OEM Parts Yamaha 2017 Yamaha 242 LTD E Series California Hull Deck Fittings

2017 Yamaha 242 LTD E Series California SAT1800GLS F3FR - Hull Deck Fittings

HULL DECK FITTINGS Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

GUNWALE (BLACK 20')

Part #: F2A-U2557-10-00 Required per assembly: 2
$555.81
-
+
Add to cart
2

GUNWALE

Part #: F2D-U2557-00-00 Required per assembly: 1 Note: BLACK
$75.84
-
+
Add to cart
3

INNER GUNWALE (STAINLESS 16')

Part #: F2A-U2519-10-00 Required per assembly: 1
$748.09
-
+
Add to cart
4

INNER GUNWALE (STAINLESS 16')

Part #: F2A-U2519-10-00 Required per assembly: 2
$748.09
-
+
Add to cart
5

SCREW, #10, X, 1-1/4

Part #: 90161-10S20-00 Required per assembly: 17
$6.11
$1.36
-
+
Add to cart
6

SCREW, TAPPING

Part #: 90162-08S20-00 Required per assembly: 1 Note: UN
$6.11
$1.36
-
+
Add to cart
7

COVER, GUNWALE(STAINLESS, STEEL)

Part #: F2A-U2518-00-00 Required per assembly: 1
$31.62
-
+
Add to cart
8

STANCHION, TABLE, 1

Part #: F3H-U4814-01-00 Required per assembly: 1
$342.70
$287.19
-
+
Add to cart
9

TABLE

Part #: F3F-U4811-00-00 Required per assembly: 1
$269.26
$260.30
-
+
Add to cart
10

MAT STEP 10

Part #: F3F-U351U-20-00 Required per assembly: 1
$118.31
$93.73
-
+
Add to cart
11

BRKT., TABLE, 2

Part #: F3H-U4826-00-00 Required per assembly: 1
$40.78
$29.45
-
+
Add to cart
12

SCREW, #10, X, 3/4&QUO

Part #: 90169-10SA1-00 Required per assembly: 6
$6.11
$1.44
-
+
Add to cart
13

ICE BOX COMP.

Part #: F2D-U4360-00-00 Required per assembly: 1
Not Available
14

BOW EYE 1

Part #: F3A-U1624-00-00 Required per assembly: 2
$41.81
$31.72
-
+
Add to cart
15

BOW EYE 1

Part #: F3F-U1624-00-00 Required per assembly: 1
$36.71
$27.94
-
+
Add to cart
16

ANCHOR ROPE RETAINER

Part #: F1C-U1794-00-00 Required per assembly: 1
$15.80
$12.84
-
+
Add to cart
17

LADDER, TRANSOM

Part #: F2D-U2425-00-00 Required per assembly: 1
$461.02
$441.37
-
+
Add to cart
18

BAND, BOARDING, LADDER

Part #: F1C-U5191-00-00 Required per assembly: 1
$51.99
$38.95
-
+
Add to cart
19

CUSHION, RUBBER

Part #: F1C-U3768-00-00 Required per assembly: 4
$17.32
$13.59
-
+
Add to cart
20

CAP, LADDER

Part #: F1C-U2155-00-00 Required per assembly: 1
$21.41
$15.86
-
+
Add to cart
21

BOLT

Part #: 90101-08802-00 Required per assembly: 4
$1.16
$0.98
-
+
Add to cart
22

WASHER, PLATE

Part #: 9299R-08600-00 Required per assembly: 4 Note: Sold in multiples of 10 only
$7.12
$2.27
-
+
Add to cart
23

BOX, SIDE

Part #: F3F-U4776-00-00 Required per assembly: 1
$55.07
$45.33
-
+
Add to cart
24

SCREW TRUSS HEAD

Part #: 90169-08SA3-00 Required per assembly: 4
$6.11
$1.36
-
+
Add to cart
25

HOLDER, DRINK

Part #: F2J-U5633-00-00 Required per assembly: 1
$20.39
$15.10
-
+
Add to cart
26

SCREW, #6, X, 3/4, PFH

Part #: 90161-06S12-00 Required per assembly: 3
$6.11
$2.42
-
+
Add to cart
27

RING

Part #: F2J-U7845-00-00 Required per assembly: 1
$7.12
$4.22
-
+
Add to cart
28

HOLDER, DRINK

Part #: F2D-U5633-10-00 Required per assembly: 2
$26.51
$19.64
-
+
Add to cart
29

CLEAT

Part #: F1C-U1616-10-00 Required per assembly: 6
$112.19
$86.17
-
+
Add to cart
30

HANDLE

Part #: F1C-U1552-01-00 Required per assembly: 1
$21.41
$15.86
-
+
Add to cart
31

SCREW, #8, X, 3/4"

Part #: 90167-08S12-00 Required per assembly: 4
$6.11
$1.29
-
+
Add to cart
32

GRIP ASSEMBLY

Part #: F3H-U270B-01-00 Required per assembly: 3
$192.77
$152.68
-
+
Add to cart
33

NUT, SELF-LOCKING

Part #: 90185-15S00-00 Required per assembly: 8
$0.45
$0.42
-
+
Add to cart
34

WASHER, PLATE

Part #: 90201-099U1-00 Required per assembly: 8
$7.12
$2.42
-
+
Add to cart
35

NET, STORAGE

Part #: F3F-U4751-00-00 Required per assembly: 1
$81.59
$63.49
-
+
Add to cart
36

HOOK

Part #: F3F-U5192-00-00 Required per assembly: 4
$7.12
$3.08
-
+
Add to cart
37

SCREW, #10, X, 1-1/4

Part #: 90161-10S20-00 Required per assembly: 4
$6.11
$1.36
-
+
Add to cart
38

GRIP ASSEMBLY

Part #: F3H-U270B-20-00 Required per assembly: 1
$98.93
$77.10
-
+
Add to cart
39

WASHER, PLATE

Part #: 90201-099U1-00 Required per assembly: 2
$7.12
$2.42
-
+
Add to cart
40

WASHER, 5/16", SPLITLOCK

Part #: 90204-15S00-00 Required per assembly: 2
$7.99
$0.97
-
+
Add to cart
41

NUT

Part #: 90170-15S00-00 Required per assembly: 2
$5.99
$1.67
-
+
Add to cart
42

HAND RAIL

Part #: F3H-U2767-00-00 Required per assembly: 2
$144.99
$112.47
-
+
Add to cart
43

WASHER, PLATE

Part #: 90201-099U1-00 Required per assembly: 4
$7.12
$2.42
-
+
Add to cart
44

NUT, SELF-LOCKING

Part #: 90185-15S00-00 Required per assembly: 4
$0.45
$0.42
-
+
Add to cart
45

BRKT., TABLE, 1

Part #: F3H-U4825-10-00 Required per assembly: 2
$112.19
$86.17
-
+
Add to cart
46

SPACER 1

Part #: F3F-U471E-00-00 Required per assembly: 2
$53.03
$42.31
-
+
Add to cart
47

SCREW, COUNTERSUNK

Part #: 90151-14S36-00 Required per assembly: 8
$6.11
$1.59
-
+
Add to cart
48

WASHER, 1/4", FL

Part #: 90201-14S00-00 Required per assembly: 8
$7.12
$1.66
-
+
Add to cart
49

NUT, SELF-LOCKING

Part #: 90185-14S00-00 Required per assembly: 8
$5.08
$0.68
-
+
Add to cart
50

SKI TOWS

Part #: F1T-U1629-00-00 Required per assembly: 1
$76.48
$58.95
-
+
Add to cart
51

LADDER, STEP, ASSEMBLY

Part #: F3F-U278A-00-00 Required per assembly: 1
$404.93
$383.98
-
+
Add to cart
52

EYE STRAP

Part #: F2D-U1543-00-00 Required per assembly: 1
$20.39
$15.86
-
+
Add to cart
53

SNAP, CARPET

Part #: F1C-U5192-00-00 Required per assembly: 2
$0.71
$0.60
-
+
Add to cart
54

SCREW, 1/4-20, X, 1-1/4

Part #: 90157-14S20-00 Required per assembly: 4
$5.08
$0.98
-
+
Add to cart
