Frame replacement parts for 2019 Honda SXS1000S2X

OEM Parts Honda 2019 Honda SXS1000S2X Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 46
001	CABLE, FRAME, GROUND Part #: 32603-HL6-A00 Required per assembly: 1 $5.85 $5.17 - + Add to cart
002	FRAME COMP NHC12 Part #: 50100-HL6-A01ZA Required per assembly: 1 $5,799.56 $4,625.15 - + Add to cart
003	BRACKET, R., ENGINE, HANGER Part #: 50310-HL6-A40 Required per assembly: 1 $103.57 $97.59 - + Add to cart
004	BRACKET, L., ENGINE, HANGER Part #: 50320-HL6-A40 Required per assembly: 1 $65.36 $52.13 - + Add to cart
005	COVER, RR., BED, PLATE Part #: 50500-HL6-A00 Required per assembly: 1 $32.18 $25.67 - + Add to cart
006	PIPE, R., SEAT, FRAME, NHC12(MAT, SATIN, BLACK) Part #: 50600-HL6-A00ZA Required per assembly: 1 $704.44 - + Add to cart
007	RUBBER, ASSEMBLY, ENGINE, MOUNTING Part #: 50810-HL6-A01 Required per assembly: 4 $25.36 $21.04 - + Add to cart
008	RUBBER, SEAT, CUSHION Part #: 77206-GF0-000 Required per assembly: 3 $6.57 $5.81 - + Add to cart
009	BOLT, FLANGE, (10X70) Part #: 90165-S5A-000 Required per assembly: 4 $11.77 $10.50 - + Add to cart
010	NUT (10MM) Part #: 90305-HC0-770 Required per assembly: 4 $4.30 $3.91 - + Add to cart
011	BOLT-WASHER (6X12) Part #: 93405-06012-08 Required per assembly: 4 Note: (6X12) (Honda Code 2646677) $2.56 $2.38 - + Add to cart
012	BOLT-WASHER (8X35) Part #: 93406-08035-08 Required per assembly: 2 $1.99 $1.84 - + Add to cart
013	NUT, FLANGE, (8MM) Part #: 94050-08080 Required per assembly: 6 $2.01 $1.83 - + Add to cart
014	NUT, FLANGE, (10MM) Part #: 94050-10080 Required per assembly: 6 $4.44 - + Add to cart
015	BOLT, FLANGE, (6X12) Part #: 95701-06012-00 Required per assembly: 2 $2.63 $2.44 - + Add to cart
016	BOLT, FLANGE, (8X40) Part #: 95701-08040-08 Required per assembly: 2 $3.25 $3.02 - + Add to cart
017	BOLT, FLANGE, (8X60) Part #: 95701-08060-08 Required per assembly: 2 $3.18 - + Add to cart
018	BOLT, FLANGE, (10X18) Part #: 95701-10018-08 Required per assembly: 8 $3.21 $2.99 - + Add to cart
019	BOLT, FLANGE, (10X32) Part #: 95701-10032-08 Required per assembly: 2 $3.26 $3.03 - + Add to cart
020	BOLT, FLANGE, (10X70) Part #: 95801-10070-08 Required per assembly: 6 $3.90 - + Add to cart
