Front Fork replacement parts for 2017 Yamaha FJR1300ES

OEM Parts Yamaha 2017 Yamaha FJR1300ES Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (L.H) Part #: 1MD-23102-00-00 Required per assembly: 1 $1,306.91 $1,197.10 - + Add to cart
2	TUBE, OUTER, (RIGHT) Part #: 1MD-23136-00-00 Required per assembly: 1 $239.99 $224.77 - + Add to cart
3	WASHER, OIL, SEAL Part #: 4V4-23146-L0-00 Required per assembly: 1 $7.49 $6.35 - + Add to cart
4	OIL SEAL Part #: 4PU-23145-01-00 Required per assembly: 1 $28.98 $20.61 - + Add to cart
5	RING, SNAP Part #: 4V4-23153-L0-00 Required per assembly: 1 $10.99 $8.50 - + Add to cart
6	SEAL, DUST Part #: 4PU-23144-00-00 Required per assembly: 1 $26.98 $19.81 - + Add to cart
7	INNER TUBE COMP.1 Part #: 1MD-23110-00-00 Required per assembly: 1 $237.99 $234.29 - + Add to cart
8	CYLINDER, COMP, FRONT, FORK Part #: 1MD-23170-10-00 Required per assembly: 1 $273.99 $268.80 - + Add to cart
9	GASKET Part #: 509-23158-L0-00 Required per assembly: 1 $17.98 $14.09 - + Add to cart
10	BOLT, HEXAGON, SOCKET, HEAD Part #: 3D8-23181-00-00 Required per assembly: 1 $9.49 $7.50 - + Add to cart
11	SPRING, FRONT, FORK Part #: 1MD-23141-00-00 Required per assembly: 1 $49.99 $43.06 - + Add to cart
12	SPACER Part #: 1MD-23118-00-00 Required per assembly: 1 $28.98 $23.54 - + Add to cart
13	NUT Part #: 3LC-23357-00-00 Required per assembly: 1 $7.49 $6.31 - + Add to cart
14	BOLT, CAP Part #: 1MD-23111-00-00 Required per assembly: 1 $658.33 $598.48 - + Add to cart
15	O-RING Part #: 39P-23147-00-00 Required per assembly: 1 $9.49 $6.77 - + Add to cart
16	FRONT FORK ASSEMBLY (R.H) Part #: 1MD-23103-00-00 Required per assembly: 1 $1,306.91 $1,197.10 - + Add to cart
17	TUBE, OUTER, (RIGHT) Part #: 1MD-23136-00-00 Required per assembly: 1 $239.99 $224.77 - + Add to cart
18	WASHER, OIL, SEAL Part #: 4V4-23146-L0-00 Required per assembly: 1 $7.49 $6.35 - + Add to cart
19	OIL SEAL Part #: 4PU-23145-01-00 Required per assembly: 1 $28.98 $20.61 - + Add to cart
20	RING, SNAP Part #: 4V4-23153-L0-00 Required per assembly: 1 $10.99 $8.50 - + Add to cart
21	SEAL, DUST Part #: 4PU-23144-00-00 Required per assembly: 1 $26.98 $19.81 - + Add to cart
22	INNER TUBE COMP.2 Part #: 1MD-23120-00-00 Required per assembly: 1 $237.99 $234.29 - + Add to cart
23	CYLINDER, COMP, FRONT, FORK Part #: 1MD-23170-00-00 Required per assembly: 1 $273.99 $268.80 - + Add to cart
24	GASKET Part #: 509-23158-L0-00 Required per assembly: 1 $17.98 $14.09 - + Add to cart
25	BOLT, HEXAGON, SOCKET, HEAD Part #: 3D8-23181-00-00 Required per assembly: 1 $9.49 $7.50 - + Add to cart
26	SPRING, FRONT, FORK Part #: 1MD-23141-00-00 Required per assembly: 1 $49.99 $43.06 - + Add to cart
27	SPACER Part #: 1MD-23118-00-00 Required per assembly: 1 $28.98 $23.54 - + Add to cart
28	NUT Part #: 3LC-23357-00-00 Required per assembly: 1 $7.49 $6.31 - + Add to cart
29	BOLT, CAP Part #: 1MD-23111-00-00 Required per assembly: 1 $658.33 $598.48 - + Add to cart
30	O-RING Part #: 39P-23147-00-00 Required per assembly: 1 $9.49 $6.77 - + Add to cart
31	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08040-00 Required per assembly: 4 $8.49 $5.15 - + Add to cart
32	UNDER BRACKET COMP. Part #: 1MD-23340-00-00 Required per assembly: 1 $425.35 - + Add to cart
33	BOLT, SOCKET Part #: 91317-08025-00 Required per assembly: 4 $9.49 $6.12 - + Add to cart
34	WIRE, SUB, LEAD Part #: 1MD-82509-00-00 Required per assembly: 1 $66.98 $60.65 - + Add to cart
35	WIRE, SUB, LEAD Part #: 1MD-82509-10-00 Required per assembly: 1 $66.98 $60.65 - + Add to cart
36	FORK SEALS KIT Part #: 4PU-W003B-00-00 Required per assembly: 1 $47.99 $43.27 - + Add to cart
