Electrical 2 replacement parts for 2017 Yamaha R3

OEM Parts Yamaha 2017 Yamaha R3 Electrical 2

ELECTRICAL 2 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	ENGINE CONTROL UNIT ASSEMBLY Part #: 2MS-H591A-01-00 Required per assembly: 1 $356.99 $346.94 - + Add to cart
2	BAND Part #: 1WD-H5546-00-00 Required per assembly: 1 $7.49 $5.85 - + Add to cart
3	NEUTRAL SWITCH ASSEMBLY Part #: 1WD-H2540-00-00 Required per assembly: 1 $35.99 $31.03 - + Add to cart
4	O-RING (1S71) Part #: 93210-21801-00 Required per assembly: 1 $1.55 $1.51 - + Add to cart
5	SCREW, PAN, HEAD, (JJ6) Part #: 98507-05016-00 Required per assembly: 2 $1.80 $1.38 - + Add to cart
6	THERMO UNIT Part #: 52B-H3591-00-00 Required per assembly: 1 $37.99 $28.37 - + Add to cart
7	GASKET Part #: 90430-10804-00 Required per assembly: 1 $5.49 $4.25 - + Add to cart
8	SENSOR OXYGEN Part #: 1WD-H592A-10-00 Required per assembly: 1 $100.98 $90.34 - + Add to cart
9	SENSOR, SPEED Part #: 1WD-H3755-00-00 Required per assembly: 1 $92.98 $89.57 - + Add to cart
10	SPACER, ENGINE, MOUNT Part #: 2MS-E5317-00-00 Required per assembly: 1 Not Available
11	BOLT, HEXAGON, SOCKET, HEAD Part #: 91312-06016-00 Required per assembly: 1 $6.49 $4.81 - + Add to cart
12	OIL PRESSURE SWITCH ASSEMBLY Part #: 1WS-82504-01-00 Required per assembly: 1 $76.98 $65.92 - + Add to cart
13	LEAD WIRE ASSEMBLY Part #: 1WD-H1315-01-00 Required per assembly: 1 $16.48 $14.89 - + Add to cart
14	COVER Part #: 1WD-H1961-00-00 Required per assembly: 1 Not Available
15	BOLT, FLANGE Part #: 95817-06016-00 Required per assembly: 2 $1.95 $1.47 - + Add to cart
16	RECTIFIER & REGULATOR ASSEMBLY Part #: 1WD-H1960-00-00 Required per assembly: 1 $118.98 $96.33 - + Add to cart
17	BOLT, FLANGE Part #: 95817-06025-00 Required per assembly: 2 $1.75 $1.44 - + Add to cart
18	STOP SWITCH ASSEMBLY Part #: 1WD-H2530-10-00 Required per assembly: 1 $53.39 $48.54 - + Add to cart
19	SENSOR, LEAN, ANGLE Part #: 1WD-H2576-00-00 Required per assembly: 1 $86.98 $64.11 - + Add to cart
20	SCREW, ROUND, TAPPING Part #: 90160-04009-00 Required per assembly: 2 $8.49 $5.10 - + Add to cart
21	WASHER, PLATE Part #: 90201-04028-00 Required per assembly: 2 $9.49 $6.18 - + Add to cart
22	NUT, ADJUSTING Part #: 4B4-84334-00-00 Required per assembly: 2 $5.49 $3.96 - + Add to cart
23	FLASHER RELAY ASSEMBLY Part #: 4VR-83350-01-00 Required per assembly: 1 Not Available
24	HORN Part #: 1WD-H3371-00-00 Required per assembly: 1 $34.99 $29.64 - + Add to cart
25	BOLT, FLANGE Part #: 95817-08012-00 Required per assembly: 1 $5.49 $3.90 - + Add to cart
26	STAY, HORN Part #: 1WD-H3378-00-00 Required per assembly: 1 $26.98 $22.95 - + Add to cart
27	BOLT, FLANGE Part #: 95817-06016-00 Required per assembly: 2 $1.95 $1.47 - + Add to cart
28	REAR REFLECTOR ASSEMBLY (3C11) Part #: 3C1-H5130-00-00 Required per assembly: 1 $4.20 $3.02 - + Add to cart
29	NUT, U Part #: 95617-05100-00 Required per assembly: 1 $10.49 $6.55 - + Add to cart
30	WASHER, PLATE Part #: 90201-05043-00 Required per assembly: 1 $8.49 $5.16 - + Add to cart
31	BRACKET, LICENSE Part #: 2MS-H4751-00-00 Required per assembly: 1 $14.49 $12.22 - + Add to cart
32	WASHER, PLATE Part #: 90201-06055-00 Required per assembly: 2 $3.20 $3.08 - + Add to cart
33	NUT, U, FLANGE Part #: 95604-06200-00 Required per assembly: 2 $2.95 $2.31 - + Add to cart
34	REAR REFLECTOR ASSEMBLY (3C11) Part #: 3C1-H5130-00-00 Required per assembly: 2 $4.20 $3.02 - + Add to cart
35	NUT, FLANGE, 3GM, (BLACK) Part #: 95707-05500-00 Required per assembly: 2 $9.49 $6.06 - + Add to cart
