Bimini Top / Carpet replacement parts for 2017 Yamaha 242 LTD S California

OEM Parts Yamaha 2017 Yamaha 242 LTD S California Bimini Top / Carpet

BIMINI TOP / CARPET Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	AWNING, CANVAS, SET Part #: F3F-U3104-21-00 Required per assembly: 1 $1,995.14 - + Add to cart
1	AWNING, CANVAS, SET Part #: F3F-U3104-50-00 Required per assembly: 1 $1,796.97 - + Add to cart
2	CANVAS, SET, ASH Part #: F3F-U3108-50-00 Required per assembly: 1 $798.32 $736.74 - + Add to cart
2	CANVAS SET TAUPE Part #: F3F-U3108-21-00 Required per assembly: 1 $798.32 $736.74 - + Add to cart
3	COVER Part #: F3F-U3119-20-00 Required per assembly: 1 $340.67 $293.31 - + Add to cart
3	COVER Part #: F3F-U3119-50-00 Required per assembly: 1 $355.97 $315.38 - + Add to cart
4	PIPE, AWNING, 1 Part #: F3F-U3111-00-00 Required per assembly: 1 $424.03 - + Add to cart
5	PIPE, AWNING, 2 Part #: F3F-U3112-01-00 Required per assembly: 1 $352.97 - + Add to cart
6	PIPE, AWNING, 3 Part #: F3F-U3113-00-00 Required per assembly: 2 $211.13 $189.78 - + Add to cart
7	PIPE, AWNING, 4 Part #: F3F-U3114-00-00 Required per assembly: 2 $247.84 $224.66 - + Add to cart
8	CARPET SET Part #: F3F-U3908-70-00 Required per assembly: 1 $1,560.06 $1,468.24 - + Add to cart
8	CARPET SET Part #: F3F-U3908-90-00 Required per assembly: 1 $1,062.77 $1,016.15 - + Add to cart
9	SNAP, CARPET Part #: F1C-U5192-00-00 Required per assembly: 50 $0.71 $0.60 - + Add to cart
10	WASHER, PLASTIC, CARPET, SNAP Part #: 90202-06SA1-00 Required per assembly: 50 $6.11 $1.97 - + Add to cart
11	CARPET 18 Part #: F3F-U398N-70-00 Required per assembly: 1 $367.19 $353.70 - + Add to cart
11	CARPET 18 Part #: F3F-U398N-90-00 Required per assembly: 1 $487.55 $464.07 - + Add to cart
12	CARPET 19 Part #: F3F-U398P-70-00 Required per assembly: 1 $212.15 $189.78 - + Add to cart
12	CARPET 19 Part #: F3F-U398P-90-00 Required per assembly: 1 $263.14 $234.30 - + Add to cart
13	CARPET 20 Part #: F3F-U398R-70-00 Required per assembly: 1 $289.67 $255.95 - + Add to cart
13	CARPET 20 Part #: F3F-U398R-90-00 Required per assembly: 1 $297.82 $268.05 - + Add to cart
14	FITTING BRACKET ASSEMBLY 1 Part #: F3F-U5920-00-00 Required per assembly: 4 $50.99 $42.31 - + Add to cart
15	SCREW TRUSS HEAD Part #: 90169-10SA5-00 Required per assembly: 8 $7.12 $3.18 - + Add to cart
