Water Pump replacement parts for 2018 Yamaha YXZ1000R EPS SS SE

OEM Parts Yamaha 2018 Yamaha YXZ1000R EPS SS SE Water Pump

WATER PUMP Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	WATER PUMP ASSEMBLY Part #: 2HC-12420-00-00 Required per assembly: 1 ~~$233.99~~ $207.19 - + Add to cart
2	COVER, HOUSING Part #: 2HC-12422-00-00 Required per assembly: 1 ~~$69.98~~ $60.13 - + Add to cart
3	GASKET, HOUSING, COVER, 1 Part #: 8ES-12427-00-00 Required per assembly: 1 ~~$18.98~~ $14.82 - + Add to cart
4	SEAL, MECHANICAL Part #: 8ES-12438-00-00 Required per assembly: 1 ~~$49.99~~ $40.63 - + Add to cart
5	BRG, R-B, 6000, 26MM, 19G, KY Part #: 93306-00004-00 Required per assembly: 1 ~~$41.99~~ $32.13 - + Add to cart
6	OIL SEAL (SD 10-21-5 HS) Part #: 93102-10207-00 Required per assembly: 1 ~~$12.49~~ $10.05 - + Add to cart
7	GEAR, IMPELLER, SHAFT Part #: 8ES-12459-01-00 Required per assembly: 1 ~~$86.98~~ $71.17 - + Add to cart
8	IMPELLER SHAFT ASSEMBLY Part #: 8ES-12450-01-00 Required per assembly: 1 ~~$41.99~~ $32.27 - + Add to cart
9	SCREW, PAN, HEAD Part #: 98580-06016-00 Required per assembly: 3 ~~$3.45~~ $3.33 - + Add to cart
10	PIN, DOWEL Part #: 93604-16092-00 Required per assembly: 2 ~~$3.18~~ $1.96 - + Add to cart
11	CIRCLIP (2R6) Part #: 99001-08600-00 Required per assembly: 2 ~~$9.49~~ $6.05 - + Add to cart
12	HOSE 1 Part #: 2HC-1243A-00-00 Required per assembly: 1 ~~$5.49~~ $4.08 - + Add to cart
13	CLIP, SCISSOR Part #: 90467-07093-00 Required per assembly: 1 ~~$3.35~~ $1.74 - + Add to cart
14	GASKET Part #: 8ES-12435-00-00 Required per assembly: 1 ~~$16.48~~ $12.23 - + Add to cart
15	GASKET Part #: 8ES-12434-00-00 Required per assembly: 1 ~~$5.49~~ $3.49 - + Add to cart
16	PIN, DOWEL(6G8) Part #: 99530-08012-00 Required per assembly: 2 ~~$6.99~~ $6.49 - + Add to cart
17	BOLT, HEXAGON, SOCKET, HEAD Part #: 91312-06040-00 Required per assembly: 4 ~~$9.49~~ $6.21 - + Add to cart
18	BOLT, SOCKET Part #: 91317-06025-00 Required per assembly: 3 ~~$2.64~~ $2.01 - + Add to cart
19	GEAR, DRIVE Part #: 8ES-12436-00-00 Required per assembly: 1 ~~$62.99~~ $51.51 - + Add to cart
20	BRG, R-B, 6000, 26MM, 19G, KY Part #: 93306-00004-00 Required per assembly: 1 ~~$41.99~~ $32.13 - + Add to cart
21	CIRCLIP, R-TYPE Part #: 93420-26077-00 Required per assembly: 1 ~~$6.49~~ $5.50 - + Add to cart
22	HOUSING, THERMOSTAT Part #: 2HC-12417-00-00 Required per assembly: 1 ~~$56.99~~ $46.63 - + Add to cart
23	THERMOSTAT Part #: 5LP-12411-01-00 Required per assembly: 1 ~~$42.99~~ $33.37 - + Add to cart
24	COVER, THERMOSTAT Part #: 4NX-12413-00-00 Required per assembly: 1 ~~$34.99~~ $25.98 - + Add to cart
25	O-RING Part #: 93210-49046-00 Required per assembly: 1 ~~$8.49~~ $5.76 - + Add to cart
26	THERMOSENSOR ASSEMBLY Part #: 5YP-85790-00-00 Required per assembly: 1 ~~$70.98~~ $55.46 - + Add to cart
27	WASHER, PLATE Part #: 90201-12790-00 Required per assembly: 1 ~~$10.49~~ $6.73 - + Add to cart
28	BOLT, FLANGE Part #: 95022-06020-00 Required per assembly: 2 ~~$3.89~~ $3.27 - + Add to cart
29	PIPE 2 Part #: B5H-12482-00-00 Required per assembly: 1 ~~$73.98~~ $59.95 - + Add to cart
30	PIPE 5 Part #: 8GL-12485-00-00 Required per assembly: 1 ~~$12.49~~ $10.12 - + Add to cart
31	HOSE CLAMP ASSEMBLY (62T) Part #: 90450-14M05-00 Required per assembly: 1 ~~$19.48~~ $15.71 - + Add to cart
32	HOSE 7 Part #: 8FA-12551-01-00 Required per assembly: 1 Not Available
33	HOSE CLAMP ASSEMBLY Part #: 90450-35001-00 Required per assembly: 1 ~~$6.49~~ $5.16 - + Add to cart
34	HOSE 6 Part #: 2HC-12589-01-00 Required per assembly: 1 ~~$10.99~~ $7.15 - + Add to cart
35	HOSE CLAMP ASSEMBLY (63M) Part #: 90450-18M09-00 Required per assembly: 1 ~~$11.49~~ $11.32 - + Add to cart
36	BOLT, FLANGE Part #: 95022-06012-00 Required per assembly: 1 ~~$3.54~~ $2.95 - + Add to cart
37	GASKET Part #: 90430-06014-00 Required per assembly: 1 ~~$8.99~~ $7.11 - + Add to cart
38	HOSE CLAMP ASSEMBLY (64X) Part #: 90450-22M14-00 Required per assembly: 1 ~~$17.48~~ $14.35 - + Add to cart
39	HOSE CLAMP ASSEMBLY (62T) Part #: 90450-14M05-00 Required per assembly: 1 ~~$19.48~~ $15.71 - + Add to cart
40	HOSE CLAMP ASSEMBLY Part #: 90450-35001-00 Required per assembly: 1 ~~$6.49~~ $5.16 - + Add to cart
41	O-RING Part #: 93210-235A1-00 Required per assembly: 1 ~~$8.49~~ $5.65 - + Add to cart
42	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-06310-00 Required per assembly: 1 ~~$3.85~~ $2.57 - + Add to cart
43	HOSE 5 Part #: 2HC-12588-01-00 Required per assembly: 1 ~~$26.98~~ $20.06 - + Add to cart
44	HOSE CLAMP ASSEMBLY (63M) Part #: 90450-18M09-00 Required per assembly: 1 ~~$11.49~~ $11.32 - + Add to cart
45	HOSE CLAMP ASSEMBLY (64X) Part #: 90450-22M14-00 Required per assembly: 1 ~~$17.48~~ $14.35 - + Add to cart
