Hull Deck Fittings replacement parts for 2018 Yamaha SX240 High Output

OEM Parts Yamaha 2018 Yamaha SX240 High Output Hull Deck Fittings

HULL DECK FITTINGS Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	GUNWALE (BLACK 20') Part #: F2A-U2557-10-00 Required per assembly: 2 $555.81 - + Add to cart
2	GUNWALE Part #: F2D-U2557-00-00 Required per assembly: 1 Note: BLACK $75.84 - + Add to cart
3	INNER GUNWALE (STAINLESS 16') Part #: F2A-U2519-10-00 Required per assembly: 1 $748.09 - + Add to cart
4	INNER GUNWALE (STAINLESS 16') Part #: F2A-U2519-10-00 Required per assembly: 2 $748.09 - + Add to cart
5	SCREW, #10, X, 1-1/4 Part #: 90161-10S20-00 Required per assembly: 17 $6.11 $1.36 - + Add to cart
6	SCREW, TAPPING Part #: 90162-08S20-00 Required per assembly: 1 Note: UN $6.11 $1.36 - + Add to cart
7	COVER, GUNWALE(STAINLESS, STEEL) Part #: F2A-U2518-00-00 Required per assembly: 1 $31.62 - + Add to cart
8	STANCHION, TABLE, 1 Part #: F3H-U4814-01-00 Required per assembly: 1 $342.70 $287.19 - + Add to cart
9	TABLE Part #: F3F-U4811-00-00 Required per assembly: 1 $269.26 $260.30 - + Add to cart
10	BRKT., TABLE, 2 Part #: F3H-U4826-00-00 Required per assembly: 1 $40.78 $29.45 - + Add to cart
11	SCREW, #10, X, 3/4&QUO Part #: 90169-10SA1-00 Required per assembly: 6 $6.11 $1.44 - + Add to cart
12	ICE BOX COMP. Part #: F2D-U4360-00-00 Required per assembly: 1 Not Available
13	BOW EYE 1 Part #: F3A-U1624-00-00 Required per assembly: 2 $41.81 $31.72 - + Add to cart
14	BOW EYE 1 Part #: F3F-U1624-00-00 Required per assembly: 1 $36.71 $27.94 - + Add to cart
15	ANCHOR ROPE RETAINER Part #: F1C-U1794-00-00 Required per assembly: 1 $15.80 $12.84 - + Add to cart
16	LADDER, TRANSOM Part #: F2D-U2425-00-00 Required per assembly: 1 $461.02 $441.37 - + Add to cart
17	BAND, BOARDING, LADDER Part #: F1C-U5191-00-00 Required per assembly: 1 $51.99 $38.95 - + Add to cart
18	CUSHION, RUBBER Part #: F1C-U3768-00-00 Required per assembly: 4 $17.32 $13.59 - + Add to cart
19	CAP, LADDER Part #: F1C-U2155-00-00 Required per assembly: 1 $21.41 $15.86 - + Add to cart
20	BOLT Part #: 90101-08802-00 Required per assembly: 4 $1.16 $0.98 - + Add to cart
21	WASHER, PLATE Part #: 9299R-08600-00 Required per assembly: 4 Note: Sold in multiples of 10 only $7.12 $2.27 - + Add to cart
22	BOX Part #: F3F-U4278-C0-00 Required per assembly: 1 $245.81 $212.57 - + Add to cart
23	LIGHT, ROOM, 1 Part #: F3F-U8124-10-00 Required per assembly: 1 $52.99 $39.71 - + Add to cart
24	WASHER Part #: 90209-10SB1-00 Required per assembly: 4 $6.11 $1.29 - + Add to cart
25	WASHER, LOCK, (#10) Part #: 90204-10S00-00 Required per assembly: 4 $7.12 $2.57 - + Add to cart
26	NUT Part #: 90170-10S00-00 Required per assembly: 4 $6.11 $1.51 - + Add to cart
27	BOX Part #: F3F-U4278-D0-00 Required per assembly: 1 $260.08 $229.20 - + Add to cart
28	BOX, SIDE Part #: F3F-U4776-00-00 Required per assembly: 1 $55.07 $45.33 - + Add to cart
29	SCREW TRUSS HEAD Part #: 90169-08SA3-00 Required per assembly: 4 $6.11 $1.36 - + Add to cart
30	HOLDER, DRINK Part #: F2J-U5633-00-00 Required per assembly: 12 $20.39 $15.10 - + Add to cart
31	SCREW, #6, X, 3/4, PFH Part #: 90161-06S12-00 Required per assembly: 3 $6.11 $2.42 - + Add to cart
32	RING Part #: F2J-U7845-00-00 Required per assembly: 1 $7.12 $4.22 - + Add to cart
33	HOLDER, DRINK Part #: F2D-U5633-10-00 Required per assembly: 2 $26.51 $19.64 - + Add to cart
34	CLEAT Part #: F1C-U1616-10-00 Required per assembly: 6 $112.19 $86.17 - + Add to cart
35	HANDLE Part #: F1C-U1552-01-00 Required per assembly: 1 $21.41 $15.86 - + Add to cart
36	SCREW, #8, X, 3/4" Part #: 90167-08S12-00 Required per assembly: 4 $6.11 $1.29 - + Add to cart
37	GRIP ASSEMBLY Part #: F4B-U270B-01-00 Required per assembly: 3 $51.99 $38.80 - + Add to cart
38	WASHER, PLATE Part #: 90201-099U1-00 Required per assembly: 6 $7.12 $2.42 - + Add to cart
39	NUT, SELF-LOCKING Part #: 90185-15S00-00 Required per assembly: 6 $0.45 $0.42 - + Add to cart
40	NET, STORAGE Part #: F3F-U4751-00-00 Required per assembly: 1 $81.59 $63.49 - + Add to cart
41	HOOK Part #: F3F-U5192-00-00 Required per assembly: 4 $7.12 $3.08 - + Add to cart
42	SCREW, #10, X, 1-1/4 Part #: 90161-10S20-00 Required per assembly: 4 $6.11 $1.36 - + Add to cart
43	GRIP ASSEMBLY Part #: F3H-U270B-20-00 Required per assembly: 1 $98.93 $77.10 - + Add to cart
44	WASHER Part #: 90209-15SA3-00 Required per assembly: 2 $4.17 $3.24 - + Add to cart
45	NUT, SELF-LOCKING Part #: 90185-15S00-00 Required per assembly: 2 $0.45 $0.42 - + Add to cart
46	HAND RAIL Part #: F3H-U2767-00-00 Required per assembly: 2 $144.99 $112.47 - + Add to cart
47	WASHER, PLATE Part #: 90201-099U1-00 Required per assembly: 4 $7.12 $2.42 - + Add to cart
48	NUT, SELF-LOCKING Part #: 90185-15S00-00 Required per assembly: 4 $0.45 $0.42 - + Add to cart
49	BRKT., TABLE, 1 Part #: F3H-U4825-10-00 Required per assembly: 2 $112.19 $86.17 - + Add to cart
50	SPACER 1 Part #: F3F-U471E-00-00 Required per assembly: 2 $53.03 $42.31 - + Add to cart
51	SCREW, COUNTERSUNK Part #: 90151-14S36-00 Required per assembly: 8 $6.11 $1.59 - + Add to cart
52	WASHER, 1/4", FL Part #: 90201-14S00-00 Required per assembly: 8 $7.12 $1.66 - + Add to cart
53	NUT, SELF-LOCKING Part #: 90185-14S00-00 Required per assembly: 8 $5.08 $0.68 - + Add to cart
54	SKI TOWS Part #: F1T-U1629-00-00 Required per assembly: 1 $76.48 $58.95 - + Add to cart
55	LADDER, STEP, ASSEMBLY Part #: F3F-U278A-00-00 Required per assembly: 1 $404.93 $383.98 - + Add to cart
56	EYE STRAP Part #: F2D-U1543-00-00 Required per assembly: 1 $20.39 $15.86 - + Add to cart
57	SNAP, CARPET Part #: F1C-U5192-00-00 Required per assembly: 2 $0.71 $0.60 - + Add to cart
58	SCREW, 1/4-20, X, 1-1/4 Part #: 90157-14S20-00 Required per assembly: 4 $5.08 $0.98 - + Add to cart
