Front Fork replacement parts for 2018 Kawasaki KX 450F

OEM Parts Kawasaki 2018 Kawasaki KX 450F Front Fork

Front Fork Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

11065	CAP, AIR, VALVE Part #: 11065-0873 Required per assembly: 1 $3.40 - + Add to cart
11065A	CAP, CHAMBER, G.B.GREEN Part #: 11065-0963-50Y Required per assembly: 1 ~~$107.40~~ $96.21 - + Add to cart
32085	STOPPER, RING Part #: 32085-0773 Required per assembly: 2 $6.55 - + Add to cart
32085A	STOPPER Part #: 32085-0782 Required per assembly: 1 $6.59 - + Add to cart
44008	PIPE-FORK OUTER Part #: 44008-0083 Required per assembly: 2 ~~$526.68~~ $517.66 - + Add to cart
44013	PIPE-FORK, INNER, RH Part #: 44013-0279 Required per assembly: 1 ~~$586.30~~ $569.86 - + Add to cart
44013A	PIPE-FORK, INNER, LH Part #: 44013-0308 Required per assembly: 1 ~~$586.30~~ $569.86 - + Add to cart
44025	RING-FORK PISTON Part #: 44025-0012 Required per assembly: 1 ~~$20.39~~ $19.75 - + Add to cart
44037	HOLDER-FORK, UNDER, F.BLACK Part #: 44037-0164-21 Required per assembly: 1 ~~$623.89~~ $599.65 - + Add to cart
44039	HOLDER-FORK, UPPER, F.BLACK Part #: 44039-0161-21 Required per assembly: 1 ~~$256.02~~ $247.06 - + Add to cart
44065	BUSHING-FRONT, FORK, SLIDE Part #: 44065-0018 Required per assembly: 2 $9.33 - + Add to cart
44065A	BUSHING-FRONT FORK Part #: 44065-0049 Required per assembly: 2 $15.95 - + Add to cart
44065B	BUSHING-FRONT FORK Part #: 44065-0050 Required per assembly: 2 $15.49 - + Add to cart
44071	DAMPER-ASSEMBLY, FORK, LH, GR+BLK+BLK Part #: 44071-1195-56B Required per assembly: 1 $2,498.17 - + Add to cart
44071A	DAMPER-ASSEMBLY, FORK, RH, GR+BLK+BLK Part #: 44071-1196-56B Required per assembly: 1 $2,063.03 - + Add to cart
44071B	DAMPER-ASSEMBLY, COMP Part #: 44071-1238 Required per assembly: 1 ~~$679.90~~ $646.99 - + Add to cart
46102	ROD, G.B.GREEN Part #: 46102-0623-50Y Required per assembly: 1 ~~$994.28~~ $989.43 - + Add to cart
46102A	ROD, PUSH Part #: 46102-0624 Required per assembly: 1 $11.90 - + Add to cart
49116	VALVE, ASSEMBLY, AIR Part #: 49116-0040 Required per assembly: 2 $2.22 - + Add to cart
55020	GUARD, FORK, LH, EBONY Part #: 55020-1938-6C Required per assembly: 1 ~~$61.20~~ $54.48 - + Add to cart
55020A	GUARD, FORK, RH, EBONY Part #: 55020-1939-6C Required per assembly: 1 ~~$61.20~~ $54.48 - + Add to cart
56071	LABEL-WARNING Part #: 56071-0496 Required per assembly: 1 $24.45 - + Add to cart
92026	SPACER, SEAL Part #: 92026-0785 Required per assembly: 2 $4.75 - + Add to cart
92033	RING-SNAP Part #: 92033-0751 Required per assembly: 2 $6.71 - + Add to cart
92049	SEAL-OIL Part #: 92049-0768 Required per assembly: 2 ~~$33.10~~ $30.15 - + Add to cart
92055	RING-O Part #: 92055-0093 Required per assembly: 1 $4.52 - + Add to cart
92055A	RING-O Part #: 92055-0094 Required per assembly: 1 $3.12 - + Add to cart
92055B	RING-O Part #: 92055-0744 Required per assembly: 2 $4.17 - + Add to cart
92055C	RING-O Part #: 92055-0799 Required per assembly: 1 $4.05 - + Add to cart
92055D	RING-O Part #: 92055-0800 Required per assembly: 1 $1.87 - + Add to cart
92055E	RING-O Part #: 92055-0801 Required per assembly: 1 $1.70 - + Add to cart
92055F	RING-O Part #: 92055-0802 Required per assembly: 1 $6.25 - + Add to cart
92055G	RING-O Part #: 92055-0804 Required per assembly: 1 $1.87 - + Add to cart
92055H	RING-O Part #: 92055-0807 Required per assembly: 1 $6.19 - + Add to cart
92055I	RING-O Part #: 92055-0877 Required per assembly: 1 $5.35 - + Add to cart
92055J	RING-O Part #: 92055-0895 Required per assembly: 2 $6.25 - + Add to cart
92093	SEAL Part #: 92093-0657 Required per assembly: 2 ~~$21.97~~ $20.93 - + Add to cart
92150	BOLT, FLANGED, 6X14 Part #: 92150-1505 Required per assembly: 6 $5.63 - + Add to cart
92153	BOLT, FLANGED Part #: 92153-1397 Required per assembly: 1 $4.46 - + Add to cart
92153A	BOLT, PLUG Part #: 92153-1398 Required per assembly: 1 $3.48 - + Add to cart
92153B	BOLT, FLANGED, 8X40 Part #: 92153-1399 Required per assembly: 4 $5.22 - + Add to cart
92154	BOLT Part #: 92154-0463 Required per assembly: 4 $4.98 - + Add to cart
92154A	BOLT Part #: 92154-0464 Required per assembly: 4 $4.09 - + Add to cart
92154B	BOLT, SEALING Part #: 92154-1500 Required per assembly: 1 ~~$31.30~~ $28.06 - + Add to cart
92154C	BOLT Part #: 92154-1904 Required per assembly: 1 ~~$66.29~~ $60.36 - + Add to cart
92154D	BOLT, CNT Part #: 92154-2286 Required per assembly: 1 ~~$44.38~~ $39.98 - + Add to cart
92154E	BOLT, G.B.GREEN Part #: 92154-2287-50Y Required per assembly: 1 ~~$392.37~~ $376.48 - + Add to cart
92173	CLAMP Part #: 92173-1579 Required per assembly: 1 $16.25 - + Add to cart
92210	NUT, LOCK Part #: 92210-0922 Required per assembly: 2 $16.08 - + Add to cart
