Frame replacement parts for 2017 Yamaha VK Professional II

OEM Parts Yamaha 2017 Yamaha VK Professional II Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FRAME COMP. Part #: 8KW-21940-00-00 Required per assembly: 1 $2,587.74 - + Add to cart
2	BULKHEAD Part #: 8FN-W2197-02-00 Required per assembly: 1 $491.83 - + Add to cart
3	BUSH, SOLID Part #: 90381-15001-00 Required per assembly: 2 $6.49 $4.02 - + Add to cart
4	BUSH, SOLID Part #: 90381-16004-00 Required per assembly: 2 $18.48 $12.69 - + Add to cart
5	BULKHEAD 2 Part #: 8FN-Y291E-02-00 Required per assembly: 1 $585.13 $549.94 - + Add to cart
6	BUSH, SOLID Part #: 90381-15001-00 Required per assembly: 2 $6.49 $4.02 - + Add to cart
7	BUSH, SOLID Part #: 90381-16004-00 Required per assembly: 2 $18.48 $12.69 - + Add to cart
8	BOLT, FLANGE Part #: 90105-08072-00 Required per assembly: 4 $4.00 $3.33 - + Add to cart
9	NUT, SELF-LOCKING Part #: 90185-08169-00 Required per assembly: 4 $9.49 $6.97 - + Add to cart
10	BRACKET, STEERING, 1 Part #: 8FN-21947-00-00 Required per assembly: 1 $206.99 $193.37 - + Add to cart
11	NUT, SELF-LOCKING, (JN5) Part #: 95607-10200-00 Required per assembly: 4 $4.15 $3.27 - + Add to cart
12	PROTECTOR Part #: 8GS-2193A-01-00 Required per assembly: 1 $124.11 - + Add to cart
13	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 48 Note: (4.7X16.4 YELLOW) $4.20 $3.46 - + Add to cart
14	RIVET, BLIND, (4.8X16.4, YELLOW) Part #: 90267-48016-00 Required per assembly: 21 $11.49 $7.70 - + Add to cart
15	REINFORCEMENT, FRAME, 3 Part #: 8FN-2198E-00-00 Required per assembly: 1 $360.18 - + Add to cart
16	BRACKET, ENGINE, 2 Part #: 8FN-2194F-00-00 Required per assembly: 1 $44.99 $38.84 - + Add to cart
17	BRACKET, ENGINE, 3 Part #: 8FN-2194G-00-00 Required per assembly: 1 $104.98 $95.18 - + Add to cart
18	RIVET, BLIND, (4.8X16.4, YELLOW) Part #: 90267-48016-00 Required per assembly: 3 $11.49 $7.70 - + Add to cart
19	RIVET, BLIND, (48X14, YELLOW) Part #: 90267-48177-00 Required per assembly: 12 $2.60 $1.68 - + Add to cart
20	REAR FRAME COMP. Part #: 8KB-21950-00-00 Required per assembly: 1 $2,951.25 - + Add to cart
21	RIVET, BLIND, (4.8X12.1, YELLOW) Part #: 90267-48023-00 Required per assembly: 41 $11.49 $8.04 - + Add to cart
22	RIVET, BLIND, (48X14, YELLOW) Part #: 90267-48177-00 Required per assembly: 39 $2.60 $1.68 - + Add to cart
23	BRACKET, RRTRACK, SUSPENTION, 1 Part #: 8JE-21944-00-00 Required per assembly: 1 $95.31 - + Add to cart
24	BRACKET, RRTRACK, SUSPENTION, 2 Part #: 8JE-21954-00-00 Required per assembly: 1 $95.31 - + Add to cart
25	NUT, CROWN Part #: 90176-10033-00 Required per assembly: 6 $10.49 $7.88 - + Add to cart
26	PROTECTOR, MUFFLER Part #: 8FN-2194H-00-00 Required per assembly: 1 $55.99 $48.79 - + Add to cart
27	REINFORCEMENT, FOOTREST, 1 Part #: 8FN-21926-00-00 Required per assembly: 1 $194.99 $182.23 - + Add to cart
28	REINFORCEMENT, FOOTREST, 2 Part #: 8FN-21936-00-00 Required per assembly: 1 $194.99 $182.23 - + Add to cart
29	BRACKET, MAIN, TRACK, 1 Part #: 8JE-21943-00-00 Required per assembly: 1 $32.99 $27.37 - + Add to cart
30	BRACKET, MAIN, TRACK, 2 Part #: 8JE-21953-00-00 Required per assembly: 1 $32.99 $27.37 - + Add to cart
31	PATCH 2 Part #: 8FN-21962-01-00 Required per assembly: 2 $32.99 $28.64 - + Add to cart
32	PATCH 3 Part #: 8FN-21963-01-00 Required per assembly: 2 $32.99 $28.64 - + Add to cart
33	CLAMP (51Y) Part #: 90465-08277-00 Required per assembly: 7 $11.49 $7.87 - + Add to cart
34	BRACKET, MAIN, TRACK, 2 Part #: 8FN-21953-00-00 Required per assembly: 2 $4.15 $3.43 - + Add to cart
35	RIVET, BLIND, (48X121, BLACK) Part #: 90267-48026-00 Required per assembly: 52 $1.80 $1.51 - + Add to cart
36	RIVET, BLIND, (4.8X14, BLACK) Part #: 90267-48028-00 Required per assembly: 78 $1.75 $1.47 - + Add to cart
37	FRAME CONNECTION KIT Part #: 8KW-W2195-00-00 Required per assembly: 1 $231.99 $217.02 - + Add to cart
38	BRACKET, CHAIN, HOUSING Part #: 8CR-21939-01-00 Required per assembly: 1 $6.49 $5.26 - + Add to cart
39	BRACKET, CHAIN, HOUSING Part #: 8FN-21939-00-00 Required per assembly: 1 $9.99 $8.23 - + Add to cart
40	BRACKET, 5 Part #: 8KW-2196M-00-00 Required per assembly: 1 $55.99 $48.60 - + Add to cart
41	BRACKET, 6 Part #: 8KW-2197M-00-00 Required per assembly: 1 $53.99 $46.95 - + Add to cart
42	RIVET, BLIND, (4.8X18.6, BLACK) Part #: 90267-48018-00 Required per assembly: 4 Note: (4.8X18.6 BLACK) $10.49 $7.23 - + Add to cart
43	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 48 Note: (4.7X16.4 YELLOW) $4.20 $3.46 - + Add to cart
44	RIVET, BLIND, (4.8X16.4, YELLOW) Part #: 90267-48016-00 Required per assembly: 6 $11.49 $7.70 - + Add to cart
45	RIVET, BLIND, (4.8X12.1, YELLOW) Part #: 90267-48023-00 Required per assembly: 6 $11.49 $8.04 - + Add to cart
46	RIVET, BLIND, (48X14, YELLOW) Part #: 90267-48177-00 Required per assembly: 22 $2.60 $1.68 - + Add to cart
47	RIVET, BLIND, (4.8X16.4, YELLOW) Part #: 90267-48016-00 Required per assembly: 2 $11.49 $7.70 - + Add to cart
48	CLAMP, WIRE, HARNESS Part #: 8FA-21999-00-00 Required per assembly: 1 $10.99 $7.12 - + Add to cart
49	FOOTREST COMP. 1 Part #: 8KW-21960-00-00 Required per assembly: 1 $267.99 $261.61 - + Add to cart
50	FOOTREST COMP. 2 Part #: 8KW-21970-00-00 Required per assembly: 1 $232.99 $225.29 - + Add to cart
51	BRACKET, ENGINE Part #: 8FN-2194E-00-00 Required per assembly: 1 $253.99 $237.57 - + Add to cart
52	NUT, SELF-LOCKING Part #: 90185-08169-00 Required per assembly: 2 $9.49 $6.97 - + Add to cart
53	BOLT, FLANGE, (3HP) Part #: 95817-10016-00 Required per assembly: 1 $9.49 $6.05 - + Add to cart
54	HEAT EXCHANGER ASSEMBLY Part #: 8FN-12440-01-00 Required per assembly: 1 $601.61 $577.92 - + Add to cart
55	BOLT, FLANGE Part #: 95817-06016-00 Required per assembly: 1 $1.95 $1.47 - + Add to cart
56	WASHER, SEAL Part #: 90210-06006-00 Required per assembly: 1 Note: AP $9.49 $5.78 - + Add to cart
57	RIVET, BLIND, (4.8X16.4, YELLOW) Part #: 90267-48016-00 Required per assembly: 8 $11.49 $7.70 - + Add to cart
58	HOUSING, REINF, SUB-ASSEMBLY, (L.H) Part #: 8EK-21920-01-00 Required per assembly: 1 Note: (L.H) $21.98 $17.37 - + Add to cart
59	COVER 1 Part #: 8FU-2198F-01-00 Required per assembly: 1 $34.99 $26.73 - + Add to cart
60	COVER 3 Part #: 8FU-2198J-01-00 Required per assembly: 1 $34.99 $26.73 - + Add to cart
61	PLATE, STRG, BRACKET, 1 Part #: 8FU-2195E-01-00 Required per assembly: 1 $13.49 $11.34 - + Add to cart
62	PLATE, STRG, BRACKET, 2 Part #: 8FU-2195F-01-00 Required per assembly: 1 $13.49 $11.34 - + Add to cart
63	FRAME UNDER 1 Part #: 8KW-2196A-00-00 Required per assembly: 1 $301.21 - + Add to cart
64	FRAME, UNDER, 2 Part #: 8KW-2196E-00-00 Required per assembly: 1 $301.21 - + Add to cart
65	BRACKET, GUARD, FITTING Part #: 8FA-21972-01-00 Required per assembly: 1 $7.49 $6.17 - + Add to cart
66	BRACKET 3 Part #: 8FA-2196F-00-00 Required per assembly: 6 $7.49 $5.47 - + Add to cart
67	RIVET, BLIND, (4.8X15.2, SILVER) Part #: 90267-48083-00 Required per assembly: 8 Note: (4.8X15.2 SILVER) $3.60 $2.74 - + Add to cart
68	RIVET, BLIND, (4.8X18.6, BLACK) Part #: 90267-48018-00 Required per assembly: 14 Note: (4.8X18.6 BLACK) $10.49 $7.23 - + Add to cart
69	RIVET, BLIND, (4.7X16.4, BLACK) Part #: 90267-47187-00 Required per assembly: 4 $2.50 $1.86 - + Add to cart
70	BRACKET, FRONT, BUMPER, 1 Part #: 8KW-21949-00-00 Required per assembly: 1 $48.99 $42.73 - + Add to cart
71	BRACKET, FRONT, BUMPER, 2 Part #: 8KW-21959-00-00 Required per assembly: 1 $48.99 $42.73 - + Add to cart
72	STAY 1 Part #: 8FA-77125-00-00 Required per assembly: 2 $4.54 $3.78 - + Add to cart
73	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 2 Note: (4.7X16.4 YELLOW) $4.20 $3.46 - + Add to cart
74	BOLT, FLANGE Part #: 95814-08016-00 Required per assembly: 6 $10.49 $6.55 - + Add to cart
75	BOLT, FLANGE, (8AB) Part #: 95817-08020-00 Required per assembly: 2 $10.49 $6.86 - + Add to cart
76	RIVET, BLIND, (4.8X12.6, SILVER) Part #: 90267-48095-00 Required per assembly: 4 Note: (4.8X12.6 SILVER) $2.70 $1.97 - + Add to cart
77	PROTECTOR, FRAME, FR Part #: 8FR-2197E-00-00 Required per assembly: 1 $49.99 $41.69 - + Add to cart
78	BOLT, BUTTON, HEAD Part #: 92012-06012-00 Required per assembly: 2 $4.70 $2.45 - + Add to cart
79	FOOTREST, REAR, 1 Part #: 8JE-27431-00-00 Required per assembly: 2 $23.98 $19.66 - + Add to cart
80	BOLT, FLANGE Part #: 95817-06012-00 Required per assembly: 8 $1.95 $1.47 - + Add to cart
81	NUT, FLANGE, (4MV) Part #: 95707-06500-00 Required per assembly: 8 $1.00 $0.77 - + Add to cart
82	REINFORCEMENT, FRAME Part #: 8FN-21933-01-00 Required per assembly: 1 $75.98 $62.69 - + Add to cart
83	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 8 Note: (4.7X16.4 YELLOW) $4.20 $3.46 - + Add to cart
84	SEAL, 5 Part #: 8FN-241A5-00-00 Required per assembly: 1 $5.99 $4.81 - + Add to cart
