2019 Honda CBF300N CB300R - Speedometer

SPEEDOMETER Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
F 02
001

METER, COMBINATION

Part #: 37100-K0A-A03 Required per assembly: 1
$299.40
$261.88
002

CASE ASSEMBLY (UPPER)

Part #: 37110-K0A-J02 Required per assembly: 1
$37.16
$29.64
003

CASE ASSEMBLY (LOWER)

Part #: 37120-K94-T01 Required per assembly: 1
$17.69
$14.11
004

METER, LCD, (MPH/KPH)

Part #: 37130-K0A-A01 Required per assembly: 1
$239.82
$237.87
005

KEY, TOP

Part #: 37205-K94-T01 Required per assembly: 2
$2.34
$2.17
006

RUB, METER, SETTING

Part #: 37215-KZZ-900 Required per assembly: 3
$2.48
$2.29
007

COVER, METER

Part #: 64110-K94-T00 Required per assembly: 1
$7.64
$6.59
008

SCREW, TAP, (3X14)

Part #: 90101-KY6-008 Required per assembly: 5
$3.64
$3.31
009

SCREW, PAN, (5X14)

Part #: 90134-KPP-T00 Required per assembly: 2
$2.02
$1.87
010

NUT, CLIP, (5MM)

Part #: 90677-KAN-T00 Required per assembly: 2
$1.72
$1.58
011

SCREW, TAP, (5X14)

Part #: 93913-25380 Required per assembly: 3
$1.95
$1.80
012

WASHER, PLAIN, (5MM)

Part #: 94103-05700 Required per assembly: 3
$1.98
$1.83
