OEM Parts Honda 2019 Honda SXS1000M3P Oil Pan

2019 Honda SXS1000M3P Pioneer 1000 EPS - Oil Pan

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
E 1410
001

PAN, OIL

Part #: 11211-HL4-000 Required per assembly: 1
$189.62
$153.48
-
+
Add to cart
002

GASKET, OIL, PAN

Part #: 11395-HL4-003 Required per assembly: 1
$12.55
$10.01
-
+
Add to cart
003

STRAINER, OIL

Part #: 15150-HL4-003 Required per assembly: 1
$35.03
$29.20
-
+
Add to cart
004

GASKET, OIL, STRAINER

Part #: 15154-MAT-000 Required per assembly: 1
$7.40
$6.49
-
+
Add to cart
005

BOLT, DRAIN, (12X15)

Part #: 90131-896-650 Required per assembly: 1
$4.52
-
+
Add to cart
006
Honda 94109-12000 Washer, Drain, (12Mm)

WASHER, DRAIN, (12MM)

Part #: 94109-12000 Required per assembly: 1
$2.17
$1.97
-
+
Add to cart
007

BOLT, FLANGE, (6X30)

Part #: 95701-06030-00 Required per assembly: 12
$2.87
$2.67
-
+
Add to cart
