OEM Parts Yamaha 2017 Yamaha Wolverine EPS Shift Cam Fork

2017 Yamaha Wolverine EPS YXE70WPBHL - Shift Cam Fork

SHIFT CAM FORK Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

SHIFT CAM ASSEMBLY

Part #: 1XD-18540-00-00 Required per assembly: 1
$138.99
$125.25
-
+
Add to cart
2

SPRING COMPRESSION278185450000

Part #: 90501-06022-00 Required per assembly: 1 Note: (USA)
$9.49
$6.05
-
+
Add to cart
3

POINT, NEUTRAL

Part #: 5KM-18542-00-00 Required per assembly: 1 Note: (USA)
$16.48
$12.46
-
+
Add to cart
4

PLATE, SIDE, 2

Part #: 4UN-18566-00-00 Required per assembly: 1 Note: (USA)
$21.98
$16.99
-
+
Add to cart
5

SCREW

Part #: 90149-05015-00 Required per assembly: 1
$6.49
$5.16
-
+
Add to cart
6

FORK, SHIFT, 1

Part #: 2MB-E8511-00-00 Required per assembly: 1
$101.98
$91.94
-
+
Add to cart
7

FORK, SHIFT, 2

Part #: 2MB-E8512-00-00 Required per assembly: 1
$113.98
$103.33
-
+
Add to cart
8

BAR, SHIFT, FORK, GUIDE, 1

Part #: 5B4-18531-00-00 Required per assembly: 1
$42.99
$34.07
-
+
Add to cart
9

SPRING

Part #: 2MB-E8123-00-00 Required per assembly: 1
$8.49
$6.92
-
+
Add to cart
10

CIRCLIP 2

Part #: 2MB-E5597-00-00 Required per assembly: 2
$1.70
$1.42
-
+
Add to cart
11

BALL

Part #: 2MB-E8218-00-00 Required per assembly: 1
$1.60
$1.21
-
+
Add to cart
12

SPRING

Part #: 2MB-E8143-00-00 Required per assembly: 1
$4.95
$4.13
-
+
Add to cart
13

BOLT, FLANGE

Part #: 90105-14003-00 Required per assembly: 1
$9.49
$6.50
-
+
Add to cart
14

GASKET

Part #: 2MB-E8363-00-00 Required per assembly: 1
$3.10
$2.57
-
+
Add to cart
15

PLUG, BLIND

Part #: 2MB-E8149-00-00 Required per assembly: 1
$2.79
$2.36
-
+
Add to cart
16

GASKET

Part #: 2MB-E1198-00-00 Required per assembly: 1
$3.00
$2.39
-
+
Add to cart
