Control Cable replacement parts for 2017 Yamaha 242 LTD S E Series

OEM Parts Yamaha 2017 Yamaha 242 LTD S E Series Control Cable

CONTROL CABLE Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	REMOCON. LEVER ASSEMBLY Part #: F3F-U134A-00-00 Required per assembly: 1 Not Available
2	COVER Part #: F3F-U1595-A0-00 Required per assembly: 1 $391.67 $341.70 - + Add to cart
3	BOLT Part #: F3F-U1355-00-00 Required per assembly: 1 $17.32 $13.59 - + Add to cart
4	SCREW, PAN, HEAD Part #: 90157-10S16-00 Required per assembly: 4 $5.08 $0.91 - + Add to cart
5	PLATE Part #: F3F-U1348-00-00 Required per assembly: 2 $11.21 $6.43 - + Add to cart
6	SCREW, COUNTERSUNK Part #: 90151-10S20-00 Required per assembly: 4 $0.46 $0.38 - + Add to cart
7	WASHER, #10, FLAT Part #: 90201-10S00-00 Required per assembly: 4 $4.99 $0.56 - + Add to cart
8	NUT, SELF-LOCKING Part #: 90185-10S00-00 Required per assembly: 4 $5.08 $1.06 - + Add to cart
9	MOTOR ASSEMBLY Part #: F3F-6140B-01-00 Required per assembly: 1 $1,721.99 $1,708.42 - + Add to cart
10	SCREW, TAPPING Part #: 90169-10SA0-00 Required per assembly: 4 $6.11 $1.36 - + Add to cart
11	COVER Part #: F3F-U7437-00-00 Required per assembly: 1 $160.13 $132.47 - + Add to cart
12	SCREW Part #: 90149-10SC4-00 Required per assembly: 4 $5.08 $3.02 - + Add to cart
13	WASHER, PLATE Part #: 90201-15S00-00 Required per assembly: 4 $0.15 - + Add to cart
14	WASHER, 5/16X1, 1/2 Part #: 90209-15SA4-00 Required per assembly: 4 $6.11 $1.51 - + Add to cart
15	NUT, WING Part #: 90175-15SA1-00 Required per assembly: 4 $3.04 $1.13 - + Add to cart
16	CONTROL UNIT ASSEMBLY Part #: F3F-H5590-02-00 Required per assembly: 1 Not Available
17	DAMPER, IGNITION, COIL Part #: 6A0-82317-01-00 Required per assembly: 4 $7.49 $7.03 - + Add to cart
18	COLLAR Part #: 90387-06119-00 Required per assembly: 4 $4.90 $4.84 - + Add to cart
19	SCREW, TAPPING Part #: 90167-10S16-00 Required per assembly: 4 $6.11 $1.36 - + Add to cart
20	WASHER, #10, FLAT Part #: 90201-10S00-00 Required per assembly: 4 $4.99 $0.56 - + Add to cart
21	CONTROL UNIT Part #: F3F-68197-00-00 Required per assembly: 1 $997.99 $981.27 - + Add to cart
22	MAT, WATER, LOCK Part #: GJ3-U755J-00-00 Required per assembly: 1 $115.25 $90.70 - + Add to cart
23	EYE STRAP Part #: F3F-U1543-00-00 Required per assembly: 2 $9.67 $7.41 - + Add to cart
24	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 4 $6.11 $1.13 - + Add to cart
25	CABLE, SHIFT Part #: F0R-U149C-10-00 Required per assembly: 2 $140.75 $117.83 - + Add to cart
26	CONNECTOR, CABLE Part #: EU0-67267-00-00 Required per assembly: 2 $59.86 $54.42 - + Add to cart
27	SHAFT, JOINT, BALL Part #: EU0-61461-30-00 Required per assembly: 2 $67.48 $66.51 - + Add to cart
