Electrical replacement parts for 2017 Suzuki LT-Z90 QuadSport

OEM Parts Suzuki 2017 Suzuki LT Z90 QuadSport Electrical

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	RELAY, ASSEMBLY, STARTING, MOTOR Part #: 31800-08H00 Required per assembly: 1 $128.45 $109.81 - + Add to cart
2	COVER Part #: 31861-38G00 Required per assembly: 1 $5.29 $4.76 - + Add to cart
3	FUSE (10A) Part #: 09481-10501 Required per assembly: 2 Note: FOR 36610-38F61,36610-38FB1 $2.59 $2.33 - + Add to cart
4	SCREW Part #: 09128-06013 Required per assembly: 2 Note: BOLT, STG MOT TERM; $1.56 $1.40 - + Add to cart
5	RECTIFIER ASSEMBLY Part #: 32800-08H01 Required per assembly: 1 $116.81 $105.13 - + Add to cart
6	CDI UNIT Part #: 32900-08H00 Required per assembly: 1 $419.83 $358.94 - + Add to cart
7	PROTECTOR (30X50X3.0) Part #: 33652-36000 Required per assembly: 1 $393.31 $336.27 - + Add to cart
8	COIL, ASSEMBLY, IGNITION Part #: 33410-36G00 Required per assembly: 1 $142.88 $122.15 - + Add to cart
9	SCREW Part #: 02162-0620B Required per assembly: 1 Note: BOLT; $2.65 $2.39 - + Add to cart
10	CAP, ASSEMBLY, SPARK, (SIDE) Part #: 33510-20E00 Required per assembly: 1 Note: CAP ASSY, SPARK PLUG; $37.38 $33.64 - + Add to cart
11	SEAL, SPARK, PLUG Part #: 33541-47D00 Required per assembly: 1 $9.67 $8.70 - + Add to cart
12	SEAL, HIGHTENSION, CORD Part #: 33542-38B00 Required per assembly: 1 Note: SEAL, HIGH TENSION CORD; $30.87 $26.39 - + Add to cart
