Wire Harness replacement parts for 2017 Honda GROM125

OEM Parts Honda 2017 Honda GROM125 Wire Harness

WIRE HARNESS Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 38
001	COIL, IGNITION Part #: 30510-K26-B01 Required per assembly: 1 $22.62 - + Add to cart
002	SPACER, IGNITION, COIL Part #: 30520-GFM-900 Required per assembly: 2 ~~$3.64~~ $3.55 - + Add to cart
003	CAP ASSEMBLY Part #: 30700-KYZ-901 Required per assembly: 1 ~~$17.42~~ $17.40 - + Add to cart
004	RECTIFIER, REGULATOR Part #: 31600-K26-B11 Required per assembly: 1 ~~$100.22~~ $86.42 - + Add to cart
005	RECTIFIER, SILICON Part #: 31700-124-008 Required per assembly: 1 ~~$29.60~~ $28.70 - + Add to cart
006	WIRE HARNESS Part #: 32100-K26-B10 Required per assembly: 1 ~~$354.82~~ $313.89 - + Add to cart
007	CAP, DUMMY, (4P) Part #: 32606-GEV-761 Required per assembly: 1 $6.00 - + Add to cart
008	RUBBER, TAILLIGHT, BRACKET Part #: 33714-KL3-620 Required per assembly: 2 ~~$3.54~~ $3.43 - + Add to cart
009	SENSOR ASSEMBLY (M6) Part #: 35160-MGS-D31 Required per assembly: 1 ~~$163.97~~ $136.62 - + Add to cart
010	HORN Part #: 38110-KWW-A41 Required per assembly: 1 $16.21 - + Add to cart
011	STAY, HORN Part #: 38111-K26-900 Required per assembly: 1 $5.40 - + Add to cart
012	COLLAR, HORN, SETTING Part #: 38117-KYZ-T00 Required per assembly: 1 ~~$1.87~~ $1.11 - + Add to cart
013	RELAY, STARTER Part #: 38501-GFM-901 Required per assembly: 1 ~~$35.27~~ $29.39 - + Add to cart
015	SUSPENSION Part #: 38506-KYK-910 Required per assembly: 1 $3.70 - + Add to cart
017	PGM-FI UNIT Part #: 38770-K26-B13 Required per assembly: 1 ~~$137.04~~ $109.23 - + Add to cart
018	SUSPENSION Part #: 38771-KZL-930 Required per assembly: 1 ~~$3.09~~ $2.82 - + Add to cart
019	BOLT, FLANGE, (6X10) Part #: 90105-K26-B00 Required per assembly: 1 ~~$2.06~~ $1.37 - + Add to cart
020	BOLT, HEX., (6X20) Part #: 92101-06020-4J Required per assembly: 2 ~~$2.40~~ $1.92 - + Add to cart
021	BOLT, FLANGE, (6X12) Part #: 95701-06012-00 Required per assembly: 1 $3.01 - + Add to cart
022	BOLT, FLANGE, (6X14) Part #: 95701-06014-00 Required per assembly: 3 ~~$2.04~~ $1.39 - + Add to cart
023	BOLT, FLANGE, (6X16) Part #: 95701-06016-00 Required per assembly: 1 Note: 95701-06016-08* ~~$2.63~~ $2.24 - + Add to cart
024	FUSE, MINI, (10A) Part #: 98200-41000 Required per assembly: 2 ~~$2.34~~ $1.83 - + Add to cart
025	FUSE, MINI, (15A) Part #: 98200-41500 Required per assembly: 1 ~~$2.27~~ $1.68 - + Add to cart
