Doors, Rear - R18rhe99bk (702141) replacement parts for 2018 Polaris General 1000 4P PS (R05)

OEM Parts Polaris 2018 Polaris General 1000 4P PS (R05) Doors, Rear - R18rhe99bk (702141)

DOORS, REAR - R18RHE99BK (702141) Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	PANEL-DOOR, OTR, RR, PNT, LH, B.PRL Part #: 5452945-666 Required per assembly: 1 Note: TO 8/28/2017 Currently Not Available
1	PANEL-DOOR, OTR, RR, PNT, LH, B.PRL Part #: 5454659-666 Required per assembly: 1 Note: FRM 8/28/2017 Currently Not Available
2	PANEL-DOOR, OTR, RR, PNT, RH, B.PRL Part #: 5454662-666 Required per assembly: 1 Note: FRM 8/28/2017 Currently Not Available
2	PANEL-DOOR, OTR, RR, PNT, RH, B.PRL Part #: 5452946-666 Required per assembly: 1 Note: TO8/28/2017 Currently Not Available
3	COVER-BLSTR, BAR, PNT, LH, BLK, PRL Part #: 5452953-666 Required per assembly: 1 Currently Not Available
4	COVER-BLSTR, BAR, PNT, RH, BLK, PRL Part #: 5452954-666 Required per assembly: 1 Currently Not Available
5	SCR-TXTH-M6X1.0X20 T40 ZPB Part #: 7519112 Currently Not Available
5	SCR-TXTH-M6X1.0X20 T40 ZPB Part #: 7519112 Currently Not Available
6	WELD-BOLSTER, REAR, LH, BLK Part #: 1022761-458 Required per assembly: 1 Currently Not Available
7	WELD-BOLSTER, REAR, RH, BLK Part #: 1022762-458 Required per assembly: 1 Currently Not Available
8	BRKT-DOOR, REAR, HINGE, BLK Part #: 5263232-329 Required per assembly: 4 Currently Not Available
9	CABLE-ADJUSTABLE REAR DOOR Part #: 7082386 Required per assembly: 1 Currently Not Available
10	SCREW Part #: 7519045 Required per assembly: 5 Currently Not Available
11	ASM-LATCH, RTRY, 2, STAGE, RR, LH Part #: 7082333 Required per assembly: 1 Currently Not Available
12	ASM-LATCH, RTRY, 2, STAGE, RR, RH Part #: 7082334 Required per assembly: 1 Currently Not Available
13	ASM-HANDLE-DOOR, REAR Part #: 7082387 Required per assembly: 1 Currently Not Available
14	SCREW Part #: 7518533 Required per assembly: 4 Note: Screw, Flange Currently Not Available
15	U-TYPE, SPEED, NUT Part #: 7081305 Required per assembly: 5 Note: Clip, U Speed Nut [Built 12/07/09 and Before] Currently Not Available
16	NUT, FLANGE Part #: 7547453 Required per assembly: 4 Currently Not Available
17	PANEL-DOOR, INNER, REAR, LH, BLK Part #: 5454348-070 Required per assembly: 1 Note: FRM 8/28/2017 Currently Not Available
17	PANEL-DOOR, INNER, REAR, LH, BLK Part #: 5454348-070 Required per assembly: 1 Note: TO8/28/2017 Currently Not Available
18	PANEL-DOOR, INNER, REAR, RH, BLK Part #: 5454349-070 Required per assembly: 1 Note: FRM 8/28/2017 Currently Not Available
18	PANEL-DOOR, INNER, REAR, RH, BLK Part #: 5454349-070 Required per assembly: 1 Note: TO8/28/2017 Currently Not Available
19	SEAL-DOOR, REAR Part #: 5510932 Required per assembly: 2 Currently Not Available
20	SCR-HEXFLGHD, M8, X, 20, 0600086 Part #: 7517838 Required per assembly: 8 Currently Not Available
21	BUSHING, DOOR, PIVOT Part #: 5450592 Required per assembly: 8 Currently Not Available
22	SCREW Part #: 7519650 Required per assembly: 8 Currently Not Available
23	SCREW Part #: 7519781 Required per assembly: 8 Currently Not Available
24	NUT-HEX-M8X1.25 8 ZOD NYL Part #: 7547480 Required per assembly: 8 Currently Not Available
25	SCR-HXFL-M8X1.25X50 8.8 ZODP30 Part #: 7519077 Required per assembly: 2 Currently Not Available
26	NUT, FLANGE Part #: 7547332 Required per assembly: 2 Note: Nut, Nylok Currently Not Available
27	WELD-STRIKER, REAR, BLK Part #: 1023631-458 Required per assembly: 2 Currently Not Available
28	SCREW Part #: 7519297 Required per assembly: 2 Currently Not Available
28	SCREW Part #: 7519297 Required per assembly: 2 Currently Not Available
29	WELD-DOOR, FRAME, REAR, LH, BLK Part #: 1023534-458 Required per assembly: 1 Currently Not Available
30	WELD-DOOR, FRAME, REAR, RH, BLK Part #: 1023535-458 Required per assembly: 1 Currently Not Available
