Front Fork replacement parts for 2018 Yamaha Zuma 125

OEM Parts Yamaha 2018 Yamaha Zuma 125 Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY Part #: 2JS-F3100-00-00 Required per assembly: 1 $361.99 $345.91 - + Add to cart
2	FRONT FORK ASSEMBLY (LH) Part #: 2JS-F3102-00-00 Required per assembly: 1 $194.99 $171.26 - + Add to cart
3	TUBE, OUTER, (L.H) Part #: 2JS-F3126-00-00 Required per assembly: 1 Not Available
4	INNER TUBE COMP.1 Part #: 2JS-F3110-00-00 Required per assembly: 1 Not Available
5	SEAT, SPRING, UPPER Part #: 2JS-F3142-00-00 Required per assembly: 1 Not Available
6	PISTON RING Part #: 4P9-F318X-00-00 Required per assembly: 1 Not Available
7	SPRING, REBOUND Part #: 4C6-F3151-00-00 Required per assembly: 1 $1.30 $1.07 - + Add to cart
8	PISTON, FRONT, FORK Part #: 4P9-F3171-00-00 Required per assembly: 1 Not Available
9	GASKET Part #: 4P9-F3158-00-00 Required per assembly: 1 $0.45 $0.34 - + Add to cart
10	BOLT, HEXAGON, SOCKET, HEAD Part #: 4P9-F3181-00-00 Required per assembly: 1 $1.95 $1.63 - + Add to cart
11	OIL SEAL Part #: 4C6-F3145-00-00 Required per assembly: 1 $11.49 $9.81 - + Add to cart
12	RING, PISTON Part #: 4P9-F3157-00-00 Required per assembly: 1 $1.20 $0.65 - + Add to cart
13	SPRING, FRONT, FORK Part #: 2JS-F3141-00-00 Required per assembly: 1 $7.99 $6.43 - + Add to cart
14	O-RING Part #: 4C6-F3147-00-00 Required per assembly: 1 Not Available
15	COLLAR Part #: 4P9-F3113-00-00 Required per assembly: 1 $3.50 $2.81 - + Add to cart
16	RING, FELT Part #: 4P9-F3155-00-00 Required per assembly: 1 $0.28 $0.25 - + Add to cart
17	CAP Part #: 4P9-F3154-00-00 Required per assembly: 1 $1.14 $0.88 - + Add to cart
18	BAND Part #: 4C6-F3192-00-00 Required per assembly: 1 $1.14 $0.91 - + Add to cart
19	BOOT Part #: 2JS-F3191-00-00 Required per assembly: 1 $13.49 $10.84 - + Add to cart
20	FRONT FORK ASSEMBLY (RH) Part #: 2JS-F3103-00-00 Required per assembly: 1 $195.99 $172.73 - + Add to cart
21	TUBE, OUTER, 2 Part #: 2JS-F3136-00-00 Required per assembly: 1 $90.98 $82.51 - + Add to cart
22	INNER TUBE COMP.1 Part #: 2JS-F3110-00-00 Required per assembly: 1 Not Available
23	SEAT, SPRING, UPPER Part #: 2JS-F3142-00-00 Required per assembly: 1 Not Available
24	PISTON RING Part #: 4P9-F318X-00-00 Required per assembly: 1 Not Available
25	SPRING, REBOUND Part #: 4C6-F3151-00-00 Required per assembly: 1 $1.30 $1.07 - + Add to cart
26	PISTON, FRONT, FORK Part #: 4P9-F3171-00-00 Required per assembly: 1 Not Available
27	GASKET Part #: 4P9-F3158-00-00 Required per assembly: 1 $0.45 $0.34 - + Add to cart
28	BOLT, HEXAGON, SOCKET, HEAD Part #: 4P9-F3181-00-00 Required per assembly: 1 $1.95 $1.63 - + Add to cart
29	OIL SEAL Part #: 4C6-F3145-00-00 Required per assembly: 1 $11.49 $9.81 - + Add to cart
30	RING, PISTON Part #: 4P9-F3157-00-00 Required per assembly: 1 $1.20 $0.65 - + Add to cart
31	SPRING, FRONT, FORK Part #: 2JS-F3141-00-00 Required per assembly: 1 $7.99 $6.43 - + Add to cart
32	O-RING Part #: 4C6-F3147-00-00 Required per assembly: 1 Not Available
33	COLLAR Part #: 4P9-F3113-00-00 Required per assembly: 1 $3.50 $2.81 - + Add to cart
34	RING, FELT Part #: 4P9-F3155-00-00 Required per assembly: 1 $0.28 $0.25 - + Add to cart
35	CAP Part #: 4P9-F3154-00-00 Required per assembly: 1 $1.14 $0.88 - + Add to cart
36	BAND Part #: 4C6-F3192-00-00 Required per assembly: 1 $1.14 $0.91 - + Add to cart
37	BOOT Part #: 2JS-F3191-00-00 Required per assembly: 1 $13.49 $10.84 - + Add to cart
38	UNDER BRACKET COMP Part #: 2JS-F3340-00-00 Required per assembly: 1 $177.99 $154.00 - + Add to cart
39	SEAL, DUST Part #: 3KW-F3462-00-00 Required per assembly: 1 $2.35 $1.36 - + Add to cart
40	RACE, BALL, 1 Part #: 4C6-F3411-10-00 Required per assembly: 1 $6.49 $5.00 - + Add to cart
41	BOLT 1 Part #: 1CE-F3346-00-00 Required per assembly: 4 $1.60 $1.35 - + Add to cart
42	RING, SNAP Part #: 4P9-F3153-00-00 Required per assembly: 2 $0.28 $0.25 - + Add to cart
43	PLUG, HOLE Part #: 10B-F312G-00-00 Required per assembly: 1 $0.44 $0.34 - + Add to cart
44	HOLDER, BRAKE, HOSE, 1 Part #: BC9-F5875-00-00 Required per assembly: 1 $7.99 $6.49 - + Add to cart
45	HOLDER, BRAKE, HOSE, 1 Part #: BC9-F5875-10-00 Required per assembly: 1 $1.75 $1.44 - + Add to cart
46	BOLT, FLANGE Part #: 95817-06014-00 Required per assembly: 2 $2.79 $2.10 - + Add to cart
47	HOLDER, BRAKE, HOSE, 2 Part #: 2JS-F5876-00-00 Required per assembly: 1 $4.25 $3.52 - + Add to cart
48	HOLDER, BRAKE, HOSE, 2 Part #: 2JS-F5876-10-00 Required per assembly: 1 $2.35 $1.29 - + Add to cart
49	BOLT, FLANGE Part #: 95817-06012-00 Required per assembly: 1 $1.95 $1.47 - + Add to cart
50	RACE, BALL, 2 Part #: 4C6-F3412-00-00 Required per assembly: 1 $5.49 $4.16 - + Add to cart
51	RETAINER, BALL, BEARING Part #: 4C6-F341E-00-00 Required per assembly: 1 $4.65 $3.67 - + Add to cart
52	RACE, BALL, 4 Part #: 4C6-F3414-00-00 Required per assembly: 1 $6.49 $3.87 - + Add to cart
53	RACE, BALL, 3 Part #: 4C6-F3413-00-00 Required per assembly: 1 $6.49 $3.87 - + Add to cart
54	RETAINER, BALL, BEARING, 2 Part #: 4C6-F341D-00-00 Required per assembly: 1 $4.65 $3.67 - + Add to cart
55	COVER, BALL, RACE, 2 Part #: 4C6-F3416-00-00 Required per assembly: 1 $2.79 $1.35 - + Add to cart
56	NUT Part #: 90179-25811-00 Required per assembly: 3 $6.49 $4.02 - + Add to cart
57	WASHER, PLATE Part #: 90202-26142-00 Required per assembly: 1 $10.49 $7.92 - + Add to cart
58	WASHER, SPECIAL Part #: 4VP-F3418-00-00 Required per assembly: 1 $2.10 $1.71 - + Add to cart
59	COVER, BALL, RACE, 1 Part #: 41D-F3415-00-00 Required per assembly: 1 $2.25 $1.86 - + Add to cart
60	BRACKET, REFLECTOR, 1 Part #: BC9-H5112-00-00 Required per assembly: 1 $5.99 $4.51 - + Add to cart
61	BRACKET, REFLECTOR, 2 Part #: BC9-H5122-00-00 Required per assembly: 1 $9.49 $5.56 - + Add to cart
62	REFLECTOR, REAR, 1 Part #: 1CH-H5131-01-00 Required per assembly: 2 $6.49 $4.28 - + Add to cart
63	NUT, U, FLANGE Part #: 95604-06200-00 Required per assembly: 2 $2.95 $2.31 - + Add to cart
64	BOLT, FLANGE Part #: 95817-06014-00 Required per assembly: 1 $2.79 $2.10 - + Add to cart
