Chassis Electrical Equipment replacement parts for 2017 Kawasaki Ninja ZX-10R ABS

OEM Parts Kawasaki 2017 Kawasaki Ninja ZX 10R ABS Chassis Electrical Equipment

Chassis Electrical Equipment Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

130	BOLT-FLANGED, 6X12 Part #: 130BA0612 Required per assembly: 1 Note: Sold in multiples of 5 only $1.90 - + Add to cart
130A	BOLT-FLANGED, 6X14 Part #: 130BA0614 Required per assembly: 1 Note: Sold in multiples of 5 only $1.46 - + Add to cart
11056	BRACKET, RELAY Part #: 11056-7706 Required per assembly: 1 $5.99 - + Add to cart
11056A	BRACKET, ECU Part #: 11056-7717 Required per assembly: 1 ~~$48.79~~ $43.83 - + Add to cart
11056B	BRACKET, FUSE Part #: 11056-7809 Required per assembly: 1 $13.98 - + Add to cart
11056C	BRACKET, SHIFTER &GEAR, POSITION Part #: 11056-7816 Required per assembly: 1 $9.33 - + Add to cart
11056D	BRACKET, FRAME, LH Part #: 11056-7828 Required per assembly: 1 $6.23 - + Add to cart
11056E	BRACKET, HARNESS Part #: 11056-7955 Required per assembly: 1 $8.82 - + Add to cart
11056F	BRACKET, CONNECTOR, RR Part #: 11056-7959 Required per assembly: 1 $6.19 - + Add to cart
11057	BRACKET, HORN Part #: 11057-0017 Required per assembly: 1 ~~$21.25~~ $20.45 - + Add to cart
14093	COVER, RELAY Part #: 14093-0476 Required per assembly: 1 ~~$32.44~~ $29.57 - + Add to cart
23062	BRACKET-COMP, CONNECTOR Part #: 23062-0873 Required per assembly: 1 ~~$40.16~~ $36.30 - + Add to cart
26006	FUSE, 15A Part #: 26006-0001 Required per assembly: 5 $6.65 - + Add to cart
26006A	FUSE, MINI, BLADE, 25A, NATURAL Part #: 26006-0020 Required per assembly: 2 $7.09 - + Add to cart
26006B	FUSE, 10A Part #: 26006-1078 Required per assembly: 7 $3.54 - + Add to cart
26006C	FUSE, 30A Part #: 26006-1080 Required per assembly: 1 $5.45 - + Add to cart
26011	WIRE-LEAD, BATTERY(+) Part #: 26011-1889 Required per assembly: 1 ~~$50.29~~ $45.13 - + Add to cart
26011A	WIRE-LEAD, BATTERY(-) Part #: 26011-0943 Required per assembly: 1 ~~$47.49~~ $42.68 - + Add to cart
26012	BATTERY, YTZ10S, 12V, 8.6AH Part #: 26012-0564 Required per assembly: 1 Note: Sold in multiples of 4 only Not Available
26031	HARNESS, MAIN Part #: 26031-2117 Required per assembly: 1 Note: CN Not Available
26031A	HARNESS, MAIN Part #: 26031-2118 Required per assembly: 1 Note: CA $1,718.06 - + Add to cart
27002	RELAY-ASSEMBLY, HEAD, LAMP Part #: 27002-0027 Required per assembly: 1 ~~$43.42~~ $39.15 - + Add to cart
27002A	RELAY ASSEMBLY Part #: 27002-1086 Required per assembly: 4 ~~$37.62~~ $34.10 - + Add to cart
27002B	RELAY, ASSEMBLY, SIGNAL, LAMP Part #: 27002-1097 Required per assembly: 1 ~~$48.33~~ $43.42 - + Add to cart
27003	HORN Part #: 27003-0113 Required per assembly: 1 ~~$85.35~~ $76.99 - + Add to cart
39156	PAD, HEAT, GUARD Part #: 39156-0389 Required per assembly: 1 $2.33 - + Add to cart
39156A	PAD, DIAG., CONNECTOR Part #: 39156-1886 Required per assembly: 1 $2.33 - + Add to cart
39156B	PAD, DIAG/DONGLE Part #: 39156-1993 Required per assembly: 1 ~~$37.06~~ $33.60 - + Add to cart
49018	DIODE Part #: 49018-0005 Required per assembly: 1 ~~$48.05~~ $43.18 - + Add to cart
49018A	DIODE Part #: 49018-0007 Required per assembly: 2 ~~$48.24~~ $43.35 - + Add to cart
53044	TRIM Part #: 53044-0018 Required per assembly: 1 $5.22 - + Add to cart
56030	LABEL, FUSE1 Part #: 56030-0955 Required per assembly: 1 $4.96 - + Add to cart
56030A	LABEL, FUSE2 Part #: 56030-0956 Required per assembly: 1 $3.40 - + Add to cart
92015	NUT, FLANGED, 6MM Part #: 92015-1367 Required per assembly: 1 ~~$3.79~~ $3.75 - + Add to cart
92037	CLAMP, SPEED, L=80.5 Part #: 92037-1903 Required per assembly: 1 $9.35 - + Add to cart
92072	BAND, 202X3.6 Part #: 92072-0782 Required per assembly: 1 $2.18 - + Add to cart
92072A	BAND, L=148 Part #: 92072-3768 Required per assembly: 1 Note: Sold in multiples of 5 only $4.48 - + Add to cart
92154	BOLT, FLANGED, 6X16 Part #: 92154-0551 Required per assembly: 1 Note: Sold in multiples of 5 only $1.87 - + Add to cart
92154A	BOLT, SOCKET, 6X10 Part #: 92154-0774 Required per assembly: 1 Note: Sold in multiples of 5 only $1.87 - + Add to cart
92154B	BOLT, FLANGED, 6X14 Part #: 92154-1864 Required per assembly: 4 $2.35 - + Add to cart
92171	CLAMP, CLIP, DIA=20 Part #: 92171-0068 Required per assembly: 2 Note: (US,CN ONLY) Sold in multiples of 5 only $2.95 - + Add to cart
92171A	CLAMP, BRAKE, HOSE Part #: 92171-0316 Required per assembly: 2 Note: ( - ER650AE032724) $4.32 - + Add to cart
92171B	CLAMP Part #: 92171-1279 Required per assembly: 1 $10.67 - + Add to cart
92172	SCREW, TAPPING, 5X16 Part #: 92172-0175 Required per assembly: 3 Note: Sold in multiples of 5 only $1.98 - + Add to cart
92172A	SCREW, TAPPING, 5X10 Part #: 92172-0262 Required per assembly: 2 Note: Sold in multiples of 10 only $1.57 - + Add to cart
92172B	SCREW, TAPPING, 5X10 Part #: 92172-0335 Required per assembly: 1 Note: Sold in multiples of 5 only $2.35 - + Add to cart
92173	CLAMP Part #: 92173-0736 Required per assembly: 1 $5.61 - + Add to cart
92173A	CLAMP Part #: 92173-0742 Required per assembly: 1 $10.65 - + Add to cart
92173B	CLAMP Part #: 92173-0791 Required per assembly: 1 $12.55 - + Add to cart
92173C	CLAMP Part #: 92173-0861 Required per assembly: 1 $3.14 - + Add to cart
92173D	CLAMP, 68MM Part #: 92173-1009 Required per assembly: 2 $5.28 - + Add to cart
92173E	CLAMP, RUBBER, PLATE Part #: 92173-1229 Required per assembly: 4 $4.52 - + Add to cart
