Speedometer (Navigation) replacement parts for 2017 Honda GL1800

OEM Parts Honda 2017 Honda GL1800 Speedometer (Navigation)

SPEEDOMETER (NAVIGATION) Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 0301
001	GROMMET, A/CLNR, HSG Part #: 17251-KE8-690 Required per assembly: 4 $3.29 - + Add to cart
002	WASHER, PIVOT Part #: 17936-921-000 Required per assembly: 1 $2.33 $2.16 - + Add to cart
003	METER, ASSEMBLY, COMBINATION, (MPH/KPH)(COO) Part #: 37100-MCA-307 Required per assembly: 1 Note: Area: 6YA 7AC $5,683.30 $4,615.42 - + Add to cart
003	METER, ASSEMBLY, COMBINATION, (MPH/KPH)(COO) Part #: 37100-MCA-306 Required per assembly: 1 Note: Area: 3YA 5AC $5,683.30 $4,615.42 - + Add to cart
004	CASE ASSEMBLY (LOWER) Part #: 37101-MCA-A81 Required per assembly: 1 $240.19 $194.42 - + Add to cart
005	PLATE, REFLECTING Part #: 37102-MCA-H31 Required per assembly: 1 $124.77 $100.99 - + Add to cart
006	LENS (COO) Part #: 37103-MCA-305 Required per assembly: 1 $193.11 $156.31 - + Add to cart
007	HEAT SINK Part #: 37104-MCA-H31 Required per assembly: 1 $166.70 $134.94 - + Add to cart
008	GASKET Part #: 37105-MCA-H31 Required per assembly: 1 $5.52 $4.97 - + Add to cart
009	RUB, METER, SETTING Part #: 37109-MBG-000 Required per assembly: 1 $3.38 $3.07 - + Add to cart
010	METER, COMBINATION, (COO) Part #: 37110-MCA-306 Required per assembly: 1 Note: Area: 3YA 5AC $907.06 $824.60 - + Add to cart
010	METER, COMBINATION Part #: 37110-MCA-S72 Required per assembly: 1 Note: Area: 6YA 7AC $748.85 - + Add to cart
011	LCD, ASSEMBLY, COLOR Part #: 37230-MCA-S82 Required per assembly: 1 $4,039.07 $3,367.71 - + Add to cart
012	STAY, METER, MOUNTING Part #: 53133-MCA-A61 Required per assembly: 1 $16.02 $12.96 - + Add to cart
013	COLLAR, FUEL, TANK Part #: 90509-750-000 Required per assembly: 2 $4.97 $4.67 - + Add to cart
014	COLLAR Part #: 90522-KF0-000 Required per assembly: 2 $5.39 $4.85 - + Add to cart
015	CLIP, WIRE Part #: 91406-166-000 Required per assembly: 1 $4.55 - + Add to cart
016	SCREW, TAP, (3X16) Part #: 93903-22420 Required per assembly: 13 $2.02 $1.87 - + Add to cart
017	SCREW, TAP, (4X16) Part #: 93903-24420 Required per assembly: 17 $1.95 $1.80 - + Add to cart
018	NUT, FLANGE, (6MM) Part #: 94050-06080 Required per assembly: 1 Note: Sold in multiples of 5 only $1.73 $1.59 - + Add to cart
019	WASHER, PLAIN, (6MM) Part #: 94103-06000 Required per assembly: 2 $2.02 $1.87 - + Add to cart
020	BOLT, FLANGE, (6X10) Part #: 96001-06010-07 Required per assembly: 2 $2.63 $2.44 - + Add to cart
021	BOLT, FLANGE, (6X20) Part #: 96001-06020-00 Required per assembly: 4 $2.27 $2.10 - + Add to cart
