Engine, Crankcase replacement parts for 2019 Polaris Scrambler 1000 XP EU (R02)

OEM Parts Polaris 2019 Polaris Scrambler 1000 XP EU (R02) Engine, Crankcase

ENGINE, CRANKCASE Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	KIT, CRANKCASE Part #: 2205144 Required per assembly: 1 Note: INCL. 2,4-6, 9-12, CASES Currently Not Available
2	PIN, DOWEL Part #: 5132835 Required per assembly: 8 Currently Not Available
3	SEAL, BALANCE, SHAFT Part #: 3610144 Required per assembly: 2 Currently Not Available
4	PLUG Part #: 7052337 Required per assembly: 3 Currently Not Available
5	PLUG Part #: 7052413 Required per assembly: 3 Currently Not Available
6	PLUG, SOCKET Part #: 7518835 Required per assembly: 3 Currently Not Available
7	BEARING-MAIN UPPER FRONT 55MM Part #: 3515829 Required per assembly: 4 Currently Not Available
8	BEARING-MAIN UPPER CENTER 55MM Part #: 3515830 Required per assembly: 2 Currently Not Available
9	SCREW Part #: 7518804 Required per assembly: 4 Currently Not Available
10	SCREW Part #: 7518805 Required per assembly: 2 Currently Not Available
11	SCREW Part #: 7518578 Required per assembly: 2 Currently Not Available
12	SCREW Part #: 7518576 Required per assembly: 12 Currently Not Available
13	SEAL, CRANKSHAFT Part #: 3610152 Required per assembly: 1 Currently Not Available
14	SEAL, CRANKSHAFT Part #: 3610220 Required per assembly: 1 Currently Not Available
15	SEAL, BALANCE, SHAFT Part #: 3610144 Required per assembly: 1 Currently Not Available
