2018 Yamaha Star Eluder XV19BJS - Headlight

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

HEADLIGHT ASSEMBLY

Part #: 2DF-84300-20-00 Required per assembly: 1
$764.99
$762.20
-
+
Add to cart
2

HEADLIGHT ASSEMBLY

Part #: 2DF-84300-30-00 Required per assembly: 1
$806.62
$746.29
-
+
Add to cart
3

DAMPER

Part #: 5PS-83513-00-00 Required per assembly: 6
$4.79
$3.61
-
+
Add to cart
4

COLLAR

Part #: 90387-06161-00 Required per assembly: 6
$9.49
$6.12
-
+
Add to cart
5

WASHER, PLATE

Part #: 90201-06036-00 Required per assembly: 4
$9.49
$6.15
-
+
Add to cart
6

BOLT, FLANGE

Part #: 95022-06025-00 Required per assembly: 4
$1.89
$1.44
-
+
Add to cart
7

BOLT, HEXAGON, SOCKET, BUTTON

Part #: 90111-06137-00 Required per assembly: 2
$6.49
$4.69
-
+
Add to cart
8

GROMMET

Part #: 90480-13014-00 Required per assembly: 2
$9.49
$6.73
-
+
Add to cart
9

NUT, SPRING

Part #: 90183-060A2-00 Required per assembly: 4
$10.49
$7.92
-
+
Add to cart
10

NUT, SPRING

Part #: 90183-050A6-00 Required per assembly: 2
$2.95
$2.33
-
+
Add to cart
11

COVER, HEADLIGHT, 1

Part #: 2DF-2838D-00-00 Required per assembly: 1
$77.98
$65.77
-
+
Add to cart
12

COVER, HEADLIGHT, 2

Part #: 2DF-2838S-00-00 Required per assembly: 1
$77.98
$65.77
-
+
Add to cart
13

SHEET

Part #: 2DF-8336V-00-00 Required per assembly: 8
$2.29
$0.80
-
+
Add to cart
