2017 Yamaha YZFR1M YZFR1MH - Front Fork

FRONT FORK Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

FRONT FORK ASSEMBLY (L.H

Part #: 2KS-23102-00-00 Required per assembly: 1
$1,944.78
$1,775.98
-
+
Add to cart
2

INNER TUBE COMP.1

Part #: 2KS-23110-00-00 Required per assembly: 1
$739.04
$683.86
-
+
Add to cart
3

FORK SEAL COVER KIT

Part #: 2KS-231E0-00-00 Required per assembly: 1
$143.99
$124.04
-
+
Add to cart
4

OUTER TUBE COMP.

Part #: 2KS-23106-00-00 Required per assembly: 1
$736.99
$728.18
-
+
Add to cart
5

NUT, HEXAGON

Part #: 90170-12060-00 Required per assembly: 1
$10.49
$8.13
-
+
Add to cart
6

BOLT, CAP

Part #: 2KS-23111-00-00 Required per assembly: 1
$463.99
$453.46
-
+
Add to cart
7

O-RING

Part #: 93210-41N50-00 Required per assembly: 1
$9.49
$6.15
-
+
Add to cart
8

FRONT FORK ASSEMBLY (R.H

Part #: 2KS-23103-00-00 Required per assembly: 1
$1,944.78
$1,775.98
-
+
Add to cart
9

INNER TUBE COMP.2

Part #: 2KS-23120-00-00 Required per assembly: 1
$739.04
$683.86
-
+
Add to cart
10

FORK SEAL COVER KIT

Part #: 2KS-231E0-00-00 Required per assembly: 1
$143.99
$124.04
-
+
Add to cart
11

OUTER TUBE COMP.

Part #: 2KS-23106-00-00 Required per assembly: 1
$736.99
$728.18
-
+
Add to cart
12

NUT, HEXAGON

Part #: 90170-12060-00 Required per assembly: 1
$10.49
$8.13
-
+
Add to cart
13

BOLT, CAP

Part #: 2KS-23111-00-00 Required per assembly: 1
$463.99
$453.46
-
+
Add to cart
14

O-RING

Part #: 93210-41N50-00 Required per assembly: 1
$9.49
$6.15
-
+
Add to cart
15

UNDER BRACKET COMP.

Part #: 2CR-23340-00-00 Required per assembly: 1
$596.99
$581.65
-
+
Add to cart
16

BOLT, HEXAGON, SOCKET, HEAD

Part #: 91314-08030-00 Required per assembly: 4
$2.54
$2.25
-
+
Add to cart
17

PROTECTOR

Part #: 5PW-23472-00-00 Required per assembly: 1
$16.48
$11.64
-
+
Add to cart
