Electrical 1 replacement parts for 2017 Yamaha Bolt

OEM Parts Yamaha 2017 Yamaha Bolt Electrical 1

ELECTRICAL 1 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	OIL LEVEL GAUGE ASSEMBLY Part #: 5S7-85720-00-00 Required per assembly: 1 $120.98 $103.66 - + Add to cart
2	O-RING Part #: 5VY-8A8E0-00-00 Required per assembly: 1 $15.49 $10.75 - + Add to cart
3	BOLT, FLANGE Part #: 95022-06016-00 Required per assembly: 2 $3.89 $3.27 - + Add to cart
4	SWITCH, SIDE, STAND Part #: 1TP-82566-00-00 Required per assembly: 1 Not Available
5	BOLT, SOCKET Part #: 91317-05016-00 Required per assembly: 2 $3.54 $2.43 - + Add to cart
6	STOP SWITCH ASSY Part #: BP6-82530-01-00 Required per assembly: 1 $45.99 $36.29 - + Add to cart
7	NEUTRAL SWITCH ASSEMBLY Part #: 3GB-82540-01-00 Required per assembly: 1 $63.99 $52.60 - + Add to cart
8	WIRE, SUB, LEAD Part #: 5S7-82509-10-00 Required per assembly: 1 $7.99 $6.49 - + Add to cart
9	CLAMP Part #: 90464-13077-00 Required per assembly: 2 $9.49 $6.55 - + Add to cart
10	GASKET Part #: 90430-10148-00 Required per assembly: 1 $5.99 $4.81 - + Add to cart
11	BRACKET, COIL Part #: 3D8-21359-01-00 Required per assembly: 1 $31.98 $26.49 - + Add to cart
12	IGNITION COIL ASSEMBLY Part #: 1TP-82310-00-00 Required per assembly: 1 Not Available
13	IGNITION COIL ASSEMBLY Part #: 1S4-82310-03-00 Required per assembly: 1 $56.99 $46.60 - + Add to cart
14	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-06020-00 Required per assembly: 4 $2.64 $2.01 - + Add to cart
15	PLUG CAP ASSEMBLY Part #: 5S7-82370-00-00 Required per assembly: 2 $78.98 $67.34 - + Add to cart
16	HOSE (L65) Part #: 90445-14020-00 Required per assembly: 1 Note: (L65) $3.79 $3.55 - + Add to cart
17	HOSE Part #: 90445-08029-00 Required per assembly: 2 $3.20 $3.08 - + Add to cart
18	BOLT, HEXAGON, SOCKET, HEAD Part #: 91312-06008-00 Required per assembly: 2 $0.40 $0.36 - + Add to cart
19	CLAMP Part #: 90464-09129-00 Required per assembly: 1 $2.22 $1.74 - + Add to cart
20	CLAMP Part #: 90464-09008-00 Required per assembly: 1 $3.20 $3.08 - + Add to cart
21	ENGINE CONTROL UNIT ASSEMBLY Part #: 1TP-8591A-00-00 Required per assembly: 1 $997.35 $906.69 - + Add to cart
22	SENSOR, SPEED Part #: 1TP-83755-00-00 Required per assembly: 1 $84.98 $71.05 - + Add to cart
23	O-RING Part #: 4D9-81168-00-00 Required per assembly: 1 $7.49 $4.25 - + Add to cart
24	BOLT (33M) Part #: 91312-06014-00 Required per assembly: 1 $5.49 $4.66 - + Add to cart
25	BRACKET Part #: 1TP-81948-00-00 Required per assembly: 1 $49.99 $43.20 - + Add to cart
26	PIN, DOWEL(6G8) Part #: 99530-08012-00 Required per assembly: 2 $6.59 $6.18 - + Add to cart
27	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-06300-00 Required per assembly: 2 $3.39 $2.81 - + Add to cart
28	THERMO UNIT Part #: 52B-H3591-00-00 Required per assembly: 1 $37.99 $28.37 - + Add to cart
29	WASHER PLATE 341839090000 Part #: 90201-10128-00 Required per assembly: 1 $4.04 $3.36 - + Add to cart
30	SENSOR, AIR, TEMPERATURE Part #: 5YU-85886-00-00 Required per assembly: 1 $37.99 $29.56 - + Add to cart
31	WIRE, SUB, LEAD Part #: B33-82509-00-00 Required per assembly: 1 $15.49 $12.70 - + Add to cart
32	CLAMP Part #: 90464-13227-00 Required per assembly: 1 $8.49 $6.49 - + Add to cart
33	SCREW, PAN, HEAD Part #: 98517-05012-00 Required per assembly: 1 $5.49 $3.84 - + Add to cart
34	CLAMP, LEAD, 1 Part #: 1TP-81443-00-00 Required per assembly: 1 $4.84 $4.02 - + Add to cart
35	CLAMP Part #: 90464-20258-00 Required per assembly: 1 $5.59 $4.08 - + Add to cart
36	FLASHER RELAY ASSEMBLY Part #: 5S7-83350-01-00 Required per assembly: 1 $107.98 $92.55 - + Add to cart
37	HORN Part #: 2S3-83371-00-00 Required per assembly: 1 $65.98 $54.81 - + Add to cart
38	BOLT, FLANGE Part #: 90105-082A5-00 Required per assembly: 1 $3.79 $2.68 - + Add to cart
