Alternator Cover replacement parts for 2018 Honda SXS1000M3P

OEM Parts Honda 2018 Honda SXS1000M3P Alternator Cover

ALTERNATOR COVER Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

E 05
001	GASKET Part #: 11396-HL4-003 Required per assembly: 1 ~~$13.47~~ $10.74 - + Add to cart
002	COVER, ALTERNATOR Part #: 11400-HL4-020 Required per assembly: 1 ~~$388.76~~ $339.10 - + Add to cart
003	CAP, TAPT, ADJ, HOLE Part #: 12361-HP5-600 Required per assembly: 1 ~~$21.44~~ $17.88 - + Add to cart
004	COVER, WATER, PUMP Part #: 19220-HL4-000 Required per assembly: 1 ~~$114.29~~ $92.51 - + Add to cart
005	GASKET Part #: 19226-HL4-000 Required per assembly: 1 ~~$12.53~~ $10.44 - + Add to cart
006	HOSE, DRAIN Part #: 19503-HL4-000 Required per assembly: 1 ~~$13.16~~ $10.98 - + Add to cart
007	STAY, WATER, HOSE Part #: 19510-HL4-000 Required per assembly: 1 $4.15 - + Add to cart
008	STAY, SENSOR, WIRE Part #: 32158-HL4-000 Required per assembly: 1 ~~$5.64~~ $5.23 - + Add to cart
009	STAY Part #: 32159-HL4-000 Required per assembly: 1 ~~$11.19~~ $9.87 - + Add to cart
010	STAY, HARNESS, CLIP Part #: 32163-HL4-000 Required per assembly: 1 $4.31 - + Add to cart
011	CAP (14MM) Part #: 90084-MN8-010 Required per assembly: 1 ~~$14.86~~ $12.38 - + Add to cart
012	WASHER (6MM) Part #: 90441-706-000 Required per assembly: 1 ~~$2.19~~ $2.03 - + Add to cart
013	BEARING (6000) Part #: 91014-HL4-003 Required per assembly: 1 ~~$13.64~~ $11.37 - + Add to cart
014	BEARING (6906) Part #: 91015-HL4-003 Required per assembly: 1 ~~$21.65~~ $17.53 - + Add to cart
015	O-RING (35.5X3) Part #: 91301-428-003 Required per assembly: 1 ~~$3.18~~ $2.96 - + Add to cart
016	O-RING (13.8X2.5) Part #: 91303-377-000 Required per assembly: 1 ~~$4.75~~ $4.32 - + Add to cart
017	PIN, DOWEL, (8X7) Part #: 91320-KE1-000 Required per assembly: 2 ~~$3.19~~ $2.97 - + Add to cart
018	PIN, DOWEL, (8X14) Part #: 94301-08140 Required per assembly: 2 ~~$3.21~~ $2.99 - + Add to cart
019	CLIP, TUBE, (B12) Part #: 95002-02120 Required per assembly: 1 ~~$2.98~~ $2.77 - + Add to cart
020	BOLT, FLANGE, (6X25) Part #: 95701-06025-00 Required per assembly: 5 ~~$2.79~~ $2.60 - + Add to cart
021	BOLT, FLANGE, (6X28) Part #: 95701-06028-00 Required per assembly: 11 ~~$2.81~~ $2.61 - + Add to cart
