Frame replacement parts for 2018 Yamaha Wolverine X4 Special

OEM Parts Yamaha 2018 Yamaha Wolverine X4 Special Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRAME SET Part #: BG4-F11A0-19-00 Required per assembly: 1 $3,677.49 - + Add to cart
2	ENGINE BRACKET COMP. Part #: BG4-21410-00-00 Required per assembly: 1 ~~$80.98~~ $72.91 - + Add to cart
3	ENGINE BRACKET COMP. 2 Part #: BG4-21420-00-00 Required per assembly: 1 ~~$80.98~~ $72.91 - + Add to cart
4	BOLT, FLANGE, (3GD) Part #: 95817-10025-00 Required per assembly: 4 ~~$9.49~~ $8.31 - + Add to cart
5	BRACKET 5 Part #: BG4-F161F-00-00 Required per assembly: 1 ~~$13.49~~ $12.63 - + Add to cart
6	BRACKET 3 Part #: BG4-F161A-00-00 Required per assembly: 1 $9.87 - + Add to cart
7	BOLT, FLANGE, (JN5) Part #: 95817-12065-00 Required per assembly: 2 $6.59 - + Add to cart
8	BOLT, FLANGE Part #: 95812-10016-00 Required per assembly: 4 $10.84 - + Add to cart
9	BRACKET, ENGINE, 1 Part #: BG4-21490-00-00 Required per assembly: 2 ~~$81.98~~ $74.36 - + Add to cart
10	BOLT, FLANGE, (JN5) Part #: 95817-12065-00 Required per assembly: 2 $6.59 - + Add to cart
11	NUT, SELF-LOCKING Part #: 90185-10011-00 Required per assembly: 2 $5.77 - + Add to cart
12	SUPPORT, ENGINE Part #: BG4-F1283-00-00 Required per assembly: 1 ~~$15.99~~ $15.64 - + Add to cart
13	SUPT., ENGINE, 2 Part #: BG4-F1284-00-00 Required per assembly: 1 ~~$15.99~~ $15.56 - + Add to cart
14	BOLT, FLANGE, (3GD) Part #: 95817-10025-00 Required per assembly: 4 ~~$9.49~~ $8.31 - + Add to cart
15	BRACKET 1 Part #: BG4-F172K-00-00 Required per assembly: 1 $5.35 - + Add to cart
16	BOLT, FLANGE Part #: 95817-06010-00 Required per assembly: 2 ~~$5.49~~ $5.43 - + Add to cart
17	BRACKET 1 Part #: BG4-F172K-00-00 Required per assembly: 1 $5.35 - + Add to cart
18	BOLT, FLANGE Part #: 95817-06010-00 Required per assembly: 2 ~~$5.49~~ $5.43 - + Add to cart
19	STAY, SUPPORT, 1 Part #: BG4-F831T-00-00 Required per assembly: 1 $50.12 - + Add to cart
20	WASHER, PLATE Part #: 90201-12039-00 Required per assembly: 4 $5.12 - + Add to cart
21	BOLT, FLANGE Part #: 95812-12020-00 Required per assembly: 4 ~~$9.49~~ $8.40 - + Add to cart
22	BRKT., RR., AXLE Part #: BG4-F1981-00-00 Required per assembly: 1 $4.92 - + Add to cart
23	BOLT, FLANGE, (JN5) Part #: 95817-08016-00 Required per assembly: 2 $5.71 - + Add to cart
24	LUG, SEAT, RAIL, LH. Part #: BG4-F1143-10-00 Required per assembly: 1 $43.77 - + Add to cart
25	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 4 $2.13 - + Add to cart
26	MEMBER, SEAT, SUPPORT Part #: BG4-F255G-01-00 Required per assembly: 1 ~~$36.99~~ $32.99 - + Add to cart
27	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 4 $2.13 - + Add to cart
28	BRACKET, LOCK, 2 Part #: BG4-F287M-00-00 Required per assembly: 1 ~~$20.98~~ $19.12 - + Add to cart
29	BOLT, FLANGE Part #: 95817-10020-00 Required per assembly: 2 ~~$8.49~~ $5.15 - + Add to cart
30	STAY, MUFFLER, 2 Part #: BG4-F1446-00-00 Required per assembly: 1 $2.54 - + Add to cart
31	PROTECTOR 1 Part #: BG4-F834V-00-00 Required per assembly: 1 ~~$72.98~~ $65.48 - + Add to cart
32	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 2 $2.13 - + Add to cart
33	COVER 3 Part #: 2MB-F198J-00-00 Required per assembly: 2 $6.75 - + Add to cart
34	BOLT, SPECIAL, 1 Part #: JW1-K6179-01-00 Required per assembly: 2 $1.77 - + Add to cart
35	BRACKET, FOOTREST, 3 Part #: BG4-F144H-00-00 Required per assembly: 2 ~~$188.99~~ $142.48 - + Add to cart
36	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 4 $2.13 - + Add to cart
37	HOOK, SIDE, COVER, 1 Part #: BG4-F1331-00-00 Required per assembly: 2 ~~$9.49~~ $8.99 - + Add to cart
38	BOLT, FLANGE Part #: 95812-06014-00 Required per assembly: 4 $7.42 - + Add to cart
39	HOOK, SIDE, COVER, 3 Part #: BG4-F1333-00-00 Required per assembly: 1 ~~$227.99~~ $187.62 - + Add to cart
40	BOLT, FLANGE Part #: 95812-06014-00 Required per assembly: 2 $7.42 - + Add to cart
41	HOOK, SIDE, COVER, 4 Part #: BG4-F1334-00-00 Required per assembly: 1 ~~$188.99~~ $142.10 - + Add to cart
42	BOLT, FLANGE Part #: 95812-06014-00 Required per assembly: 2 $7.42 - + Add to cart
43	REINFORCEMENT, FRAME, 1 Part #: BG4-F1986-01-00 Required per assembly: 1 $1,086.94 - + Add to cart
44	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 3 $2.13 - + Add to cart
45	MOLD, FUEL, TANK Part #: 31A-24188-01-00 Required per assembly: 1 $14.78 - + Add to cart
46	TOOL KIT Part #: BG4-F8100-00-00 Required per assembly: 1 ~~$24.98~~ $20.56 - + Add to cart
47	GAUGE, AIR Part #: 1XD-F811A-00-00 Required per assembly: 1 $9.33 - + Add to cart
48	POUCH Part #: 1P0-F8186-01-00 Required per assembly: 1 $3.75 - + Add to cart
49	MOLD, FUEL, TANK Part #: 3VD-24188-00-00 Required per assembly: 1 ~~$41.99~~ $32.93 - + Add to cart
