
-
+
Add to cart
