Rear Wheel 2 replacement parts for 2018 Yamaha YXZ1000R EPS SE

OEM Parts Yamaha 2018 Yamaha YXZ1000R EPS SE Rear Wheel 2

REAR WHEEL 2 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	CAST, WHEEL, REAR Part #: 2HC-F5307-51-00 Required per assembly: 1 $269.03 - + Add to cart
2	TIRE (27X11.00R14 Part #: 94111-14807-00 Required per assembly: 1 Not Available
3	VALVE, RIM, (TR413) Part #: 93900-00812-00 Required per assembly: 1 $9.49 $7.36 - + Add to cart
4	PLATE, LOCK Part #: 2HC-F4658-30-00 Required per assembly: 1 $191.99 $148.22 - + Add to cart
5	BOLT, FLANGE Part #: 90105-068C3-00 Required per assembly: 15 $1.80 $1.36 - + Add to cart
6	HUB, FRONT Part #: 2HC-F5111-01-00 Required per assembly: 1 $120.98 $88.35 - + Add to cart
7	BOLT, SERRATION Part #: 90114-12005-00 Required per assembly: 4 $3.20 $2.65 - + Add to cart
8	NUT, CROWN Part #: 90176-12800-00 Required per assembly: 4 $3.95 $2.98 - + Add to cart
9	REAR DRIVE SHAFT A Part #: 2HC-2531H-13-00 Required per assembly: 1 $299.88 - + Add to cart
10	BALL JOINT SET Part #: 2HC-2530T-12-00 Required per assembly: 1 $499.99 $491.31 - + Add to cart
11	DOUBLE OFF SET JOINT Part #: 2HC-2530V-00-00 Required per assembly: 1 $425.52 - + Add to cart
12	BOOT SET (BALL JOINT) Part #: 2HC-2530X-13-00 Required per assembly: 1 $53.99 $45.57 - + Add to cart
13	BOOT SET (DOUBLE OFFSET JOINT) Part #: 2HC-2530Y-01-00 Required per assembly: 1 $58.99 $46.63 - + Add to cart
14	CLIP, SPRING Part #: 2HC-2536E-00-00 Required per assembly: 1 $5.49 $4.49 - + Add to cart
15	RING 1 Part #: 16B-25185-00-00 Required per assembly: 1 $5.49 $3.40 - + Add to cart
16	CLIP, SPRING Part #: 16B-2536E-00-00 Required per assembly: 1 $5.49 $3.30 - + Add to cart
17	SNAP RING Part #: 2HC-2512J-00-00 Required per assembly: 1 $4.95 $4.10 - + Add to cart
18	BAND Part #: 2HC-25719-00-00 Required per assembly: 1 $7.49 $6.05 - + Add to cart
19	BAND Part #: 2HC-26293-00-00 Required per assembly: 1 $10.99 $8.56 - + Add to cart
20	BOOT BAND (SMALL) Part #: 2HC-2512G-10-00 Required per assembly: 1 $8.49 $7.00 - + Add to cart
21	BAND Part #: 2HC-26397-00-00 Required per assembly: 1 $5.99 $4.81 - + Add to cart
22	SHAFT Part #: 2HC-259A2-00-00 Required per assembly: 1 $117.98 $100.23 - + Add to cart
23	WASHER, PLATE Part #: 90201-25023-00 Required per assembly: 1 $11.49 $9.15 - + Add to cart
24	NUT Part #: 90179-24006-00 Required per assembly: 1 $15.49 $14.02 - + Add to cart
25	CAP, WHEEL Part #: 2HC-F512A-00-00 Required per assembly: 1 $3.25 $2.83 - + Add to cart
26	REAR KNUCKLE ASSEMBLY Part #: 2HC-F532F-02-00 Required per assembly: 1 $349.99 $322.30 - + Add to cart
27	BEARING Part #: 93305-00603-00 Required per assembly: 1 $139.99 $119.89 - + Add to cart
28	OIL SEAL Part #: 93106-42801-00 Required per assembly: 1 $6.49 $5.47 - + Add to cart
29	OIL SEAL Part #: 93106-38800-00 Required per assembly: 1 $15.49 $11.58 - + Add to cart
30	COLLAR Part #: 90387-30013-00 Required per assembly: 1 $16.48 $11.84 - + Add to cart
31	NIPPLE, GREASE(6A1) Part #: 93700-06M03-00 Required per assembly: 2 $8.49 $8.30 - + Add to cart
32	BUSH, SOLID(2NL) Part #: 90381-17067-00 Required per assembly: 4 $13.87 $12.61 - + Add to cart
33	CIRCLIP (70R) Part #: 93420-72065-00 Required per assembly: 1 $8.99 $8.30 - + Add to cart
34	COLLAR Part #: 90387-12060-00 Required per assembly: 1 $31.98 $24.24 - + Add to cart
35	COLLAR Part #: 90387-12061-00 Required per assembly: 1 $39.99 $31.31 - + Add to cart
36	COVER, THRUST, 1 Part #: 1XD-23517-00-00 Required per assembly: 4 $11.49 $9.18 - + Add to cart
37	BOLT, FLANGE Part #: 90105-12066-00 Required per assembly: 1 $13.49 $11.48 - + Add to cart
38	BOLT, FLANGE Part #: 90105-12097-00 Required per assembly: 1 $19.48 $15.86 - + Add to cart
39	NUT, SELF-LOCKING Part #: 90185-12007-00 Required per assembly: 2 $11.49 $8.77 - + Add to cart
40	RING, WHEEL, RR., 2 Part #: 2HC-F535C-00-00 Required per assembly: 1 $11.49 $8.75 - + Add to cart
41	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-06096-00 Required per assembly: 3 $9.49 $6.15 - + Add to cart
42	PLATE, GUIDE, 2 Part #: 2HC-F2342-00-00 Required per assembly: 1 $10.49 $7.00 - + Add to cart
43	BOLT, BUTTON, HEAD Part #: 92012-06012-00 Required per assembly: 2 $4.70 $2.45 - + Add to cart
