Front Fork replacement parts for 2017 Yamaha YZ125

OEM Parts Yamaha 2017 Yamaha YZ125 Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (L.H Part #: 1SR-23102-00-00 Required per assembly: 1 $1,789.29 $1,635.62 - + Add to cart
2	TUBE, OUTER, 2 Part #: 1SS-23136-00-00 Required per assembly: 1 $649.99 $638.80 - + Add to cart
3	RING, SNAP Part #: 17D-23153-00-00 Required per assembly: 1 $5.49 $4.10 - + Add to cart
4	INNER TUBE COMP.2 Part #: 1SS-23120-00-00 Required per assembly: 1 $504.99 $485.14 - + Add to cart
5	PISTON, FRONT, FORK Part #: 5XE-23171-L0-00 Required per assembly: 1 $30.98 $20.32 - + Add to cart
6	METAL, SLIDE, 1 Part #: 5XE-23125-L0-00 Required per assembly: 1 $28.98 $20.64 - + Add to cart
7	WASHER, OIL, SEAL Part #: 5XC-23146-10-00 Required per assembly: 1 $15.49 $10.07 - + Add to cart
8	OIL SEAL Part #: 17D-23145-00-00 Required per assembly: 1 $30.98 $22.38 - + Add to cart
9	RING, SNAP Part #: 5XE-23153-L0-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
10	SEAL, DUST Part #: 5XE-23144-L0-00 Required per assembly: 1 $24.98 $18.93 - + Add to cart
11	CYLINDER, COMP., FRONT, FORK Part #: 1SR-23170-00-00 Required per assembly: 1 $814.99 $804.14 - + Add to cart
12	O-RING Part #: 1C3-23147-L1-00 Required per assembly: 1 $3.75 $3.14 - + Add to cart
13	SEAT, SPRING, UPPER Part #: 17D-23142-00-00 Required per assembly: 1 $80.98 $67.44 - + Add to cart
14	VALVE COMP. Part #: 1SS-2316A-00-00 Required per assembly: 1 $412.99 $403.39 - + Add to cart
15	O-RING Part #: 1C3-23188-L1-00 Required per assembly: 1 $3.20 $2.69 - + Add to cart
16	O-RING Part #: 1C3-23188-N0-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
17	O-RING Part #: 1C3-23188-P0-00 Required per assembly: 1 $7.49 $6.31 - + Add to cart
18	GASKET Part #: 1W4-23114-L0-00 Required per assembly: 2 $8.49 $7.30 - + Add to cart
19	AIR VALVE COMP. Part #: 1C3-23190-L1-00 Required per assembly: 1 $25.98 $19.70 - + Add to cart
20	O-RING Part #: 1C3-23188-R1-00 Required per assembly: 1 $4.29 $2.69 - + Add to cart
21	SPRING, FRONT, FORK, (K=4.1N/MM) Part #: 1C3-23141-C1-00 Required per assembly: 1 Note: AP Not Available
22	BOLT, CAP Part #: 5XC-23111-01-00 Required per assembly: 1 $78.98 $65.77 - + Add to cart
23	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $11.99 $9.62 - + Add to cart
24	GASKET Part #: 276-23114-01-00 Required per assembly: 1 $4.59 $3.81 - + Add to cart
25	FRONT FORK ASSEMBLY (R.H Part #: 1SR-23103-00-00 Required per assembly: 1 $1,789.29 $1,635.62 - + Add to cart
26	TUBE, OUTER, 2 Part #: 1SS-23136-00-00 Required per assembly: 1 $649.99 $638.80 - + Add to cart
27	RING, SNAP Part #: 17D-23153-00-00 Required per assembly: 1 $5.49 $4.10 - + Add to cart
28	INNER TUBE COMP.1 Part #: 1SS-23110-00-00 Required per assembly: 1 $519.99 $497.92 - + Add to cart
29	PISTON, FRONT, FORK Part #: 5XE-23171-L0-00 Required per assembly: 1 $30.98 $20.32 - + Add to cart
30	METAL, SLIDE, 1 Part #: 5XE-23125-L0-00 Required per assembly: 1 $28.98 $20.64 - + Add to cart
31	WASHER, OIL, SEAL Part #: 5XC-23146-10-00 Required per assembly: 1 $15.49 $10.07 - + Add to cart
32	OIL SEAL Part #: 17D-23145-00-00 Required per assembly: 1 $30.98 $22.38 - + Add to cart
33	RING, SNAP Part #: 5XE-23153-L0-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
34	SEAL, DUST Part #: 5XE-23144-L0-00 Required per assembly: 1 $24.98 $18.93 - + Add to cart
35	CYLINDER, COMP., FRONT, FORK Part #: 1SR-23170-00-00 Required per assembly: 1 $814.99 $804.14 - + Add to cart
36	O-RING Part #: 1C3-23147-L1-00 Required per assembly: 1 $3.75 $3.14 - + Add to cart
37	SEAT, SPRING, UPPER Part #: 17D-23142-00-00 Required per assembly: 1 $80.98 $67.44 - + Add to cart
38	VALVE COMP. Part #: 1SS-2316A-00-00 Required per assembly: 1 $412.99 $403.39 - + Add to cart
39	O-RING Part #: 1C3-23188-L1-00 Required per assembly: 1 $3.20 $2.69 - + Add to cart
40	O-RING Part #: 1C3-23188-N0-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
41	O-RING Part #: 1C3-23188-P0-00 Required per assembly: 1 $7.49 $6.31 - + Add to cart
42	GASKET Part #: 1W4-23114-L0-00 Required per assembly: 2 $8.49 $7.30 - + Add to cart
43	AIR VALVE COMP. Part #: 1C3-23190-L1-00 Required per assembly: 1 $25.98 $19.70 - + Add to cart
44	O-RING Part #: 1C3-23188-R1-00 Required per assembly: 1 $4.29 $2.69 - + Add to cart
45	SPRING, FRONT, FORK, (K=4.1N/MM) Part #: 1C3-23141-C1-00 Required per assembly: 1 Note: AP Not Available
46	BOLT, CAP Part #: 5XC-23111-01-00 Required per assembly: 1 $78.98 $65.77 - + Add to cart
47	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $11.99 $9.62 - + Add to cart
48	GASKET Part #: 276-23114-01-00 Required per assembly: 1 $4.59 $3.81 - + Add to cart
49	UNDER BRACKET COMP. Part #: 1SR-23340-00-00 Required per assembly: 1 $582.97 $542.97 - + Add to cart
50	BEARING (4SR) Part #: 93332-00081-00 Required per assembly: 1 $63.99 - + Add to cart
51	BOLT, FLANGE Part #: 90105-08154-00 Required per assembly: 8 $8.49 $5.67 - + Add to cart
52	GUIDE, CABLE Part #: 1SS-23389-00-00 Required per assembly: 1 $4.34 $3.14 - + Add to cart
53	BOLT, FLANGE Part #: 90105-06107-00 Required per assembly: 1 $9.49 $6.05 - + Add to cart
54	COLLAR Part #: 90387-06104-00 Required per assembly: 1 $1.60 $1.30 - + Add to cart
55	PROTECTOR 2 Part #: 17D-2315J-50-00 Required per assembly: 1 $24.41 - + Add to cart
56	PROTECTOR 1 Part #: 17D-2315H-50-00 Required per assembly: 1 $24.41 - + Add to cart
57	BOLT Part #: 90109-06232-00 Required per assembly: 6 $4.15 $3.43 - + Add to cart
58	CLAMP Part #: 17D-23466-00-00 Required per assembly: 1 $18.98 $15.74 - + Add to cart
59	CLAMP Part #: 17D-23467-00-00 Required per assembly: 1 $27.98 $21.55 - + Add to cart
60	BOLT, FLANGE Part #: 90105-06170-00 Required per assembly: 2 $5.49 $4.16 - + Add to cart
61	FORK SEALS KIT Part #: 17D-W003B-00-00 Required per assembly: 1 $105.55 $95.95 - + Add to cart
