Rear Box And Fenders - A18haa15b7/B2 (100795) replacement parts for 2018 Polaris ACE 150 EFI, 501S, Indy (R02)

OEM Parts Polaris 2018 Polaris ACE 150 EFI, 501S, Indy (R02) Rear Box And Fenders - A18haa15b7/B2 (100795)

REAR BOX AND FENDERS - A18HAA15B7/B2 (100795) Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	PANEL-CLOSE, OFF, REAR, BLK Part #: 5453283-070 Required per assembly: 1 Currently Not Available
2	FENDER-REAR, LH, WTLTG Part #: 5453284-599 Required per assembly: 1 Note: B2 Currently Not Available
2	FENDER-REAR, LH, INDY, RED Part #: 5453284-293 Required per assembly: 1 Note: B7 Currently Not Available
3	FENDER-REAR, RH, WTLTG Part #: 5453285-599 Required per assembly: 1 Note: B2 Currently Not Available
3	FENDER-REAR, RH, INDY, RED Part #: 5453285-293 Required per assembly: 1 Note: B7 Currently Not Available
4	BOX-CARGO, REAR, BLK Part #: 5453286-070 Required per assembly: 1 Currently Not Available
5	SCREW Part #: 7519650 Required per assembly: 47 Currently Not Available
5	SCREW Part #: 7519650 Required per assembly: 47 Currently Not Available
5	SCREW Part #: 7519650 Required per assembly: 47 Currently Not Available
5	SCREW Part #: 7519650 Required per assembly: 47 Currently Not Available
6	NUT, U-TYPE Part #: 7547674 Required per assembly: 30 ~~$2.99~~ $1.73 - + Add to cart
6	NUT, U-TYPE Part #: 7547674 Required per assembly: 30 ~~$2.99~~ $1.73 - + Add to cart
6	NUT, U-TYPE Part #: 7547674 Required per assembly: 30 ~~$2.99~~ $1.73 - + Add to cart
6	NUT, U-TYPE Part #: 7547674 Required per assembly: 30 ~~$2.99~~ $1.73 - + Add to cart
7	RIVET Part #: 7661855 Required per assembly: 31 ~~$2.99~~ $1.73 - + Add to cart
7	RIVET Part #: 7661855 Required per assembly: 31 ~~$2.99~~ $1.73 - + Add to cart
