Frame replacement parts for 2018 Yamaha Kodiak 450 EPS 4WD Hunter

OEM Parts Yamaha 2018 Yamaha Kodiak 450 EPS 4WD Hunter Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRAME COMP. Part #: BB5-F1110-02-00 Required per assembly: 1 $1,096.13 - + Add to cart
2	STAY, ENGINE, 1 Part #: BB5-F1315-00-00 Required per assembly: 1 $9.99 $8.23 - + Add to cart
3	STAY, ENGINE, 2 Part #: BB5-F1316-00-00 Required per assembly: 1 $6.49 $5.58 - + Add to cart
4	BOLT, FLANGE Part #: 95817-10030-00 Required per assembly: 2 $9.49 $6.05 - + Add to cart
5	BOLT, FLANGE Part #: 95812-08020-00 Required per assembly: 2 $2.79 $1.66 - + Add to cart
6	STAY, ENGINE, 3 Part #: BB5-F1317-00-00 Required per assembly: 1 $5.99 $4.84 - + Add to cart
7	STAY, ENGINE, 4 Part #: BB5-F1318-00-00 Required per assembly: 1 $5.49 $4.25 - + Add to cart
8	BOLT, FLANGE Part #: 95812-08020-00 Required per assembly: 4 $2.79 $1.66 - + Add to cart
9	DAMPER, RUBBER, 1 Part #: 3B4-21485-01-00 Required per assembly: 2 $46.99 $41.38 - + Add to cart
10	NUT, SELF-LOCKING Part #: 90185-10011-00 Required per assembly: 2 $4.95 $4.10 - + Add to cart
11	BOLT, FLANGE Part #: 95817-10020-00 Required per assembly: 2 $8.49 $5.15 - + Add to cart
12	BOLT, FLANGE Part #: 95022-06012-00 Required per assembly: 2 $3.54 $2.95 - + Add to cart
13	DAMPER, RUBBER, 1 Part #: 3B4-21485-01-00 Required per assembly: 2 $46.99 $41.38 - + Add to cart
14	NUT, SELF-LOCKING Part #: 90185-10011-00 Required per assembly: 2 $4.95 $4.10 - + Add to cart
15	BOLT, FLANGE Part #: 95817-10020-00 Required per assembly: 2 $8.49 $5.15 - + Add to cart
16	BOLT, FLANGE Part #: 95022-06012-00 Required per assembly: 2 $3.54 $2.95 - + Add to cart
17	BOLT, FLANGE Part #: 90105-10051-00 Required per assembly: 2 $16.48 $11.07 - + Add to cart
18	NUT, SELF-LOCKING Part #: 95602-10200-00 Required per assembly: 2 $2.70 $2.25 - + Add to cart
19	WASHER, PLATE Part #: 90201-10035-00 Required per assembly: 4 $4.50 $3.76 - + Add to cart
20	STAY, MUFFLER, 2 Part #: BB5-F1446-00-00 Required per assembly: 1 $3.54 $2.87 - + Add to cart
21	PROTECTOR 1 Part #: 1CT-F2825-00-00 Required per assembly: 1 Not Available
22	WASHER, PLATE Part #: 90201-06078-00 Required per assembly: 1 $6.49 $5.38 - + Add to cart
23	BOLT, FLANGE Part #: 95817-06012-00 Required per assembly: 2 $1.95 $1.47 - + Add to cart
24	TOOL KIT Part #: BB5-F8100-00-00 Required per assembly: 1 $10.49 $7.50 - + Add to cart
25	GAUGE, AIR Part #: 1NV-2811A-01-00 Required per assembly: 1 $62.99 $49.61 - + Add to cart
26	O-RING Part #: 93210-92448-00 Required per assembly: 1 $12.49 $8.75 - + Add to cart
27	O-RING Part #: 93210-64297-00 Required per assembly: 1 $8.99 $7.36 - + Add to cart
28	HOOK Part #: 1D9-F8488-01-00 Required per assembly: 1 Note: (YMUS) $43.09 - + Add to cart
29	BOLT, FLANGE Part #: 95812-10040-00 Required per assembly: 2 $9.49 $7.29 - + Add to cart
30	GUARD, ENGINE, 1 Part #: 5ND-F147A-03-00 Required per assembly: 1 $95.77 - + Add to cart
31	BOLT Part #: 90109-06043-00 Required per assembly: 8 $3.00 $2.27 - + Add to cart
32	GUARD COMP. Part #: 1CT-F840K-00-00 Required per assembly: 1 $19.98 $16.90 - + Add to cart
33	BOLT Part #: 90109-06043-00 Required per assembly: 1 $3.00 $2.27 - + Add to cart
34	BOLT Part #: 90109-06202-00 Required per assembly: 2 $3.10 $2.59 - + Add to cart
