Front Fork replacement parts for 2018 Yamaha YZ250

OEM Parts Yamaha 2018 Yamaha YZ250 Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (L.H Part #: 1SS-23102-00-00 Required per assembly: 1 $1,976.13 - + Add to cart
2	TUBE, OUTER, 2 Part #: 1SS-23136-00-00 Required per assembly: 1 ~~$649.99~~ $617.68 - + Add to cart
3	RING, SNAP Part #: 17D-23153-00-00 Required per assembly: 1 $5.77 - + Add to cart
4	INNER TUBE COMP.2 Part #: 1SS-23120-00-00 Required per assembly: 1 ~~$504.99~~ $477.28 - + Add to cart
5	PISTON, FRONT, FORK Part #: 5XE-23171-L0-00 Required per assembly: 1 ~~$30.98~~ $22.74 - + Add to cart
6	METAL, SLIDE, 1 Part #: 5XE-23125-L0-00 Required per assembly: 1 ~~$28.98~~ $22.98 - + Add to cart
7	WASHER, OIL, SEAL Part #: 5XC-23146-10-00 Required per assembly: 1 ~~$15.49~~ $13.11 - + Add to cart
8	OIL SEAL Part #: 17D-23145-00-00 Required per assembly: 1 ~~$30.98~~ $24.22 - + Add to cart
9	RING, SNAP Part #: 5XE-23153-L0-00 Required per assembly: 1 $8.63 - + Add to cart
10	SEAL, DUST Part #: 5XE-23144-L0-00 Required per assembly: 1 ~~$24.98~~ $21.65 - + Add to cart
11	CYLINDER, COMP., FRONT, FORK Part #: 1SS-23170-00-00 Required per assembly: 1 ~~$644.99~~ $630.73 - + Add to cart
12	O-RING Part #: 1C3-23147-L1-00 Required per assembly: 1 $4.48 - + Add to cart
13	SEAT, SPRING, UPPER Part #: 17D-23142-00-00 Required per assembly: 1 ~~$80.98~~ $67.44 - + Add to cart
14	VALVE COMP. Part #: 1SS-2316A-00-00 Required per assembly: 1 ~~$412.99~~ $400.47 - + Add to cart
15	O-RING Part #: 1C3-23188-L1-00 Required per assembly: 1 $3.86 - + Add to cart
16	O-RING Part #: 1C3-23188-N0-00 Required per assembly: 1 $8.63 - + Add to cart
17	O-RING Part #: 1C3-23188-P0-00 Required per assembly: 1 $8.63 - + Add to cart
18	GASKET Part #: 1W4-23114-L0-00 Required per assembly: 2 $9.87 - + Add to cart
19	AIR VALVE COMP. Part #: 1C3-23190-L1-00 Required per assembly: 1 ~~$25.98~~ $22.27 - + Add to cart
20	O-RING Part #: 1C3-23188-R1-00 Required per assembly: 1 ~~$4.29~~ $3.86 - + Add to cart
21	SPRING, FRONT, FORK, (K=43N/MM) Part #: 1C3-23141-E1-00 Required per assembly: 1 Note: AP Not Available
22	BOLT, CAP Part #: 5XC-23111-01-00 Required per assembly: 1 ~~$78.98~~ $65.77 - + Add to cart
23	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $12.60 - + Add to cart
24	GASKET Part #: 276-23114-01-00 Required per assembly: 1 $5.39 - + Add to cart
25	FRONT FORK ASSEMBLY (R.H Part #: 1SS-23103-00-00 Required per assembly: 1 $1,585.13 - + Add to cart
26	TUBE, OUTER, 2 Part #: 1SS-23136-00-00 Required per assembly: 1 ~~$649.99~~ $617.68 - + Add to cart
27	RING, SNAP Part #: 17D-23153-00-00 Required per assembly: 1 $5.77 - + Add to cart
28	INNER TUBE COMP.1 Part #: 1SS-23110-00-00 Required per assembly: 1 ~~$519.99~~ $489.15 - + Add to cart
29	PISTON, FRONT, FORK Part #: 5XE-23171-L0-00 Required per assembly: 1 ~~$30.98~~ $22.74 - + Add to cart
30	METAL, SLIDE, 1 Part #: 5XE-23125-L0-00 Required per assembly: 1 ~~$28.98~~ $22.98 - + Add to cart
31	WASHER, OIL, SEAL Part #: 5XC-23146-10-00 Required per assembly: 1 ~~$15.49~~ $13.11 - + Add to cart
32	OIL SEAL Part #: 17D-23145-00-00 Required per assembly: 1 ~~$30.98~~ $24.22 - + Add to cart
33	RING, SNAP Part #: 5XE-23153-L0-00 Required per assembly: 1 $8.63 - + Add to cart
34	SEAL, DUST Part #: 5XE-23144-L0-00 Required per assembly: 1 ~~$24.98~~ $21.65 - + Add to cart
35	CYLINDER, COMP., FRONT, FORK Part #: 1SS-23170-00-00 Required per assembly: 1 ~~$644.99~~ $630.73 - + Add to cart
36	O-RING Part #: 1C3-23147-L1-00 Required per assembly: 1 $4.48 - + Add to cart
37	SEAT, SPRING, UPPER Part #: 17D-23142-00-00 Required per assembly: 1 ~~$80.98~~ $67.44 - + Add to cart
38	VALVE COMP. Part #: 1SS-2316A-00-00 Required per assembly: 1 ~~$412.99~~ $400.47 - + Add to cart
39	O-RING Part #: 1C3-23188-L1-00 Required per assembly: 1 $3.86 - + Add to cart
40	O-RING Part #: 1C3-23188-N0-00 Required per assembly: 1 $8.63 - + Add to cart
41	O-RING Part #: 1C3-23188-P0-00 Required per assembly: 1 $8.63 - + Add to cart
42	GASKET Part #: 1W4-23114-L0-00 Required per assembly: 2 $9.87 - + Add to cart
43	AIR VALVE COMP. Part #: 1C3-23190-L1-00 Required per assembly: 1 ~~$25.98~~ $22.27 - + Add to cart
44	O-RING Part #: 1C3-23188-R1-00 Required per assembly: 1 ~~$4.29~~ $3.86 - + Add to cart
45	SPRING, FRONT, FORK, (K=43N/MM) Part #: 1C3-23141-E1-00 Required per assembly: 1 Note: AP Not Available
46	BOLT, CAP Part #: 5XC-23111-01-00 Required per assembly: 1 ~~$78.98~~ $65.77 - + Add to cart
47	GASKET Part #: 2HH-23158-L0-00 Required per assembly: 1 $12.60 - + Add to cart
48	GASKET Part #: 276-23114-01-00 Required per assembly: 1 $5.39 - + Add to cart
49	UNDER BRACKET COMP. Part #: 1SS-23340-10-00 Required per assembly: 1 $630.78 - + Add to cart
50	BEARING (4SR) Part #: 93332-00081-00 Required per assembly: 1 $63.99 - + Add to cart
51	BOLT, FLANGE Part #: 90105-08154-00 Required per assembly: 8 ~~$8.49~~ $7.83 - + Add to cart
52	GUIDE, CABLE Part #: 1SS-23389-00-00 Required per assembly: 1 $4.48 - + Add to cart
53	BOLT, FLANGE Part #: 90105-06107-00 Required per assembly: 1 ~~$9.49~~ $8.31 - + Add to cart
54	COLLAR Part #: 90387-06104-00 Required per assembly: 1 $1.90 - + Add to cart
55	PROTECTOR 2 Part #: 17D-2315J-50-00 Required per assembly: 1 $27.50 - + Add to cart
56	PROTECTOR 1 Part #: 17D-2315H-50-00 Required per assembly: 1 $27.50 - + Add to cart
57	BOLT Part #: 90109-06232-00 Required per assembly: 6 $4.87 - + Add to cart
58	CLAMP Part #: 17D-23466-00-00 Required per assembly: 1 ~~$18.98~~ $18.90 - + Add to cart
59	CLAMP Part #: 17D-23467-00-00 Required per assembly: 1 ~~$27.98~~ $23.64 - + Add to cart
60	BOLT, FLANGE Part #: 90105-06170-00 Required per assembly: 2 $5.85 - + Add to cart
61	FORK SEALS KIT Part #: 17D-W003B-00-00 Required per assembly: 1 $95.95 - + Add to cart
