Front Fork replacement parts for 2017 Yamaha WR250R

OEM Parts Yamaha 2017 Yamaha WR250R Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (L.H) Part #: 32D-23102-50-00 Required per assembly: 1 $1,350.48 - + Add to cart
2	OUTER TUBE COMP. (L.H) Part #: 3D7-23106-50-00 Required per assembly: 1 ~~$740.99~~ $721.17 - + Add to cart
3	INNER TUBE COMP1 Part #: 3D7-23110-00-00 Required per assembly: 1 ~~$402.99~~ $390.72 - + Add to cart
4	PISTON, FRONT, FORK Part #: 5ET-23171-L0-00 Required per assembly: 1 ~~$23.98~~ $21.56 - + Add to cart
5	METAL, SLIDE, 1 Part #: 5ET-23125-L0-00 Required per assembly: 1 ~~$38.99~~ $28.53 - + Add to cart
6	WASHER, OIL, SEAL Part #: 5UN-23146-L0-00 Required per assembly: 1 ~~$17.98~~ $16.11 - + Add to cart
7	OIL SEAL Part #: 5UN-23145-L0-00 Required per assembly: 1 ~~$24.98~~ $21.81 - + Add to cart
8	RING, SNAP Part #: 4SS-23153-L0-00 Required per assembly: 1 ~~$8.49~~ $8.25 - + Add to cart
9	SEAL, DUST Part #: 5HD-23144-L0-00 Required per assembly: 1 ~~$33.99~~ $26.05 - + Add to cart
10	CYLINDER, COMP, FRONT, FORK Part #: 32D-23170-00-00 Required per assembly: 1 $469.66 - + Add to cart
11	VALVE COMP. Part #: 32D-2316A-00-00 Required per assembly: 1 ~~$280.99~~ $262.94 - + Add to cart
12	O-RING (3XJ-23147-00) Part #: 4DA-23147-L0-00 Required per assembly: 1 ~~$16.48~~ $15.97 - + Add to cart
13	GASKET Part #: 276-23114-01-00 Required per assembly: 1 $5.39 - + Add to cart
14	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $12.60 - + Add to cart
15	GUIDE, SPRING Part #: 3D7-23117-00-00 Required per assembly: 1 ~~$38.99~~ $33.48 - + Add to cart
16	NUT Part #: 3XJ-23357-L0-00 Required per assembly: 1 $1.42 - + Add to cart
17	SPRING, FRONT, FORK Part #: 32D-23141-00-00 Required per assembly: 1 ~~$59.99~~ $51.82 - + Add to cart
18	SEAT, SPRING, LOWER Part #: 4SS-23143-L0-00 Required per assembly: 1 $14.64 - + Add to cart
19	BOLT, CAP Part #: 3D7-23111-00-00 Required per assembly: 1 ~~$234.99~~ $220.16 - + Add to cart
20	O-RING Part #: 3D7-23147-00-00 Required per assembly: 1 ~~$7.49~~ $7.05 - + Add to cart
21	PLUG, HOLE Part #: 3JD-2312G-L0-00 Required per assembly: 1 $8.76 - + Add to cart
22	BOLT, FLANGE, (4KG) Part #: 95024-08040-00 Required per assembly: 2 ~~$9.49~~ $8.31 - + Add to cart
23	PROTECTER, GUIDE, COMP, 1 Part #: 5XC-2314F-00-00 Required per assembly: 1 ~~$52.99~~ $40.70 - + Add to cart
24	FRONT FORK ASSEMBLY (R.H) Part #: 32D-23103-50-00 Required per assembly: 1 $1,350.48 - + Add to cart
25	OUTER TUBE COMP. (L.H) Part #: 3D7-23106-50-00 Required per assembly: 1 ~~$740.99~~ $721.17 - + Add to cart
26	INNER TUBE COMP2 Part #: 3D7-23120-00-00 Required per assembly: 1 ~~$396.99~~ $387.37 - + Add to cart
27	PISTON, FRONT, FORK Part #: 5ET-23171-L0-00 Required per assembly: 1 ~~$23.98~~ $21.56 - + Add to cart
28	METAL, SLIDE, 1 Part #: 5ET-23125-L0-00 Required per assembly: 1 ~~$38.99~~ $28.53 - + Add to cart
29	WASHER, OIL, SEAL Part #: 5UN-23146-L0-00 Required per assembly: 1 ~~$17.98~~ $16.11 - + Add to cart
30	OIL SEAL Part #: 5UN-23145-L0-00 Required per assembly: 1 ~~$24.98~~ $21.81 - + Add to cart
31	RING, SNAP Part #: 4SS-23153-L0-00 Required per assembly: 1 ~~$8.49~~ $8.25 - + Add to cart
32	SEAL, DUST Part #: 5HD-23144-L0-00 Required per assembly: 1 ~~$33.99~~ $26.05 - + Add to cart
33	CYLINDER, COMP, FRONT, FORK Part #: 32D-23170-00-00 Required per assembly: 1 $469.66 - + Add to cart
34	VALVE COMP. Part #: 32D-2316A-00-00 Required per assembly: 1 ~~$280.99~~ $262.94 - + Add to cart
35	O-RING (3XJ-23147-00) Part #: 4DA-23147-L0-00 Required per assembly: 1 ~~$16.48~~ $15.97 - + Add to cart
36	GASKET Part #: 276-23114-01-00 Required per assembly: 1 $5.39 - + Add to cart
37	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $12.60 - + Add to cart
38	GUIDE, SPRING Part #: 3D7-23117-00-00 Required per assembly: 1 ~~$38.99~~ $33.48 - + Add to cart
39	NUT Part #: 3XJ-23357-L0-00 Required per assembly: 1 $1.42 - + Add to cart
40	SPRING, FRONT, FORK Part #: 32D-23141-00-00 Required per assembly: 1 ~~$59.99~~ $51.82 - + Add to cart
41	SEAT, SPRING, LOWER Part #: 4SS-23143-L0-00 Required per assembly: 1 $14.64 - + Add to cart
42	BOLT, CAP Part #: 3D7-23111-00-00 Required per assembly: 1 ~~$234.99~~ $220.16 - + Add to cart
43	O-RING Part #: 3D7-23147-00-00 Required per assembly: 1 ~~$7.49~~ $7.05 - + Add to cart
44	PLUG, HOLE Part #: 3JD-2312G-L0-00 Required per assembly: 1 $8.76 - + Add to cart
45	BOLT, FLANGE, (4KG) Part #: 95024-08040-00 Required per assembly: 2 ~~$9.49~~ $8.31 - + Add to cart
46	PROTECTER, GUIDE, COMP, 1 Part #: 5XC-2314F-00-00 Required per assembly: 1 ~~$52.99~~ $40.70 - + Add to cart
47	UNDER BRACKET COMP. Part #: 3D7-23340-00-00 Required per assembly: 1 ~~$670.99~~ $660.14 - + Add to cart
48	BOLT, FLANGE, (4KG) Part #: 95024-08040-00 Required per assembly: 4 ~~$9.49~~ $8.31 - + Add to cart
49	GUIDE, CABLE Part #: 3D7-2331E-00-00 Required per assembly: 1 ~~$10.99~~ $10.84 - + Add to cart
50	BRACKET, REFLECTOR, 1 Part #: 32D-85112-00-00 Required per assembly: 1 ~~$24.98~~ $21.79 - + Add to cart
51	BRACKET, REFLECTOR, 1 Part #: 32D-85112-10-00 Required per assembly: 1 ~~$24.98~~ $21.84 - + Add to cart
52	GUIDE, CABLE Part #: 5VK-23389-00-00 Required per assembly: 1 ~~$16.48~~ $14.16 - + Add to cart
53	BOLT, FLANGE Part #: 90105-05016-00 Required per assembly: 1 $6.05 - + Add to cart
54	PROTECTOR 1 (LEFT) Part #: 1C3-2315H-10-00 Required per assembly: 1 ~~$22.98~~ $19.71 - + Add to cart
55	EMBLEM, YAMAHA Part #: 4XL-2153A-11-00 Required per assembly: 1 ~~$10.99~~ $10.84 - + Add to cart
56	PROTECTOR 2 (RIGHT) Part #: 1C3-2315J-10-00 Required per assembly: 1 ~~$22.98~~ $19.71 - + Add to cart
57	EMBLEM, YAMAHA Part #: 4XL-2153A-11-00 Required per assembly: 1 ~~$10.99~~ $10.84 - + Add to cart
58	BOLT 2 Part #: 3SP-23356-L0-00 Required per assembly: 6 ~~$8.99~~ $5.24 - + Add to cart
59	CLAMP Part #: 3D7-23466-00-00 Required per assembly: 1 $14.90 - + Add to cart
60	CLAMP Part #: 3D7-23467-00-00 Required per assembly: 1 ~~$19.98~~ $18.32 - + Add to cart
61	NUT, CROWN Part #: 90176-06014-00 Required per assembly: 2 $8.59 - + Add to cart
