OEM Parts Yamaha 2018 Yamaha YDX Torc Frame

2018 Yamaha YDX Torc YTORCSTYB X1M3-10A - Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

FRAME COMP.

Part #: X1M-F1110-20-P0 Required per assembly: 1
$1,050.24
$1,004.77
-
+
Add to cart
2

REAR DERAILLER

Part #: X1M-F535B-00-00 Required per assembly: 1
$354.99
$344.77
-
+
Add to cart
3

BRACKET, DERAILLER, REAR

Part #: X1M-F114D-00-00 Required per assembly: 1
$14.99
$11.76
-
+
Add to cart
4

BRACKET 5

Part #: X1M-F112K-00-00 Required per assembly: 1
$9.49
$7.64
-
+
Add to cart
5

SCREW 2

Part #: X1M-F11C6-00-00 Required per assembly: 2
Not Available
6

BOLT

Part #: X1M-F2125-00-00 Required per assembly: 2
$4.71
$2.99
-
+
Add to cart
7

BOLT

Part #: X1M-F2125-10-00 Required per assembly: 2
$3.54
$2.27
-
+
Add to cart
8

GROMMET

Part #: X1M-F1719-10-00 Required per assembly: 1
$12.49
$9.31
-
+
Add to cart
9

GROMMET

Part #: X1M-F1719-30-00 Required per assembly: 1
$13.49
$10.27
-
+
Add to cart
10

BRACKET

Part #: X1M-F256L-00-00 Required per assembly: 1
$7.49
$5.03
-
+
Add to cart
11

SCREW 3

Part #: X1M-F11C7-00-00 Required per assembly: 1
$2.39
$1.38
-
+
Add to cart
12

LOCK COMP.

Part #: X1M-H256A-00-00 Required per assembly: 1
$105.98
$83.81
-
+
Add to cart
13

BOLT

Part #: X1M-F1738-00-00 Required per assembly: 1
$3.54
$2.86
-
+
Add to cart
14

SCREW 4

Part #: X1M-F11C8-00-00 Required per assembly: 2
$2.43
$1.69
-
+
Add to cart
15

CLAMP, WIRE, HARNESS

Part #: X0N-F1999-00-00 Required per assembly: 2
$2.87
$2.10
-
+
Add to cart
16

LABEL INFORMATION

Part #: X1M-F11A5-00-00 Required per assembly: 1
$2.20
$1.32
-
+
Add to cart
17

LABEL, CAUTION

Part #: X1M-H4306-00-00 Required per assembly: 1
$2.39
$1.60
-
+
Add to cart
18

LABEL, CAUTION

Part #: X1M-F2298-00-00 Required per assembly: 1
$2.39
$1.51
-
+
Add to cart
19

FORK COMP. 1

Part #: X1M-F3780-21-00 Required per assembly: 1
$2,007.60
$1,834.09
-
+
Add to cart
20

STEERING SET

Part #: X1M-F341A-00-00 Required per assembly: 1
$159.99
$136.46
-
+
Add to cart
21

CAP ASSEMBLY

Part #: X1M-F287K-00-00 Required per assembly: 1
$9.49
$5.94
-
+
Add to cart
22

COLLAR 1

Part #: X0N-F3363-00-00 Required per assembly: 2
$7.49
$4.78
-
+
Add to cart
23

COLLAR 2

Part #: X0N-F3364-00-00 Required per assembly: 2
$5.59
$4.05
-
+
Add to cart
24

CRANK SET

Part #: X1M-F781A-00-00 Required per assembly: 1
$174.99
$142.88
-
+
Add to cart
25

PEDAL SET

Part #: X1M-F785A-00-00 Required per assembly: 1
$23.98
$17.96
-
+
Add to cart
