Gunwale & Mat replacement parts for 2019 Yamaha FX Cruiser HO

OEM Parts Yamaha 2019 Yamaha FX Cruiser HO Gunwale & Mat

GUNWALE & MAT Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	GUNWALE, BOW Part #: F3X-U2511-11-00 Required per assembly: 1 $99.28 - + Add to cart
2	BOLT, SPECIAL Part #: F7K-U491K-00-00 Required per assembly: 2 ~~$7.12~~ $4.84 - + Add to cart
3	NUT, LOCK Part #: F2N-U142L-00-00 Required per assembly: 2 ~~$6.11~~ $1.51 - + Add to cart
4	GUNWALE, SIDE Part #: F3X-U2512-00-00 Required per assembly: 2 $175.67 - + Add to cart
4	GUNWALE, SIDE Part #: F3X-U2512-10-00 Required per assembly: 2 $176.43 - + Add to cart
5	INNER, GUNWALE Part #: F3X-U2519-10-00 Required per assembly: 2 $43.13 - + Add to cart
5	INNER, GUNWALE Part #: F3X-U2519-20-00 Required per assembly: 2 ~~$24.46~~ $24.13 - + Add to cart
6	RIVET, BLIND Part #: 90267-489U8-00 Required per assembly: 12 ~~$6.99~~ $1.44 - + Add to cart
7	WASHER Part #: 9299R-05200-00 Required per assembly: 12 ~~$7.12~~ $4.84 - + Add to cart
8	JOINT, GUNWALE, LH Part #: F3X-U252E-10-00 Required per assembly: 1 ~~$52.00~~ $49.31 - + Add to cart
9	GUNWALL INSIDE Part #: F3X-U2514-60-00 Required per assembly: 1 ~~$112.19~~ $87.68 - + Add to cart
9	GUNWALL INSIDE Part #: F3X-U2514-00-00 Required per assembly: 1 ~~$18.35~~ $12.08 - + Add to cart
10	BOLT, SPECIAL Part #: F7K-U491K-00-00 Required per assembly: 1 ~~$7.12~~ $4.84 - + Add to cart
11	SCREW Part #: F3X-U7823-12-00 Required per assembly: 3 ~~$5.99~~ $1.32 - + Add to cart
12	SCREW Part #: F4G-U7823-10-00 Required per assembly: 2 ~~$10.99~~ $5.29 - + Add to cart
13	BRACKET Part #: F3X-U4949-00-00 Required per assembly: 2 ~~$7.12~~ $2.80 - + Add to cart
14	RIVET, BLIND Part #: 90267-489U6-00 Required per assembly: 4 ~~$7.12~~ $1.51 - + Add to cart
15	NUT, LOCK Part #: F2N-U142L-00-00 Required per assembly: 4 ~~$6.11~~ $1.51 - + Add to cart
16	JOINT, GUNWALE, RH Part #: F3X-U252F-10-00 Required per assembly: 1 ~~$52.00~~ $49.31 - + Add to cart
17	GUNWALL INSIDE Part #: F3X-U2514-70-00 Required per assembly: 1 ~~$18.35~~ $12.08 - + Add to cart
17	GUNWALL INSIDE Part #: F3X-U2514-10-00 Required per assembly: 1 ~~$18.35~~ $12.08 - + Add to cart
18	BOLT, SPECIAL Part #: F7K-U491K-00-00 Required per assembly: 1 ~~$7.12~~ $4.84 - + Add to cart
19	SCREW Part #: F3X-U7823-12-00 Required per assembly: 3 ~~$5.99~~ $1.32 - + Add to cart
20	SCREW Part #: F4G-U7823-10-00 Required per assembly: 2 ~~$10.99~~ $5.29 - + Add to cart
21	BRACKET Part #: F3X-U4949-00-00 Required per assembly: 2 ~~$7.12~~ $2.80 - + Add to cart
22	RIVET, BLIND Part #: 90267-489U6-00 Required per assembly: 4 ~~$7.12~~ $1.51 - + Add to cart
23	NUT, LOCK Part #: F2N-U142L-00-00 Required per assembly: 4 ~~$6.11~~ $1.51 - + Add to cart
24	GUNWALE, STERN, 1 Part #: F3X-U251D-10-00 Required per assembly: 1 ~~$44.86~~ $43.72 - + Add to cart
25	INNER, GUNWALE, AFT Part #: F3X-U255C-00-00 Required per assembly: 1 $30.13 - + Add to cart
25	INNER, GUNWALE, AFT Part #: F3X-U255C-60-00 Required per assembly: 1 $58.23 - + Add to cart
26	BOLT, SPECIAL Part #: F7K-U491K-00-00 Required per assembly: 2 ~~$7.12~~ $4.84 - + Add to cart
27	SCREW Part #: F3X-U7823-12-00 Required per assembly: 2 ~~$5.99~~ $1.32 - + Add to cart
28	NUT, LOCK Part #: F2N-U142L-00-00 Required per assembly: 4 ~~$6.11~~ $1.51 - + Add to cart
29	GUNWALE, STERN, 2 Part #: F3X-U251E-10-00 Required per assembly: 1 ~~$44.86~~ $40.72 - + Add to cart
30	INNER, GUNWALE, AFT Part #: F3X-U255C-70-00 Required per assembly: 1 $29.60 - + Add to cart
30	INNER, GUNWALE, AFT Part #: F3X-U255C-10-00 Required per assembly: 1 $30.13 - + Add to cart
31	BOLT, SPECIAL Part #: F7K-U491K-00-00 Required per assembly: 2 ~~$7.12~~ $4.84 - + Add to cart
32	SCREW Part #: F3X-U7823-12-00 Required per assembly: 2 ~~$5.99~~ $1.32 - + Add to cart
33	NUT, LOCK Part #: F2N-U142L-00-00 Required per assembly: 4 ~~$6.11~~ $1.51 - + Add to cart
34	COVER, GUNWALE, 1 Part #: F3X-U252C-10-00 Required per assembly: 1 $65.86 - + Add to cart
34	COVER, GUNWALE, 1 Part #: F3X-U252C-01-00 Required per assembly: 1 ~~$14.27~~ $11.32 - + Add to cart
35	BOLT, SPECIAL Part #: F7K-U491K-00-00 Required per assembly: 2 ~~$7.12~~ $4.84 - + Add to cart
36	NUT, LOCK Part #: F2N-U142L-00-00 Required per assembly: 2 ~~$6.11~~ $1.51 - + Add to cart
37	MAT, UPPER Part #: F3X-U3581-01-00 Required per assembly: 1 ~~$96.89~~ $84.56 - + Add to cart
38	MAT, STEP, 1 Part #: F3X-U351H-00-00 Required per assembly: 1 ~~$42.82~~ $31.72 - + Add to cart
39	MAT, STEP, 2 Part #: F3X-U351J-00-00 Required per assembly: 1 ~~$42.82~~ $31.72 - + Add to cart
40	MAT, STEP, 3 Part #: F3X-U351K-00-00 Required per assembly: 1 ~~$57.10~~ $45.33 - + Add to cart
41	MAT, STEP, 4 Part #: F3X-U351M-00-00 Required per assembly: 1 ~~$57.10~~ $45.33 - + Add to cart
42	MAT, STEP, 5 Part #: F3X-U351N-00-00 Required per assembly: 1 ~~$60.17~~ $46.84 - + Add to cart
43	MAT, STEP, 6 Part #: F3X-U351P-00-00 Required per assembly: 1 ~~$60.17~~ $46.84 - + Add to cart
44	WASHER, PLATE Part #: 90201-06805-00 Required per assembly: 4 ~~$0.30~~ $0.28 - + Add to cart
