Gearshift Drum (2) replacement parts for 2017 Honda CRF1000D

OEM Parts Honda 2017 Honda CRF1000D Gearshift Drum (2)

GEARSHIFT DRUM (2) Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

E 1601
001	FORK, R., GEARSHIFT Part #: 24211-MJP-G80 Required per assembly: 1 $65.27 $54.42 - + Add to cart
002	FORK, L., GEARSHIFT Part #: 24212-MJP-G80 Required per assembly: 1 $65.27 $52.84 - + Add to cart
003	FORK Part #: 24213-HL4-000 Required per assembly: 2 $69.20 $56.01 - + Add to cart
004	DRUM, GEARSHIFT Part #: 24310-MJP-G80 Required per assembly: 1 $160.96 $128.37 - + Add to cart
005	CENTER, SHIFT, DRUM Part #: 24312-MJP-G80 Required per assembly: 1 $37.21 $29.67 - + Add to cart
006	PIN, SHIFTER Part #: 24315-HL4-000 Required per assembly: 1 $9.91 $8.78 - + Add to cart
007	SHIFTER, DRUM Part #: 24321-KT8-030 Required per assembly: 1 $60.12 $48.68 - + Add to cart
008	COLLAR, SHIFTER Part #: 24322-MM4-000 Required per assembly: 1 $6.15 $5.47 - + Add to cart
009	PAWL, A, RATCHET Part #: 24324-KA3-711 Required per assembly: 1 $15.32 $12.77 - + Add to cart
010	SHAFT Part #: 24325-HL4-000 Required per assembly: 2 $20.71 $17.27 - + Add to cart
011	PAWL, B, RATCHET Part #: 24325-KA3-711 Required per assembly: 1 $15.32 $12.77 - + Add to cart
012	PLUNGER, PAWL Part #: 24326-KBH-901 Required per assembly: 2 $6.98 $6.16 - + Add to cart
013	PLATE, CHANGE, GUIDE Part #: 24328-MJP-G80 Required per assembly: 1 $10.52 $9.03 - + Add to cart
014	SPRING, PAWL, PLUNGER Part #: 24329-KA3-740 Required per assembly: 2 $3.60 - + Add to cart
015	COLLAR Part #: 24329-MGS-D20 Required per assembly: 1 $4.57 - + Add to cart
016	STOPPER Part #: 24430-HL4-000 Required per assembly: 1 $16.81 $14.02 - + Add to cart
017	WASHER Part #: 24433-MJP-G80 Required per assembly: 1 $3.70 $3.36 - + Add to cart
018	COLLAR Part #: 24434-MJP-G80 Required per assembly: 1 $11.88 $10.13 - + Add to cart
019	SPRING Part #: 24435-MJP-G80 Required per assembly: 1 $4.90 - + Add to cart
020	SPINDLE, GEARSHIFT Part #: 24610-MJP-G80 Required per assembly: 1 $83.99 $67.98 - + Add to cart
021	SPRING Part #: 24651-MGS-D20 Required per assembly: 1 $11.42 $9.74 - + Add to cart
022	PIN Part #: 24652-HA0-000 Required per assembly: 1 $9.87 $8.49 - + Add to cart
023	BOLT-WASHER (6X12) Part #: 90021-MM5-000 Required per assembly: 2 $6.15 $5.47 - + Add to cart
024	WASHER (14MM) Part #: 90451-155-000 Required per assembly: 1 $5.15 $4.68 - + Add to cart
025	BEARING (25X47X8) Part #: 91007-MGS-D21 Required per assembly: 1 $18.90 $15.76 - + Add to cart
026	BEARING (12X18X12) Part #: 91024-MGS-D21 Required per assembly: 1 $4.64 - + Add to cart
027	BEARING (14X20X12) Part #: 91028-MGS-D21 Required per assembly: 1 $5.89 $5.27 - + Add to cart
028	OIL SEAL (14X22X5) Part #: 91203-KK3-830 Required per assembly: 1 $5.18 $4.71 - + Add to cart
029	PIN, DOWEL, (8X14) Part #: 94301-08140 Required per assembly: 1 $3.21 $2.99 - + Add to cart
030	PIN, DOWEL, (8X20) Part #: 94301-08200 Required per assembly: 1 $3.21 $2.99 - + Add to cart
031	CIRCLIP (14MM) Part #: 94510-14000 Required per assembly: 1 $2.06 $1.90 - + Add to cart
032	BOLT, FLANGE, (6X35) Part #: 95701-06035-00 Required per assembly: 2 $2.87 $2.67 - + Add to cart
033	ROLLER (4X8) Part #: 96220-40080 Required per assembly: 1 $1.57 $1.45 - + Add to cart
