MODULES and CONTROLLERS - R17RMAL4G9 (700696) Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	ASM-CONTROLLER, 48V, PROG, THK Part #: 4015614 Required per assembly: 1 Currently Not Available
2	CHARGER-48V, ONBOARD, REFRESH Part #: 4016041 Required per assembly: 1 Currently Not Available
3	ASM-CONTACTOR 48V TROMBETTA Part #: 4012818 Required per assembly: 1 Currently Not Available
4	NUT, FLANGE Part #: 7547339 Required per assembly: 7 Currently Not Available
4	NUT, FLANGE Part #: 7547339 Required per assembly: 7 Currently Not Available
4	NUT, FLANGE Part #: 7547339 Required per assembly: 7 Currently Not Available
5	SCREW Part #: 7518535 Required per assembly: 6 Currently Not Available
5	SCREW Part #: 7518535 Required per assembly: 6 Currently Not Available
6	SCREW Part #: 7512026 Required per assembly: 4 Note: Screw Currently Not Available
7	BRKT-CHARGER, MNT, BLK Part #: 5259390-329 Required per assembly: 1 Currently Not Available
8	SCREW Part #: 7518529 Required per assembly: 10 ~~$2.99~~ $1.73 - + Add to cart
8	SCREW Part #: 7518529 Required per assembly: 10 ~~$2.99~~ $1.73 - + Add to cart
8	SCREW Part #: 7518529 Required per assembly: 10 ~~$2.99~~ $1.73 - + Add to cart
9	RELAY, SOLID, STATE, 9, AMP Part #: 4012829 Required per assembly: 1 Note: Relay, Solid State Currently Not Available
10	SCREW Part #: 7518375 Required per assembly: 1 Currently Not Available
11	CONVERTOR, 48V, DC/12V, DC Part #: 4013453 Required per assembly: 1 Currently Not Available
12	COVER-ECM Part #: 5438786 Required per assembly: 1 Currently Not Available
13	WASHER-INT/EXT LOCK 5/16 Part #: 7556560 Required per assembly: 1 Currently Not Available
14	SCREW Part #: 7518780 Required per assembly: 4 Currently Not Available
15	CABLE-CHARGING Part #: 4012836 Required per assembly: 1 Currently Not Available
16	BRACKET, DC/DC, CONVERTER Part #: 5255330 Required per assembly: 1 Currently Not Available
17	STUD-M8X1.25X14X14 Part #: 7519183 Required per assembly: 1 Currently Not Available
18	NUT, HEX, JAM Part #: 7547469 Required per assembly: 2 Currently Not Available
19	WASHER Part #: 7556528 Required per assembly: 2 Currently Not Available
20	HEAT SHRINK-1"IDX2.5" 4:1 Part #: 5521655 Required per assembly: 1 Currently Not Available
21	STRAP, PANDUIT, 14" Part #: 7080761 Required per assembly: 1 Note: Cable Tie Currently Not Available
22	HARNESS-CONTACTOR, BATTERY Part #: 2413242 Required per assembly: 1 Currently Not Available
23	EXTRUSION, CONTROLLER Part #: 5137201 Required per assembly: 1 Currently Not Available
24	ECU-UNPROGRAMMED, BMC, BRAMMO Part #: 4015687 Required per assembly: 1 Currently Not Available
25	ECU-UNPROGRAMMED, BMC Part #: 4016193 Required per assembly: 1 Currently Not Available
26	ECM Part #: 4014125 Required per assembly: 1 Currently Not Available
27	SCREW Part #: 7516822 Required per assembly: 1 Currently Not Available
28	SCREW Part #: 7518925 Required per assembly: 4 Currently Not Available
29	BOLT, FLANGE Part #: 7518612 Required per assembly: 4 Note: Bolt Currently Not Available
30	BOLT Part #: 7518695 Required per assembly: 4 Currently Not Available
31	SCREW Part #: 7519090 Required per assembly: 2 Currently Not Available
32	TRIM, EDGE, 6FT, BLACK Part #: 5521131 Required per assembly: 1 Currently Not Available
33	BOLT Part #: 7519168 Required per assembly: 12 Currently Not Available
34	LOCK WASHER Part #: 7552801 Required per assembly: 4 ~~$3.99~~ $2.30 - + Add to cart
35	WASHER, LOCK Part #: 7556111 Required per assembly: 4 Currently Not Available
