Electrical replacement parts for 2018 Suzuki RV200 VanVan

OEM Parts Suzuki 2018 Suzuki RV200 VanVan Electrical

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	COIL, ASSEMBLY, IGNITION Part #: 33410-13G00 Required per assembly: 1 Not Available
2	BOLT Part #: 07130-0516B Required per assembly: 2 $2.67 $2.40 - + Add to cart
3	CAP, SPARK, PLUG Part #: 33510-97313 Required per assembly: 1 Note: CAP ASSY, SPARK PLUG; $18.20 $15.55 - + Add to cart
4	SEAL, SPARK, PLUG, CAP Part #: 33541-38210 Required per assembly: 1 $5.94 $5.35 - + Add to cart
5	SEAL, HIGHTENSION, CORD Part #: 33542-38B00 Required per assembly: 1 Note: SEAL, HIGH TENSION CORD; $30.87 $26.39 - + Add to cart
6	RECTIFIER ASSEMBLY Part #: 32800-05F20 Required per assembly: 1 $239.32 $215.39 - + Add to cart
7	BOLT Part #: 07120-0620B Required per assembly: 1 Note: BOLT; $3.70 $3.33 - + Add to cart
8	CONTROL, UNIT, FI Part #: 32920-13G40 Required per assembly: 1 Not Available
9	PROTECTOR (20X90X4) Part #: 33652-49000 Required per assembly: 1 Note: CUSHION, FI (90X20X4); $3.88 $3.49 - + Add to cart
10	SENSOR, ASSEMBLY, FUEL, CUT Part #: 33960-06G10 Required per assembly: 1 $116.08 $99.24 - + Add to cart
11	RELAY, STARTING, MOTOR Part #: 31800-47E01 Required per assembly: 1 $98.84 $84.50 - + Add to cart
12	COVER Part #: 31861-47E00 Required per assembly: 1 Note: COVER, RELAY ASSY; $17.46 $14.92 - + Add to cart
13	FUSE (20A) Part #: 09481-20102 Required per assembly: 2 $3.14 $2.83 - + Add to cart
14	SCREW Part #: 09128-06013 Required per assembly: 2 Note: BOLT, STG MOT TERM; $1.50 $1.35 - + Add to cart
