OEM Parts Honda 2017 Honda VFR1200X Steering Stem

2017 Honda VFR1200X - Steering Stem

STEERING STEM Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
F 09
001

DUST SEAL

Part #: 53214-371-010 Required per assembly: 1
$14.56
$12.14
-
+
Add to cart
002

DUST SEAL

Part #: 53214-MCJ-751 Required per assembly: 1
$5.73
$5.21
-
+
Add to cart
003

STEM, SUB-ASSEMBLY, STRG

Part #: 53219-MGH-640 Required per assembly: 1
$1,044.12
$845.18
-
+
Add to cart
004

THREAD

Part #: 53220-MCJ-D10 Required per assembly: 1
$18.55
$15.46
-
+
Add to cart
005

BOLT (8X45)

Part #: 90134-MEL-000 Required per assembly: 4
$4.10
$3.73
-
+
Add to cart
006

THREAD B

Part #: 90302-425-830 Required per assembly: 1
$21.65
$21.00
-
+
Add to cart
007

WASHER, LOCK

Part #: 90506-425-830 Required per assembly: 1
$8.47
$7.36
-
+
Add to cart
008

BEARING, HEAD, PIPE

Part #: 91015-KT8-005 Required per assembly: 1
$41.96
$34.31
-
+
Add to cart
009

BEARING, HEAD, PIPE

Part #: 91016-KT8-005 Required per assembly: 1
$41.96
$34.31
-
+
Add to cart
