OEM Parts Honda 2018 Honda CRF125FB Gearshift Drum

2018 Honda CRF125FB - Gearshift Drum

GEARSHIFT DRUM Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
E 19
001

FORK, R., GEARSHIFT

Part #: 24211-KWS-900 Required per assembly: 1
$57.93
$46.89
-
+
Add to cart
002

FORK, L., GEARSHIFT

Part #: 24212-KWS-900 Required per assembly: 1
$57.93
$46.89
-
+
Add to cart
003

SHAFT

Part #: 24241-KPH-C00 Required per assembly: 1
$12.60
$10.19
-
+
Add to cart
004

DRUM, GEARSHIFT

Part #: 24301-KWS-900 Required per assembly: 1
$87.62
$70.92
-
+
Add to cart
005

PLATE SET

Part #: 24410-KVS-305 Required per assembly: 1
$28.04
$23.40
-
+
Add to cart
006

STOPPER

Part #: 24430-KRM-B10 Required per assembly: 1
$13.53
$10.95
-
+
Add to cart
007

SPRING, DRUM, STOPPER

Part #: 24436-KTT-900 Required per assembly: 1
$4.07
-
+
Add to cart
008

SPINDLE, GEARSHIFT

Part #: 24610-KYY-900 Required per assembly: 1
$93.73
$75.86
-
+
Add to cart
009

SPRING

Part #: 24651-KSP-910 Required per assembly: 1
$4.97
-
+
Add to cart
010

PIN

Part #: 24652-KRM-840 Required per assembly: 1
$7.49
$6.82
-
+
Add to cart
011

ROTOR

Part #: 35753-KWS-900 Required per assembly: 1
$5.94
$5.31
-
+
Add to cart
012

BOLT, HEX., (6X20)

Part #: 90003-KVS-900 Required per assembly: 1
$3.01
$2.80
-
+
Add to cart
013

PIVOT

Part #: 90022-KRM-840 Required per assembly: 1
$2.44
$2.26
-
+
Add to cart
014

WASHER, DRUM, STOPPER

Part #: 90417-360-000 Required per assembly: 1
$2.73
$2.54
-
+
Add to cart
015

WASHER (14MM)

Part #: 90457-KRM-840 Required per assembly: 1
$1.80
$1.67
-
+
Add to cart
016

CIRCLIP (14MM)

Part #: 94510-14000 Required per assembly: 1
$2.06
$1.90
-
+
Add to cart
017

ROLLER (3X8.5)

Part #: 96220-30085 Required per assembly: 2
$1.60
$1.46
-
+
Add to cart
