OEM Parts Yamaha 2017 Yamaha SR400 Electrical 2

2017 Yamaha SR400 SR400HCB - Electrical 2

ELECTRICAL 2 Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

NEUTRAL SWITCH ASSEMBLY

Part #: 4GY-82540-10-00 Required per assembly: 1
$41.99
$32.93
-
+
Add to cart
2

GASKET

Part #: 90430-10148-00 Required per assembly: 1
$5.99
$4.81
-
+
Add to cart
3

STOP SWITCH ASSEMBLY

Part #: 3HT-82530-00-00 Required per assembly: 1
$32.99
$26.64
-
+
Add to cart
4

FLASHER RELAY ASSEMBLY

Part #: 3HT-83350-01-00 Required per assembly: 1
$61.99
$49.85
-
+
Add to cart
5

HORN

Part #: 25G-83371-00-00 Required per assembly: 1
$98.98
$81.44
-
+
Add to cart
6

BOLT, FLANGE

Part #: 95817-08012-00 Required per assembly: 1
$5.49
$3.90
-
+
Add to cart
7

SWITCH, SIDE, STAND

Part #: 3D8-82566-70-00 Required per assembly: 1
Not Available
8

SCREW, PAN, HEAD

Part #: 98507-05014-00 Required per assembly: 2
$8.49
$5.17
-
+
Add to cart
9

BAND

Part #: 1UA-82591-00-00 Required per assembly: 2
$5.49
$4.05
-
+
Add to cart
10

BAND

Part #: 1UA-82591-00-00 Required per assembly: 1
$5.49
$4.05
-
+
Add to cart
11

RELAY ASSEMBLY (5UM-E0)

Part #: 5UM-81950-E0-00 Required per assembly: 2
$22.98
$18.13
-
+
Add to cart
12

HOLDER, RELAY

Part #: 5XT-81952-00-00 Required per assembly: 1
$11.49
$9.25
-
+
Add to cart
13

DAMPER

Part #: 3HT-82176-00-00 Required per assembly: 1
$12.49
$10.02
-
+
Add to cart
