Frame replacement parts for 2017 Yamaha RS Vector

OEM Parts Yamaha 2017 Yamaha RS Vector Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FRAME COMP. Part #: 8JU-21940-00-00 Required per assembly: 1 $2,689.11 - + Add to cart
2	BULKHEAD Part #: 8FA-W2197-13-00 Required per assembly: 1 $485.56 - + Add to cart
3	BUSH, SOLID Part #: 90381-15001-00 Required per assembly: 2 $6.49 $4.02 - + Add to cart
4	BUSH, SOLID Part #: 90381-16004-00 Required per assembly: 2 $18.48 $12.69 - + Add to cart
5	BULKHEAD 2 Part #: 8FA-W2198-15-00 Required per assembly: 1 Not Available
6	BUSH, SOLID Part #: 90381-15001-00 Required per assembly: 2 $6.49 $4.02 - + Add to cart
7	BUSH, SOLID Part #: 90381-16004-00 Required per assembly: 2 $18.48 $12.69 - + Add to cart
8	BOLT, FLANGE Part #: 95817-08060-00 Required per assembly: 3 $4.79 $3.21 - + Add to cart
9	BOLT, WASHER, BASED Part #: 90105-084A1-00 Required per assembly: 1 $11.49 $9.21 - + Add to cart
10	NUT, SELF-LOCKING Part #: 90185-08169-00 Required per assembly: 4 $9.49 $6.97 - + Add to cart
11	BRACKET 2 Part #: 8HG-2836E-00-00 Required per assembly: 1 $12.99 $10.69 - + Add to cart
12	BRACKET, STEERING, 1 Part #: 8FG-21947-00-00 Required per assembly: 1 $182.99 $170.95 - + Add to cart
13	NUT, SELF-LOCKING, (JN5) Part #: 95607-10200-00 Required per assembly: 4 $4.15 $3.27 - + Add to cart
14	PROTECTOR Part #: 8FR-2193A-01-00 Required per assembly: 1 $100.98 $91.52 - + Add to cart
15	HEAT EXCHANGER ASSEMBLY Part #: 8JA-12440-00-00 Required per assembly: 1 $538.33 $495.39 - + Add to cart
16	HOSE 7 Part #: 8FA-12551-00-00 Required per assembly: 1 $9.49 $7.62 - + Add to cart
17	CLIP, SCISSOR Part #: 90467-28046-00 Required per assembly: 1 $18.48 $12.22 - + Add to cart
18	HOSE CLAMP ASSEMBLY Part #: 90450-35001-00 Required per assembly: 1 $6.49 $5.16 - + Add to cart
19	NUT, SELF-LOCKING Part #: 90185-08169-00 Required per assembly: 1 $9.49 $6.97 - + Add to cart
20	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 43 Note: (4.7X16.4 YELLOW) $4.20 $3.46 - + Add to cart
21	PLATE, COVER Part #: 8ES-2131D-00-00 Required per assembly: 1 $5.49 $4.19 - + Add to cart
22	RIVET, BLIND, (4.8X16.4, YELLOW) Part #: 90267-48016-00 Required per assembly: 12 $11.49 $7.70 - + Add to cart
23	CLAMP Part #: 90462-08083-00 Required per assembly: 1 $13.49 $11.34 - + Add to cart
24	RIVET, BLIND, (48X14, YELLOW) Part #: 90267-48177-00 Required per assembly: 16 $2.60 $1.68 - + Add to cart
25	REAR FRAME COMP. Part #: 8JU-21950-00-00 Required per assembly: 1 $2,835.37 - + Add to cart
26	REINEFORCEMENT, FRAME, REAR, 1 Part #: 8FA-W2199-10-00 Required per assembly: 1 $2,472.36 $2,256.60 - + Add to cart
27	REINFORCEMENT, FOOTR Part #: 8FG-21926-00-00 Required per assembly: 1 $141.99 $140.16 - + Add to cart
28	REINFORCEMENT, FOOTR Part #: 8FG-21936-00-00 Required per assembly: 1 $141.99 $128.16 - + Add to cart
29	BRACKET, MAIN, TRACK, 1 Part #: 8HN-21943-00-00 Required per assembly: 1 $48.99 $42.59 - + Add to cart
30	BRACKET, MAIN, TRACK Part #: 8HN-21953-00-00 Required per assembly: 1 $38.99 $34.17 - + Add to cart
31	BRACKET, RR.TRACK, SUSPENTION, 1 Part #: 8FT-21944-00-00 Required per assembly: 1 $86.98 $78.52 - + Add to cart
32	BRACKET, RR.TRACK, SU Part #: 8FT-21954-00-00 Required per assembly: 1 $86.98 $78.52 - + Add to cart
33	BOLT, FLANGE Part #: 95814-10020-00 Required per assembly: 4 $4.45 $3.70 - + Add to cart
34	PATCH 8 Part #: 8FU-21988-01-00 Required per assembly: 2 $9.49 $7.86 - + Add to cart
35	BRACKET, FUEL, TANK, 1 Part #: 8CR-2194N-00-00 Required per assembly: 2 $3.64 $3.08 - + Add to cart
36	BRACKET 1 Part #: 8FA-2194X-00-00 Required per assembly: 1 $4.20 $3.46 - + Add to cart
37	BRACKET 2 Part #: 8FA-2195X-00-00 Required per assembly: 1 $4.20 $3.46 - + Add to cart
38	PROTECTOR, MUFFLER Part #: 8ES-2194H-00-00 Required per assembly: 1 $68.98 $57.18 - + Add to cart
39	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 1 Note: (4.7X16.4 YELLOW) $4.20 $3.46 - + Add to cart
40	PATCH 3 Part #: 8FT-21963-01-00 Required per assembly: 1 $61.99 $55.38 - + Add to cart
41	PATCH 4 Part #: 8FT-21964-01-00 Required per assembly: 1 $61.99 $55.38 - + Add to cart
42	HEAT EXCHANGER ASSEMBLY Part #: 8FT-1241A-00-00 Required per assembly: 1 $879.99 $803.90 - + Add to cart
43	WASHER, SEAL Part #: 90210-06006-00 Required per assembly: 1 Note: AP $9.49 $5.78 - + Add to cart
44	BOLT, FLANGE Part #: 95817-06012-00 Required per assembly: 1 $1.95 $1.47 - + Add to cart
45	RIVET, BLIND, (4.8X12.6, SILVER) Part #: 90267-48095-00 Required per assembly: 2 Note: (4.8X12.6 SILVER) $2.70 $1.97 - + Add to cart
46	BOLT, BUTTON, HEAD Part #: 92012-10020-00 Required per assembly: 2 $3.75 $3.08 - + Add to cart
47	MEMBER, SIDE, 1 Part #: 8FG-2111J-00-00 Required per assembly: 1 $88.98 $80.18 - + Add to cart
48	MEMBER, SIDE, 2 Part #: 8FG-2111K-00-00 Required per assembly: 1 $88.98 $80.18 - + Add to cart
49	PANEL, SUB, FRAME, 5 Part #: 8FT-21916-01-00 Required per assembly: 1 $173.45 - + Add to cart
50	PATCH 8 Part #: 8FG-21988-00-00 Required per assembly: 1 $4.90 $4.08 - + Add to cart
51	PATCH 9 Part #: 8FG-21989-00-00 Required per assembly: 1 $4.90 $4.08 - + Add to cart
52	RIVET, BLIND Part #: 90267-47197-00 Required per assembly: 8 Note: FOR EF30ISEBH $2.39 $1.58 - + Add to cart
53	RIVET, BLIND, (4.8X12.1, YELLOW) Part #: 90267-48023-00 Required per assembly: 30 $11.49 $8.04 - + Add to cart
54	BRACKET, REFLECTOR, 1 Part #: 8FT-2113J-00-00 Required per assembly: 2 $13.99 $11.52 - + Add to cart
55	FRAME CONNECTION KIT Part #: 8JU-W2195-00-00 Required per assembly: 1 $218.99 $204.62 - + Add to cart
56	BRACKET, CHAIN, HOUSING Part #: 8CR-21939-01-00 Required per assembly: 2 $6.49 $5.26 - + Add to cart
57	BRACKET, 5 Part #: 8JA-2196M-00-00 Required per assembly: 1 $35.99 $31.24 - + Add to cart
58	BRACKET, 6 Part #: 8JA-2197M-00-00 Required per assembly: 1 $35.99 $31.24 - + Add to cart
59	COVER 2 Part #: 8FP-2198G-01-00 Required per assembly: 1 $25.98 $20.20 - + Add to cart
60	CLAMP, WIRE, HARNESS Part #: 8FA-21999-00-00 Required per assembly: 1 $10.99 $7.12 - + Add to cart
61	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 58 Note: (4.7X16.4 YELLOW) $4.20 $3.46 - + Add to cart
62	RIVET, BLIND, (4.8X18.6, BLACK) Part #: 90267-48018-00 Required per assembly: 4 Note: (4.8X18.6 BLACK) $10.49 $7.23 - + Add to cart
63	RIVET, BLIND, (4.8X16.4, YELLOW) Part #: 90267-48016-00 Required per assembly: 14 $11.49 $7.70 - + Add to cart
64	RIVET, BLIND, (48X14, YELLOW) Part #: 90267-48177-00 Required per assembly: 10 $2.60 $1.68 - + Add to cart
65	RIVET, BLIND, (4.8X16.4, YELLOW) Part #: 90267-48016-00 Required per assembly: 4 $11.49 $7.70 - + Add to cart
66	FOOTREST COMP. 1 Part #: 8JA-21960-00-00 Required per assembly: 1 Not Available
67	FOOTREST COMP. 2 Part #: 8HG-21970-00-00 Required per assembly: 1 $260.99 $257.95 - + Add to cart
68	HOUSING, REINF, SUB-ASSEMBLY, (L.H) Part #: 8EK-21920-01-00 Required per assembly: 1 Note: (L.H) $21.98 $17.37 - + Add to cart
69	GROMMET Part #: 90480-13567-00 Required per assembly: 2 $5.49 $3.81 - + Add to cart
70	FRAME UNDER 1 Part #: 8GM-2196A-01-00 Required per assembly: 1 $214.47 - + Add to cart
71	FRAME, UNDER, 2 Part #: 8FP-2196E-02-00 Required per assembly: 1 $97.97 - + Add to cart
72	BRACKET, GUARD, FITTING Part #: 8FP-21972-00-00 Required per assembly: 1 $41.99 $31.34 - + Add to cart
73	BRACKET 3 Part #: 8FA-2196F-00-00 Required per assembly: 6 $7.49 $5.47 - + Add to cart
74	RIVET, BLIND, (4.8X18.6, BLACK) Part #: 90267-48018-00 Required per assembly: 12 Note: (4.8X18.6 BLACK) $10.49 $7.23 - + Add to cart
75	RIVET, BLIND, (4.7X16.4, BLACK) Part #: 90267-47187-00 Required per assembly: 3 $2.50 $1.86 - + Add to cart
76	PROTECTOR, FRAME Part #: 8FT-21978-00-00 Required per assembly: 2 $129.72 - + Add to cart
77	BRACKET 7 Part #: 8FT-2197N-00-00 Required per assembly: 2 $9.49 $7.68 - + Add to cart
78	BRACKET 7 Part #: 8FU-2197N-00-00 Required per assembly: 4 $23.98 $17.72 - + Add to cart
79	BRACKET 3 Part #: 8FT-2196F-00-00 Required per assembly: 1 $17.48 $14.62 - + Add to cart
80	BRACKET 4 Part #: 8FT-2196G-00-00 Required per assembly: 1 $12.99 $10.70 - + Add to cart
81	BOLT, FLANGE, (8AB) Part #: 95817-08020-00 Required per assembly: 2 $10.49 $6.86 - + Add to cart
82	RIVET, BLIND, (4.7X16.4, BLACK) Part #: 90267-47186-00 Required per assembly: 12 $3.20 $2.27 - + Add to cart
83	RIVET, BLIND, (4.8X15.2, SILVER) Part #: 90267-48083-00 Required per assembly: 8 Note: (4.8X15.2 SILVER) $3.60 $2.74 - + Add to cart
84	RIVET, BLIND, (4.8X12.6, SILVER) Part #: 90267-48095-00 Required per assembly: 4 Note: (4.8X12.6 SILVER) $2.70 $1.97 - + Add to cart
85	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 8 Note: (4.7X16.4 YELLOW) $4.20 $3.46 - + Add to cart
86	RIVET, BLIND, (4.8X12.1, YELLOW) Part #: 90267-48023-00 Required per assembly: 12 $11.49 $8.04 - + Add to cart
87	RIVET, BLIND, (48X14, YELLOW) Part #: 90267-48177-00 Required per assembly: 4 $2.60 $1.68 - + Add to cart
88	PROTECTOR, FRAME, FR Part #: 8FR-2197E-00-00 Required per assembly: 1 $49.99 $41.69 - + Add to cart
89	BOLT, BUTTON, HEAD Part #: 92012-06012-00 Required per assembly: 2 $4.70 $2.45 - + Add to cart
90	SPACER Part #: 8FA-21998-00-00 Required per assembly: 4 $4.25 $3.52 - + Add to cart
91	SHIELD, HEAT Part #: 8FG-23892-00-00 Required per assembly: 1 $50.99 $43.03 - + Add to cart
92	RIVET, BLIND, (48X123) Part #: 90267-48059-00 Required per assembly: 14 Note: (4.8X12.3) (4.8X12.3) $3.54 $2.42 - + Add to cart
93	GROMMET Part #: 90480-12053-00 Required per assembly: 1 Note: Sold in multiples of 5 only $8.49 $5.67 - + Add to cart
94	LABEL, WARNING, 2 Part #: 8HA-77762-E0-00 Required per assembly: 1 $11.49 $9.19 - + Add to cart
95	STOPPER Part #: 8HG-24768-00-00 Required per assembly: 1 $7.99 $6.49 - + Add to cart
96	DAMPER 1 Part #: 8HG-2214F-00-00 Required per assembly: 2 $12.49 $10.39 - + Add to cart
97	TAPE 4 Part #: 8FA-7717H-00-00 Required per assembly: 1 $1.75 $1.47 - + Add to cart
98	LABEL, WARNING, 5 Part #: 8JT-77765-E0-00 Required per assembly: 1 $6.49 $5.29 - + Add to cart
