OEM Parts Yamaha 2018 Yamaha YFZ450R SE Radiator Hose

2018 Yamaha YFZ450R SE YFZ45YSSJW - Radiator Hose

RADIATOR HOSE Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

RADIATOR ASSY

Part #: 1TD-E2460-03-00 Required per assembly: 1
$382.99
$316.75
-
+
Add to cart
2

BLOWER ASSEMBLY

Part #: 1TD-E2405-01-00 Required per assembly: 1
$242.99
$199.66
-
+
Add to cart
3

PLATE

Part #: 1PE-E2535-00-00 Required per assembly: 3
$4.15
$3.02
-
+
Add to cart
4

BOLT, BLOWER, HOLDING

Part #: 1PE-E2675-00-00 Required per assembly: 3
$1.55
$1.18
-
+
Add to cart
5

CAP, RADIATOR

Part #: 1HP-E2462-00-00 Required per assembly: 1
$32.99
$24.51
-
+
Add to cart
6

PIPE 1

Part #: 5TG-12481-00-00 Required per assembly: 1
$30.98
$23.28
-
+
Add to cart
7

BOLT, FLANGE

Part #: 95022-06012-00 Required per assembly: 1
$3.54
$2.95
-
+
Add to cart
8

O-RING (1LX)

Part #: 93210-16500-00 Required per assembly: 1
$7.49
$4.82
-
+
Add to cart
9

HOSE 1

Part #: 1TD-E2576-00-00 Required per assembly: 1
$8.49
$6.97
-
+
Add to cart
10

HOSE 2

Part #: 1TD-E2577-00-00 Required per assembly: 1
$9.49
$7.91
-
+
Add to cart
11

CLIP, SCISSOR

Part #: 90467-23067-00 Required per assembly: 3
$7.49
$3.90
-
+
Add to cart
12

HOSE CLAMP ASSEMBLY

Part #: 90450-32015-00 Required per assembly: 1
$19.48
$14.97
-
+
Add to cart
13

GROMMET

Part #: 90480-15058-00 Required per assembly: 4
$9.49
$6.05
-
+
Add to cart
14
Yamaha 90387-07391-00 Collar 437216330000

COLLAR 437216330000

Part #: 90387-07391-00 Required per assembly: 4
$10.49
$7.61
-
+
Add to cart
15

BOLT, WITH, WASHER

Part #: 90119-06181-00 Required per assembly: 4
$9.49
$6.05
-
+
Add to cart
