Exhaust 2 replacement parts for 2018 Yamaha 210 FSH

OEM Parts Yamaha 2018 Yamaha 210 FSH Exhaust 2

EXHAUST 2 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	HOSE 2 Part #: 6FV-E243E-00-00 Required per assembly: 1 ~~$18.35~~ $15.10 - + Add to cart
2	JOINT, HOSE, 3 Part #: 6EY-12584-00-00 Required per assembly: 1 ~~$12.99~~ $12.84 - + Add to cart
3	HOSE (L400) Part #: 90445-18012-00 Required per assembly: 1 Note: (L400) ~~$24.98~~ $24.92 - + Add to cart
4	TUBE (L300) Part #: 90447-19014-00 Required per assembly: 1 ~~$5.99~~ $5.44 - + Add to cart
5	CLIP Part #: 90467-160A0-00 Required per assembly: 2 ~~$3.99~~ $3.61 - + Add to cart
6	CLAMP Part #: 90465-13M39-00 Required per assembly: 1 ~~$5.40~~ $4.71 - + Add to cart
7	HOSE (L170) (L170) Part #: 90445-21015-00 Required per assembly: 1 ~~$15.78~~ $14.35 - + Add to cart
8	CLIP Part #: 90467-200A3-00 Required per assembly: 2 ~~$7.99~~ $7.24 - + Add to cart
9	HOSE (L160) Part #: 90445-16019-00 Required per assembly: 1 ~~$7.99~~ $7.24 - + Add to cart
10	HOSE (L70) Part #: 90446-24M44-00 Required per assembly: 1 ~~$3.99~~ $3.61 - + Add to cart
11	CLIP Part #: 90467-150A1-00 Required per assembly: 2 ~~$4.49~~ $4.08 - + Add to cart
12	HOSE (L1900) Part #: 90445-16023-00 Required per assembly: 1 ~~$41.55~~ $37.77 - + Add to cart
13	CLIP Part #: 90467-160A0-00 Required per assembly: 1 ~~$3.99~~ $3.61 - + Add to cart
14	HOSE 2 Part #: 6EY-12577-00-00 Required per assembly: 1 ~~$14.49~~ $14.35 - + Add to cart
15	CLIP Part #: 90467-160A0-00 Required per assembly: 2 ~~$3.99~~ $3.61 - + Add to cart
16	HOSE 4 Part #: 6S5-12579-00-00 Required per assembly: 1 ~~$21.60~~ $19.64 - + Add to cart
17	CLIP Part #: 90467-160A0-00 Required per assembly: 2 ~~$3.99~~ $3.61 - + Add to cart
18	HOSE (L370) Part #: 90445-18018-00 Required per assembly: 1 ~~$19.11~~ $17.37 - + Add to cart
19	CLIP Part #: 90467-160A0-00 Required per assembly: 2 ~~$3.99~~ $3.61 - + Add to cart
20	THERMOSTAT Part #: 6D3-12411-00-00 Required per assembly: 1 ~~$125.48~~ $123.95 - + Add to cart
21	COVER, THERMOSTAT Part #: 6EY-12413-00-00 Required per assembly: 1 ~~$17.45~~ $15.86 - + Add to cart
22	BOLT, FLANGE Part #: 90105-06035-00 Required per assembly: 2 ~~$2.49~~ $2.27 - + Add to cart
23	HOSE 1 Part #: 6FV-E243A-00-00 Required per assembly: 1 ~~$18.35~~ $14.35 - + Add to cart
24	HOSE, WITH, SPRING, (L380) Part #: 90447-22008-00 Required per assembly: 2 Note: (L380) ~~$6.49~~ $5.88 - + Add to cart
25	JOINT ASSEMBLY Part #: 6B5-12580-00-00 Required per assembly: 2 ~~$138.99~~ $137.56 - + Add to cart
26	CLIP Part #: 90467-150A5-00 Required per assembly: 2 ~~$2.99~~ $2.72 - + Add to cart
27	CAP, 1 Part #: 6EY-84385-00-00 Required per assembly: 2 ~~$15.78~~ $14.35 - + Add to cart
28	NUT Part #: EU0-61652-00-00 Required per assembly: 2 ~~$19.98~~ $13.18 - + Add to cart
29	CLIP Part #: 90467-200A3-00 Required per assembly: 4 ~~$7.99~~ $7.24 - + Add to cart
30	HOSE, WITH, SPRING Part #: 90447-28007-00 Required per assembly: 2 Note: (L560) ~~$14.12~~ $12.84 - + Add to cart
31	CLIP Part #: 90467-240A0-00 Required per assembly: 2 ~~$7.49~~ $6.80 - + Add to cart
32	WAVERUNNER / JET BOAT CONDUCTION WATER FLUSH FITTING Part #: 67X-E2590-00-00 Required per assembly: 1 ~~$8.15~~ $6.33 - + Add to cart
